module atmosphere / physics / PBL More...

Functions/Subroutines
subroutine, public	atmos_phy_bl_driver_tracer_setup
	Config. More...

subroutine, public	atmos_phy_bl_driver_setup
	Setup. More...

subroutine, public	atmos_phy_bl_driver_finalize
	Finalize. More...

subroutine, public	atmos_phy_bl_driver_mkinit (TKE_CONST)
	make initial state More...

subroutine, public	atmos_phy_bl_driver_calc_tendency (update_flag)
	calculate tendency More...

Detailed Description

module atmosphere / physics / PBL

Description: Planetary boundary layer turbulence

Author: Team SCALE

NAMELIST

No namelist group

History Output

name	description	unit	variable
Kh_BL	eddy diffusion	m2/s	Kh
Nu_BL	eddy viscosity	m2/s	Nu
QL_BL	liquid water content in partial condensation	kg/kg	QL
RHOT_t_BL	RHOT tendency (BL)	K.kg/m3/s	RHOT_t_BL
RHOU_t_BL	MOMX tendency (BL)	kg/m2/s2	RHOU_t_BL
RHOV_t_BL	MOMY tendency (BL)	kg/m2/s2	RHOV_t_BL
Zi_BL	depth of the boundary layer	m	Zi
cldfrac_BL	cloud fraction in partial condensation	1	cldfrac
{TRACER_NAME}_t_BL	RHO*{TRACER_NAME} tendency (BL); {TRACER_NAME} depends on the physics schemes, e.g., QV, QC, QR.	kg/m3/s	RHOQ_t_BL

Function/Subroutine Documentation

◆ atmos_phy_bl_driver_tracer_setup()

subroutine, public mod_atmos_phy_bl_driver::atmos_phy_bl_driver_tracer_setup

Config.

Definition at line 51 of file mod_atmos_phy_bl_driver.F90.

     use scale_prc, only: &
        prc_abort
     use scale_tracer, only: &
        tracer_regist
     use scale_atmos_phy_bl_mynn, only: &
        atmos_phy_bl_mynn_tracer_setup, &
        atmos_phy_bl_mynn_ntracer, &
        atmos_phy_bl_mynn_name, &
        atmos_phy_bl_mynn_desc, &
        atmos_phy_bl_mynn_units
     use scale_atmos_phy_bl_mynn_jmapplib, only: &
        atmos_phy_bl_mynn_jmapplib_ntracer, &
        atmos_phy_bl_mynn_jmapplib_name, &
        atmos_phy_bl_mynn_jmapplib_desc, &
        atmos_phy_bl_mynn_jmapplib_units
     use mod_atmos_admin, only: &
        atmos_phy_bl_type, &
        atmos_sw_phy_bl
     use mod_atmos_phy_bl_vars, only: &
        qs, qe
     implicit none
     !---------------------------------------------------------------------------

     log_newline
     log_info("ATMOS_PHY_BL_driver_tracer_setup",*) 'Setup'

     if ( atmos_sw_phy_bl ) then
        select case ( atmos_phy_bl_type )
        case ( 'MYNN' )
           call atmos_phy_bl_mynn_tracer_setup
           call tracer_regist( &
                qs, &
                atmos_phy_bl_mynn_ntracer, &
                atmos_phy_bl_mynn_name,    &
                atmos_phy_bl_mynn_desc,    &
                atmos_phy_bl_mynn_units    )
           qe = qs + atmos_phy_bl_mynn_ntracer - 1
        case ( 'MYNN-JMAPPLIB' )
           call tracer_regist( &
                qs, &
                atmos_phy_bl_mynn_jmapplib_ntracer, &
                atmos_phy_bl_mynn_jmapplib_name,    &
                atmos_phy_bl_mynn_jmapplib_desc,    &
                atmos_phy_bl_mynn_jmapplib_units    )
           qe = qs + atmos_phy_bl_mynn_jmