mod_atmos_phy_tb_driver Module Reference

module ATMOSPHERE / Physics Turbulence More...

Functions/Subroutines
subroutine, public	atmos_phy_tb_driver_tracer_setup
	Tracer setup. More...
subroutine, public	atmos_phy_tb_driver_setup
	Setup. More...
subroutine, public	atmos_phy_tb_driver_finalize
	finalize More...
subroutine, public	atmos_phy_tb_driver_calc_tendency (update_flag)
	calclate tendency More...

Detailed Description

module ATMOSPHERE / Physics Turbulence

Description

Sub-grid scale turbulence process

Author

Team SCALE

NAMELIST

• No namelist group

History Output

name	description	unit	variable
SGS_XFLX_{TRACER_NAME}	SGS X FLUX of {TRACER_NAME}; {TRACER_NAME} depends on the physics schemes, e.g., QV, QC, QR.	kg/m2/s	QFLX_RHOQ
SGS_YFLX_{TRACER_NAME}	SGS Y FLUX of {TRACER_NAME}; {TRACER_NAME} depends on the physics schemes, e.g., QV, QC, QR.	kg/m2/s	QFLX_RHOQ
SGS_ZFLX_{TRACER_NAME}	SGS Z FLUX of {TRACER_NAME}; {TRACER_NAME} depends on the physics schemes, e.g., QV, QC, QR.	kg/m2/s	QFLX_RHOQ
MOMX_t_TB	MOMX tendency (TB)	kg/m2/s2	MOMX_t_TB
MOMY_t_TB	MOMY tendency (TB)	kg/m2/s2	MOMY_t_TB
MOMZ_t_TB	MOMZ tendency (TB)	kg/m2/s2	MOMZ_t_TB
NU	eddy viscosity	m2/s	NU
Pr	Prantle number	NIL	Pr
RHOT_t_TB	RHOT tendency (TB)	K.kg/m3/s	RHOT_t_TB
Ri	Richardson number	NIL	Ri
SGS_XFLX_MOMX	SGS X FLUX of MOMX	kg/m/s2	QFLX_MOMX
SGS_XFLX_MOMY	SGS X FLUX of MOMY	kg/m/s2	QFLX_MOMY
SGS_XFLX_MOMZ	SGS X FLUX of MOMZ	kg/m/s2	QFLX_MOMZ
SGS_XFLX_RHOT	SGS X FLUX of RHOT	K*kg/m2/s	QFLX_RHOT
SGS_YFLX_MOMX	SGS Y FLUX of MOMX	kg/m/s2	QFLX_MOMX
SGS_YFLX_MOMY	SGS Y FLUX of MOMY	kg/m/s2	QFLX_MOMY
SGS_YFLX_MOMZ	SGS Y FLUX of MOMZ	kg/m/s2	QFLX_MOMZ
SGS_YFLX_RHOT	SGS Y FLUX of RHOT	K*kg/m2/s	QFLX_RHOT
SGS_ZFLX_MOMX	SGS Z FLUX of MOMX	kg/m/s2	QFLX_MOMX
SGS_ZFLX_MOMY	SGS Z FLUX of MOMY	kg/m/s2	QFLX_MOMY
SGS_ZFLX_MOMZ	SGS Z FLUX of MOMZ	kg/m/s2	QFLX_MOMZ
SGS_ZFLX_RHOT	SGS Z FLUX of RHOT	K*kg/m2/s	QFLX_RHOT
{TRACER_NAME}_t_TB	tendency rho*{TRACER_NAME} in TB; {TRACER_NAME} depends on the physics schemes, e.g., QV, QC, QR.	kg/m3/s	RHOQ_t_TB

Function/Subroutine Documentation

atmos_phy_tb_driver_tracer_setup()

subroutine, public mod_atmos_phy_tb_driver::atmos_phy_tb_driver_tracer_setup

Tracer setup.

Definition at line 56 of file mod_atmos_phy_tb_driver.F90.

    use scale_prc, only: &
       prc_abort
    use scale_atmos_phy_tb_d1980, only: &
       atmos_phy_tb_d1980_config
    use scale_atmos_phy_tb_dns, only: &
       atmos_phy_tb_dns_config
    use mod_atmos_admin, only: &
       atmos_phy_tb_type, &
       atmos_sw_phy_tb
    use mod_atmos_phy_tb_vars, only: &
       i_tke
    implicit none
    !---------------------------------------------------------------------------

    if ( .not. atmos_sw_phy_tb ) return

    log_newline
    log_info("ATMOS_PHY_TB_driver_tracer_setup",*) 'Setup'

    select case( atmos_phy_tb_type )
    case( 'SMAGORINSKY' )
       i_tke = -1
    case( 'D1980' )
       call atmos_phy_tb_d1980_config( atmos_phy_tb_type, & ! [IN]
                                       i_tke              ) ! [OUT]
    case( 'DNS' )
       call atmos_phy_tb_dns_config( atmos_phy_tb_type, & ! [IN]
                                     i_tke              ) ! [OUT]
    case('OFF')
       ! do nothing
    case default
       log_error("ATMOS_PHY_TB_driver_tracer_setup",*) 'ATMOS_PHY_TB_TYPE is invalid: ', atmos_phy_tb_type
       call prc_abort
    end select

    return

References scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_config(), scale_atmos_phy_tb_dns::atmos_phy_tb_dns_config(), mod_atmos_admin::atmos_phy_tb_type, mod_atmos_admin::atmos_sw_phy_tb, mod_atmos_phy_tb_vars::i_tke, and scale_prc::prc_abort().

Referenced by mod_atmos_driver::atmos_driver_tracer_setup().

Here is the call graph for this function:

Here is the caller graph for this function:

atmos_phy_tb_driver_setup()

subroutine, public mod_atmos_phy_tb_driver::atmos_phy_tb_driver_setup

Setup.

Definition at line 97 of file mod_atmos_phy_tb_driver.F90.

    use scale_atmos_grid_cartesc, only: &
       cdz => atmos_grid_cartesc_cdz, &
       cdx => atmos_grid_cartesc_cdx, &
       cdy => atmos_grid_cartesc_cdy
    use scale_atmos_grid_cartesc_real, only: &
       real_cz  => atmos_grid_cartesc_real_cz, &
       real_fz  => atmos_grid_cartesc_real_fz
    use scale_atmos_grid_cartesc_metric, only: &
       mapf  => atmos_grid_cartesc_metric_mapf
    use scale_atmos_phy_tb_smg, only: &
       atmos_phy_tb_smg_setup
    use scale_atmos_phy_tb_d1980, only: &
       atmos_phy_tb_d1980_setup
    use scale_atmos_phy_tb_dns, only: &
       atmos_phy_tb_dns_setup
    use mod_atmos_admin, only: &
       atmos_phy_tb_type, &
       atmos_sw_phy_tb,   &
       atmos_sw_phy_bl
    use mod_atmos_phy_tb_vars, only: &
       momz_t_tb => atmos_phy_tb_momz_t
    use scale_monitor, only: &
       monitor_reg
    implicit none

    integer :: i, j
    logical :: horizontal = .false.
    !---------------------------------------------------------------------------

    if ( .not. atmos_sw_phy_tb ) return

    log_newline
    log_info("ATMOS_PHY_TB_driver_setup",*) 'Setup'

    ! initialize
    !$omp parallel do
    !$acc kernels copy(MOMZ_t_TB)
    do j = js, je
    do i = is, ie
       momz_t_tb(ks-1,i,j) = 0.0_rp
       momz_t_tb(ke  ,i,j) = 0.0_rp
    enddo
    enddo
    !$acc end kernels

    ! setup library component
    select case( atmos_phy_tb_type )
    case( 'SMAGORINSKY' )
       if ( atmos_sw_phy_bl ) horizontal = .true.
       call atmos_phy_tb_smg_setup( real_fz, real_cz, cdx, cdy, mapf(:,:,:,i_xy), horizontal ) ! [IN]
    case( 'D1980' )
       call atmos_phy_tb_d1980_setup( cdz, cdx, cdy, real_cz ) ! [IN]
    case( 'DNS' )
       call atmos_phy_tb_dns_setup( cdz, cdx, cdy, real_cz ) ! [IN]
    end select


    ! monitor
    call monitor_reg( "QTOTFLX_TB_WEST",  "water mass flux at the western boundary",  "kg", & ! [IN]
                      monit_west,                                                           & ! [OUT]
                      dim_type="ZY-W", is_tendency=.true.                                   ) ! [IN]
    call monitor_reg( "QTOTFLX_TB_EAST",  "water mass flux at the eastern boundary",  "kg", & ! [IN]
                      monit_east,                                                           & ! [OUT]
                      dim_type="ZY-E", is_tendency=.true.                                   ) ! [IN]
    call monitor_reg( "QTOTFLX_TB_SOUTH", "water mass flux at the southern boundary", "kg", & ! [IN]
                      monit_south,                                                          & ! [OUT]
                      dim_type="ZX-S", is_tendency=.true.                                   ) ! [IN]
    call monitor_reg( "QTOTFLX_TB_NORTH", "water mass flux at the northern boundary", "kg", & ! [IN]
                      monit_north,                                                          & ! [OUT]
                      dim_type="ZX-N", is_tendency=.true.                                   ) ! [IN]


    return

References scale_atmos_grid_cartesc::atmos_grid_cartesc_cdx, scale_atmos_grid_cartesc::atmos_grid_cartesc_cdy, scale_atmos_grid_cartesc::atmos_grid_cartesc_cdz, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_mapf, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_cz, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_fz, scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_setup(), scale_atmos_phy_tb_dns::atmos_phy_tb_dns_setup(), mod_atmos_phy_tb_vars::atmos_phy_tb_momz_t, scale_atmos_phy_tb_smg::atmos_phy_tb_smg_setup(), mod_atmos_admin::atmos_phy_tb_type, mod_atmos_admin::atmos_sw_phy_bl, mod_atmos_admin::atmos_sw_phy_tb, scale_atmos_grid_cartesc_index::i_xy, scale_atmos_grid_cartesc_index::ie, scale_atmos_grid_cartesc_index::is, scale_atmos_grid_cartesc_index::je, scale_atmos_grid_cartesc_index::js, scale_atmos_grid_cartesc_index::ke, scale_atmos_grid_cartesc_index::ks, and scale_monitor::monitor_reg().

Referenced by mod_atmos_driver::atmos_driver_setup().

Here is the call graph for this function:

Here is the caller graph for this function:

atmos_phy_tb_driver_finalize()

subroutine, public mod_atmos_phy_tb_driver::atmos_phy_tb_driver_finalize

finalize

Definition at line 175 of file mod_atmos_phy_tb_driver.F90.

    use scale_atmos_phy_tb_smg, only: &
       atmos_phy_tb_smg_finalize
    use scale_atmos_phy_tb_d1980, only: &
       atmos_phy_tb_d1980_finalize
    use mod_atmos_admin, only: &
       atmos_phy_tb_type, &
       atmos_sw_phy_tb
    implicit none
    !---------------------------------------------------------------------------

    log_newline
    log_info("ATMOS_PHY_TB_driver_finalize",*) 'Finalize'

    if ( .not. atmos_sw_phy_tb ) return

    select case( atmos_phy_tb_type )
    case( 'SMAGORINSKY' )
       call atmos_phy_tb_smg_finalize
    case( 'D1980' )
       call atmos_phy_tb_d1980_finalize
    end select

    return

References scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_finalize(), scale_atmos_phy_tb_smg::atmos_phy_tb_smg_finalize(), mod_atmos_admin::atmos_phy_tb_type, and mod_atmos_admin::atmos_sw_phy_tb.

Referenced by mod_atmos_driver::atmos_driver_finalize().

Here is the call graph for this function:

Here is the caller graph for this function:

atmos_phy_tb_driver_calc_tendency()

subroutine, public mod_atmos_phy_tb_driver::atmos_phy_tb_driver_calc_tendency

(

logical, intent(in)

update_flag

)

calclate tendency

Definition at line 203 of file mod_atmos_phy_tb_driver.F90.

    use scale_prc_cartesc, only: &
       prc_has_w, &
       prc_has_e, &
       prc_has_s, &
       prc_has_n
    use scale_statistics, only: &
       statistics_checktotal, &
       statistics_total
    use scale_atmos_grid_cartesc, only: &
       fdz  => atmos_grid_cartesc_fdz, &
       rcdz => atmos_grid_cartesc_rcdz, &
       rfdz => atmos_grid_cartesc_rfdz, &
       cdx  => atmos_grid_cartesc_cdx, &
       fdx  => atmos_grid_cartesc_fdx, &
       cdy  => atmos_grid_cartesc_cdy, &
       fdy  => atmos_grid_cartesc_fdy
    use scale_atmos_grid_cartesc_real, only: &
       fz  => atmos_grid_cartesc_real_fz, &
       atmos_grid_cartesc_real_vol,       &
       atmos_grid_cartesc_real_totvol,    &
       atmos_grid_cartesc_real_volwxy,    &
       atmos_grid_cartesc_real_totvolwxy, &
       atmos_grid_cartesc_real_volzuy,    &
       atmos_grid_cartesc_real_totvolzuy, &
       atmos_grid_cartesc_real_volzxv,    &
       atmos_grid_cartesc_real_totvolzxv
    use scale_atmos_grid_cartesc_metric, only: &
       gsqrt => atmos_grid_cartesc_metric_gsqrt, &
       j13g  => atmos_grid_cartesc_metric_j13g,  &
       j23g  => atmos_grid_cartesc_metric_j23g,  &
       j33g  => atmos_grid_cartesc_metric_j33g,  &
       mapf  => atmos_grid_cartesc_metric_mapf
    use scale_file_history, only: &
       file_history_in
    use scale_monitor, only: &
       monitor_put
    use scale_time, only: &
       dt_tb => time_dtsec_atmos_phy_tb
    use scale_atmos_phy_tb_smg, only: &
       atmos_phy_tb_smg
    use scale_atmos_phy_tb_d1980, only: &
       atmos_phy_tb_d1980
    use scale_atmos_phy_tb_dns, only: &
       atmos_phy_tb_dns
    use scale_atmos_phy_tb_common, only: &
       calc_tend_momz => atmos_phy_tb_calc_tend_momz, &
       calc_tend_momx => atmos_phy_tb_calc_tend_momx, &
       calc_tend_momy => atmos_phy_tb_calc_tend_momy, &
       calc_tend_phi  => atmos_phy_tb_calc_tend_phi
    use mod_atmos_admin, only: &
       atmos_phy_tb_type
    use mod_atmos_vars, only: &
       atmos_vars_get_diagnostic, &
       dens => dens_av,   &
       momz => momz_av,   &
       momx => momx_av,   &
       momy => momy_av,   &
       rhot => rhot_av,   &
       pott,              &
       qtrc => qtrc_av,   &
       momz_t => momz_tp, &
       momx_t => momx_tp, &
       momy_t => momy_tp, &
       rhot_t => rhot_tp, &
       rhoq_t => rhoq_tp
    use mod_atmos_phy_tb_vars, only: &
       i_tke, &
       momz_t_tb => atmos_phy_tb_momz_t, &
       momx_t_tb => atmos_phy_tb_momx_t, &
       momy_t_tb => atmos_phy_tb_momy_t, &
       rhot_t_tb => atmos_phy_tb_rhot_t, &
       rhoq_t_tb => atmos_phy_tb_rhoq_t
    use mod_atmos_phy_sf_vars, only: &
       sflx_mw => atmos_phy_sf_sflx_mw, &
       sflx_mu => atmos_phy_sf_sflx_mu, &
       sflx_mv => atmos_phy_sf_sflx_mv, &
       sflx_sh => atmos_phy_sf_sflx_sh, &
       sflx_q  => atmos_phy_sf_sflx_qtrc
    implicit none

    logical, intent(in) :: update_flag

    ! eddy viscosity/diffusion flux
    real(RP) :: QFLX_MOMZ(KA,IA,JA,3)
    real(RP) :: QFLX_MOMX(KA,IA,JA,3)
    real(RP) :: QFLX_MOMY(KA,IA,JA,3)
    real(RP) :: QFLX_RHOT(KA,IA,JA,3)
    real(RP) :: QFLX_RHOQ(KA,IA,JA,3,QA)

    real(RP) :: Nu(KA,IA,JA) ! eddy viscosity
    real(RP) :: Ri(KA,IA,JA) ! Richardson number
    real(RP) :: Pr(KA,IA,JA) ! Prandtl number

    real(RP) :: N2(KA,IA,JA)

    real(RP) :: tend(KA,IA,JA)

    ! for monitor
    real(RP) :: qflx_x(KA,JA)
    real(RP) :: qflx_y(KA,IA)

    integer  :: JJS, JJE
    integer  :: IIS, IIE

    integer  :: k, i, j, iq
    !---------------------------------------------------------------------------

    !$acc data create(QFLX_RHOQ)


    if ( update_flag ) then

       !$acc data copyin(GSQRT, J13G, J23G, MAPF) &
       !$acc      create(QFLX_MOMZ, QFLX_MOMX, QFLX_MOMY, QFLX_RHOT, &
       !$acc             Nu, Ri, Pr, N2, tend)

       call atmos_vars_get_diagnostic( "N2", n2 )

       select case( atmos_phy_tb_type )
       case( 'SMAGORINSKY' )
          call atmos_phy_tb_smg( qflx_momz, qflx_momx, qflx_momy,         & ! [OUT]
                                 qflx_rhot, qflx_rhoq,                    & ! [OUT]
                                 momz_t_tb, momx_t_tb, momy_t_tb,         & ! [OUT]
                                 rhot_t_tb, rhoq_t_tb,                    & ! [OUT]
                                 nu, ri, pr,                              & ! [OUT]
                                 momz, momx, momy, pott, dens, qtrc, n2,  & ! [IN]
                                 fz, fdz, rcdz, rfdz, cdx, fdx, cdy, fdy, & ! [IN]
                                 gsqrt, j13g, j23g, j33g, mapf,           & ! [IN]
                                 dt_tb                                    ) ! [IN]
       case( 'D1980' )
          !$acc kernels
          momz_t_tb(:,:,:)   = 0.0_rp
          momx_t_tb(:,:,:)   = 0.0_rp
          momy_t_tb(:,:,:)   = 0.0_rp
          rhot_t_tb(:,:,:)   = 0.0_rp
          !$acc end kernels
          !$acc update host(MOMZ,MOMX,MOMY,RHOT,DENS,QTRC,N2,SFLX_MW,SFLX_MU,SFLX_MV,SFLX_SH,SFLX_Q)
          call atmos_phy_tb_d1980( qflx_momz, qflx_momx, qflx_momy,        & ! [OUT]
                                   qflx_rhot, qflx_rhoq,                   & ! [OUT]
                                   rhoq_t_tb,                              & ! [OUT]
                                   nu, ri, pr,                             & ! [OUT]
                                   momz, momx, momy, rhot, dens, qtrc, n2, & ! [IN]
                                   sflx_mw, sflx_mu, sflx_mv,              & ! [IN]
                                   sflx_sh, sflx_q,                        & ! [IN]
                                   gsqrt, j13g, j23g, j33g, mapf,          & ! [IN]
                                   dt_tb                                   ) ! [IN]
          !$acc update device(QFLX_MOMZ,QFLX_MOMX,QFLX_MOMY,QFLX_RHOT,QFLX_RHOQ,RHOQ_t_TB,Nu,Ri,Pr)
       case( 'DNS' )
          !$acc kernels
          momz_t_tb(:,:,:)   = 0.0_rp
          momx_t_tb(:,:,:)   = 0.0_rp
          momy_t_tb(:,:,:)   = 0.0_rp
          rhot_t_tb(:,:,:)   = 0.0_rp
          !$acc end kernels
          !$acc update host(MOMZ,MOMX,MOMY,RHOT,DENS,QTRC,N2,SFLX_MW,SFLX_MU,SFLX_MV,SFLX_SH,SFLX_Q)
          call atmos_phy_tb_dns( qflx_momz, qflx_momx, qflx_momy,        & ! [OUT]
                                 qflx_rhot, qflx_rhoq,                   & ! [OUT]
                                 rhoq_t_tb,                              & ! [OUT]
                                 nu, ri, pr,                             & ! [OUT]
                                 momz, momx, momy, rhot, dens, qtrc, n2, & ! [IN]
                                 sflx_mw, sflx_mu, sflx_mv,              & ! [IN]
                                 sflx_sh, sflx_q,                        & ! [IN]
                                 gsqrt, j13g, j23g, j33g, mapf,          & ! [IN]
                                 dt_tb                                   ) ! [IN]
          !$acc update device(QFLX_MOMZ,QFLX_MOMX,QFLX_MOMY,QFLX_RHOT,QFLX_RHOQ,RHOQ_t_TB,Nu,Ri,Pr)
       end select


       do jjs = js, je, jblock
       jje = jjs+jblock-1
       do iis = is, ie, iblock
       iie = iis+iblock-1

          call calc_tend_momz( tend(:,:,:), & ! (out)
                               qflx_momz,   & ! (in)
                               gsqrt, j13g, j23g, j33g, mapf, & ! (in)
                               iis, iie, jjs, jje ) ! (in)
          !$omp parallel do
          !$acc kernels
          do j = jjs, jje
          do i = iis, iie
          do k = ks, ke-1
             momz_t_tb(k,i,j) = momz_t_tb(k,i,j) + tend(k,i,j)
          end do
          end do
          end do
          !$acc end kernels

          call calc_tend_momx( tend(:,:,:), & ! (out)
                               qflx_momx,   & ! (in)
                               gsqrt, j13g, j23g, j33g, mapf, & ! (in)
                               iis, iie, jjs, jje ) ! (in)
          !$omp parallel do
          !$acc kernels
          do j = jjs, jje
          do i = iis, iie
          do k = ks, ke
             momx_t_tb(k,i,j) = momx_t_tb(k,i,j) + tend(k,i,j)
          end do
          end do
          end do
          !$acc end kernels

          call calc_tend_momy( tend(:,:,:), & ! (out)
                               qflx_momy,   & ! (in)
                               gsqrt, j13g, j23g, j33g, mapf, & ! (in)
                               iis, iie, jjs, jje ) ! (in)
          !$omp parallel do
          !$acc kernels
          do j = jjs, jje
          do i = iis, iie
          do k = ks, ke
             momy_t_tb(k,i,j) = momy_t_tb(k,i,j) + tend(k,i,j)
          end do
          end do
          end do
          !$acc end kernels

          call calc_tend_phi ( tend(:,:,:), & ! (out)
                               qflx_rhot,   & ! (in)
                               gsqrt, j13g, j23g, j33g, mapf, & ! (in)
                               iis, iie, jjs, jje ) ! (in)
          !$omp parallel do
          !$acc kernels
          do j = jjs, jje
          do i = iis, iie
          do k = ks, ke
             rhot_t_tb(k,i,j) = rhot_t_tb(k,i,j) + tend(k,i,j)
          end do
          end do
          end do
          !$acc end kernels

          do iq = 1, qa
             if ( iq == i_tke .or. .not. tracer_advc(iq) ) cycle

             call calc_tend_phi( tend(:,:,:),                   & ! (out)
                                 qflx_rhoq(:,:,:,:,iq),         & ! (in)
                                 gsqrt, j13g, j23g, j33g, mapf, & ! (in)
                                 iis, iie, jjs, jje ) ! (in)

             !$omp parallel do
             !$acc kernels
             do j = jjs, jje
             do i = iis, iie
             do k = ks, ke
                rhoq_t_tb(k,i,j,iq) = rhoq_t_tb(k,i,j,iq) + tend(k,i,j)
             end do
             end do
             end do
             !$acc end kernels

          end do

       end do
       end do


       call file_history_in( nu(:,:,:), 'NU',  'eddy viscosity',           'm2/s' , fill_halo=.true. )
       call file_history_in( ri(:,:,:), 'Ri',  'Richardson number',        'NIL'  , fill_halo=.true. )
       call file_history_in( pr(:,:,:), 'Pr',  'Prantle number',           'NIL'  , fill_halo=.true. )

       call file_history_in( momz_t_tb(:,:,:), 'MOMZ_t_TB', 'MOMZ tendency (TB)', 'kg/m2/s2',  fill_halo=.true. )
       call file_history_in( momx_t_tb(:,:,:), 'MOMX_t_TB', 'MOMX tendency (TB)', 'kg/m2/s2',  fill_halo=.true. )
       call file_history_in( momy_t_tb(:,:,:), 'MOMY_t_TB', 'MOMY tendency (TB)', 'kg/m2/s2',  fill_halo=.true. )
       call file_history_in( rhot_t_tb(:,:,:), 'RHOT_t_TB', 'RHOT tendency (TB)', 'K.kg/m3/s', fill_halo=.true. )

       do iq = 1, qa
          call file_history_in( rhoq_t_tb(:,:,:,iq), trim(tracer_name(iq))//'_t_TB',                      &
                        'tendency rho*'//trim(tracer_name(iq))//' in TB', 'kg/m3/s', fill_halo=.true. )
       enddo

       call file_history_in( qflx_momz(:,:,:,zdir), 'SGS_ZFLX_MOMZ', 'SGS Z FLUX of MOMZ', 'kg/m/s2', &
                     fill_halo=.true.)
       call file_history_in( qflx_momz(:,:,:,xdir), 'SGS_XFLX_MOMZ', 'SGS X FLUX of MOMZ', 'kg/m/s2', &
                     dim_type='ZHXHY', fill_halo=.true.)
       call file_history_in( qflx_momz(:,:,:,ydir), 'SGS_YFLX_MOMZ', 'SGS Y FLUX of MOMZ', 'kg/m/s2', &
                     dim_type='ZHXYH', fill_halo=.true.)

       call file_history_in( qflx_momx(:,:,:,zdir), 'SGS_ZFLX_MOMX', 'SGS Z FLUX of MOMX', 'kg/m/s2', &
                     dim_type='ZHXHY', fill_halo=.true.)
       call file_history_in( qflx_momx(:,:,:,xdir), 'SGS_XFLX_MOMX', 'SGS X FLUX of MOMX', 'kg/m/s2', &
                     fill_halo=.true.)
       call file_history_in( qflx_momx(:,:,:,ydir), 'SGS_YFLX_MOMX', 'SGS Y FLUX of MOMX', 'kg/m/s2', &
                     dim_type='ZXHYH', fill_halo=.true.)

       call file_history_in( qflx_momy(:,:,:,zdir), 'SGS_ZFLX_MOMY', 'SGS Z FLUX of MOMY', 'kg/m/s2', &
                     dim_type='ZHXYH', fill_halo=.true.)
       call file_history_in( qflx_momy(:,:,:,xdir), 'SGS_XFLX_MOMY', 'SGS X FLUX of MOMY', 'kg/m/s2', &
                     dim_type='ZXHYH', fill_halo=.true.)
       call file_history_in( qflx_momy(:,:,:,ydir), 'SGS_YFLX_MOMY', 'SGS Y FLUX of MOMY', 'kg/m/s2', &
                     fill_halo=.true.)

       call file_history_in( qflx_rhot(:,:,:,zdir), 'SGS_ZFLX_RHOT', 'SGS Z FLUX of RHOT', 'K*kg/m2/s', &
                     dim_type='ZHXY', fill_halo=.true.)
       call file_history_in( qflx_rhot(:,:,:,xdir), 'SGS_XFLX_RHOT', 'SGS X FLUX of RHOT', 'K*kg/m2/s', &
                     dim_type='ZXHY', fill_halo=.true.)
       call file_history_in( qflx_rhot(:,:,:,ydir), 'SGS_YFLX_RHOT', 'SGS Y FLUX of RHOT', 'K*kg/m2/s', &
                     dim_type='ZXYH', fill_halo=.true.)


       do iq = 1, qa
          if ( iq == i_tke .or. .not. tracer_advc(iq) ) cycle

          call file_history_in( qflx_rhoq(:,:,:,zdir,iq), &
               'SGS_ZFLX_'//trim(tracer_name(iq)), 'SGS Z FLUX of '//trim(tracer_name(iq)), 'kg/m2/s', &
               dim_type='ZHXY', fill_halo=.true.)
          call file_history_in( qflx_rhoq(:,:,:,xdir,iq), &
               'SGS_XFLX_'//trim(tracer_name(iq)), 'SGS X FLUX of '//trim(tracer_name(iq)), 'kg/m2/s', &
               dim_type='ZXHY', fill_halo=.true.)
          call file_history_in( qflx_rhoq(:,:,:,ydir,iq), &
               'SGS_YFLX_'//trim(tracer_name(iq)), 'SGS Y FLUX of '//trim(tracer_name(iq)), 'kg/m2/s', &
               dim_type='ZXYH', fill_halo=.true.)
       end do

       if ( statistics_checktotal ) then
          !$acc data copyin(ATMOS_GRID_CARTESC_REAL_VOLWXY, ATMOS_GRID_CARTESC_REAL_VOLZUY, ATMOS_GRID_CARTESC_REAL_VOLZXV, ATMOS_GRID_CARTESC_REAL_VOL)
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 momz_t_tb(:,:,:), 'MOMZ_t_TB',         &
                                 atmos_grid_cartesc_real_volwxy(:,:,:), &
                                 atmos_grid_cartesc_real_totvolwxy      )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 momx_t_tb(:,:,:), 'MOMX_t_TB',         &
                                 atmos_grid_cartesc_real_volzuy(:,:,:), &
                                 atmos_grid_cartesc_real_totvolzuy      )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 momy_t_tb(:,:,:), 'MOMY_t_TB',         &
                                 atmos_grid_cartesc_real_volzxv(:,:,:), &
                                 atmos_grid_cartesc_real_totvolzxv      )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 rhot_t_tb(:,:,:), 'RHOT_t_TB',       &
                                 atmos_grid_cartesc_real_vol(:,:,:),  &
                                 atmos_grid_cartesc_real_totvol       )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 nu(:,:,:),        'Nu',              &
                                 atmos_grid_cartesc_real_vol(:,:,:),  &
                                 atmos_grid_cartesc_real_totvol       )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 ri(:,:,:),        'Ri',              &
                                 atmos_grid_cartesc_real_vol(:,:,:),  &
                                 atmos_grid_cartesc_real_totvol       )
          call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                 pr(:,:,:),        'Pr',              &
                                 atmos_grid_cartesc_real_vol(:,:,:),  &
                                 atmos_grid_cartesc_real_totvol       )

          do iq = 1, qa
             call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                    rhoq_t_tb(:,:,:,iq), trim(tracer_name(iq))//'_t_TB', &
                                    atmos_grid_cartesc_real_vol(:,:,:),                  &
                                    atmos_grid_cartesc_real_totvol                       )
          enddo
          !$acc end data
       endif

       !$acc end data

    endif

    !$omp parallel do default(none) private(i,j,k) OMP_SCHEDULE_ collapse(2) &
    !$omp shared(JS,JE,IS,IE,KS,KE,MOMZ_t,MOMZ_t_TB,MOMX_t,MOMX_t_TB,MOMY_t,MOMY_t_TB,RHOT_t,RHOT_t_TB)
    !$acc kernels
    do j = js, je
    do i = is, ie
    do k = ks, ke
       momz_t(k,i,j) = momz_t(k,i,j) + momz_t_tb(k,i,j)
       momx_t(k,i,j) = momx_t(k,i,j) + momx_t_tb(k,i,j)
       momy_t(k,i,j) = momy_t(k,i,j) + momy_t_tb(k,i,j)
       rhot_t(k,i,j) = rhot_t(k,i,j) + rhot_t_tb(k,i,j)
    enddo
    enddo
    enddo
    !$acc end kernels

    do iq = 1, qa

       if ( .not. ( iq == i_tke .or. tracer_advc(iq) ) ) cycle

       !$omp parallel do private(i,j,k) OMP_SCHEDULE_ collapse(2)
!       !$acc kernels async(iq)
       !$acc kernels
       do j  = js, je
       do i  = is, ie
       do k  = ks, ke
          rhoq_t(k,i,j,iq) = rhoq_t(k,i,j,iq) + rhoq_t_tb(k,i,j,iq)
       enddo
       enddo
       enddo
       !$acc end kernels

    enddo

    !$acc data create(qflx_x, qflx_y)

    if ( monit_west > 0 ) then
       !$acc kernels
       qflx_x(:,:) = 0.0_rp
       !$acc end kernels
       if ( .not. prc_has_w ) then
          do iq = 1, qa
             if ( tracer_advc(iq) .and. tracer_mass(iq) == 1.0_rp ) then
                !$acc kernels
                do j = js, je
                do k = ks, ke
                   qflx_x(k,j) = qflx_x(k,j) + qflx_rhoq(k,is-1,j,xdir,iq)
                end do
                end do
                !$acc end kernels
             end if
          end do
       end if
!$acc update host(qflx_x)
       call monitor_put( monit_west, qflx_x(:,:) )
    end if
    if ( monit_east > 0 ) then
       !$acc kernels
       qflx_x(:,:) = 0.0_rp
       !$acc end kernels
       if ( .not. prc_has_e ) then
          do iq = 1, qa
             if ( tracer_advc(iq) .and. tracer_mass(iq) == 1.0_rp ) then
                !$acc kernels
                do j = js, je
                do k = ks, ke
                   qflx_x(k,j) = qflx_x(k,j) + qflx_rhoq(k,ie,j,xdir,iq)
                end do
                end do
                !$acc end kernels
             end if
          end do
       end if
!$acc update host(qflx_x)
       call monitor_put( monit_east, qflx_x(:,:) )
    end if
    if ( monit_south > 0 ) then
       !$acc kernels
       qflx_y(:,:) = 0.0_rp
       !$acc end kernels
       if ( .not. prc_has_s ) then
          do iq = 1, qa
             if ( tracer_advc(iq) .and. tracer_mass(iq) == 1.0_rp ) then
                !$acc kernels
                do i = is, ie
                do k = ks, ke
                   qflx_y(k,i) = qflx_y(k,i) + qflx_rhoq(k,i,js-1,ydir,iq)
                end do
                end do
                !$acc end kernels
             end if
          end do
       end if
!$acc update host(qflx_y)
       call monitor_put( monit_south, qflx_y(:,:) )
    end if
    if ( monit_north > 0 ) then
       !$acc kernels
       qflx_y(:,:) = 0.0_rp
       !$acc end kernels
       if ( .not. prc_has_n ) then
          do iq = 1, qa
             if ( tracer_advc(iq) .and. tracer_mass(iq) == 1.0_rp ) then
                !$acc kernels
                do i = is, ie
                do k = ks, ke
                   qflx_y(k,i) = qflx_y(k,i) + qflx_rhoq(k,i,je,ydir,iq)
                end do
                end do
                !$acc end kernels
             end if
          end do
       end if
!$acc update host(qflx_y)
       call monitor_put( monit_north, qflx_y(:,:) )
    end if

!    !$acc wait

    !$acc end data
    !$acc end data

    return

References scale_atmos_grid_cartesc::atmos_grid_cartesc_cdx, scale_atmos_grid_cartesc::atmos_grid_cartesc_cdy, scale_atmos_grid_cartesc::atmos_grid_cartesc_fdx, scale_atmos_grid_cartesc::atmos_grid_cartesc_fdy, scale_atmos_grid_cartesc::atmos_grid_cartesc_fdz, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_gsqrt, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_j13g, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_j23g, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_j33g, scale_atmos_grid_cartesc_metric::atmos_grid_cartesc_metric_mapf, scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdz, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_fz, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_totvol, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_totvolwxy, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_totvolzuy, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_totvolzxv, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_vol, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_volwxy, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_volzuy, scale_atmos_grid_cartesc_real::atmos_grid_cartesc_real_volzxv, scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdz, mod_atmos_phy_sf_vars::atmos_phy_sf_sflx_mu, mod_atmos_phy_sf_vars::atmos_phy_sf_sflx_mv, mod_atmos_phy_sf_vars::atmos_phy_sf_sflx_mw, mod_atmos_phy_sf_vars::atmos_phy_sf_sflx_qtrc, mod_atmos_phy_sf_vars::atmos_phy_sf_sflx_sh, scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momx(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momy(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momz(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_phi(), scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980(), scale_atmos_phy_tb_dns::atmos_phy_tb_dns(), mod_atmos_phy_tb_vars::atmos_phy_tb_momx_t, mod_atmos_phy_tb_vars::atmos_phy_tb_momy_t, mod_atmos_phy_tb_vars::atmos_phy_tb_momz_t, mod_atmos_phy_tb_vars::atmos_phy_tb_rhoq_t, mod_atmos_phy_tb_vars::atmos_phy_tb_rhot_t, scale_atmos_phy_tb_smg::atmos_phy_tb_smg(), mod_atmos_admin::atmos_phy_tb_type, mod_atmos_vars::dens, mod_atmos_vars::dens_av, mod_atmos_phy_tb_vars::i_tke, scale_atmos_grid_cartesc_index::ia, scale_atmos_grid_cartesc_index::iblock, scale_atmos_grid_cartesc_index::ie, scale_atmos_grid_cartesc_index::is, scale_atmos_grid_cartesc_index::ja, scale_atmos_grid_cartesc_index::jblock, scale_atmos_grid_cartesc_index::je, scale_atmos_grid_cartesc_index::js, scale_tracer::k, scale_atmos_grid_cartesc_index::ka, scale_atmos_grid_cartesc_index::ke, scale_atmos_grid_cartesc_index::ks, mod_atmos_vars::momx, mod_atmos_vars::momx_av, mod_atmos_vars::momx_tp, mod_atmos_vars::momy, mod_atmos_vars::momy_av, mod_atmos_vars::momy_tp, mod_atmos_vars::momz, mod_atmos_vars::momz_av, mod_atmos_vars::momz_tp, mod_atmos_vars::pott, scale_prc_cartesc::prc_has_e, scale_prc_cartesc::prc_has_n, scale_prc_cartesc::prc_has_s, scale_prc_cartesc::prc_has_w, scale_tracer::qa, mod_atmos_vars::qtrc, mod_atmos_vars::qtrc_av, mod_atmos_vars::rhoq_tp, mod_atmos_vars::rhot, mod_atmos_vars::rhot_av, mod_atmos_vars::rhot_tp, scale_statistics::statistics_checktotal, scale_time::time_dtsec_atmos_phy_tb, scale_tracer::tracer_advc, scale_tracer::tracer_mass, scale_tracer::tracer_name, scale_atmos_grid_cartesc_index::xdir, scale_atmos_grid_cartesc_index::ydir, and scale_atmos_grid_cartesc_index::zdir.

Referenced by mod_atmos_driver::atmos_driver_calc_tendency().

Here is the call graph for this function:

Here is the caller graph for this function:
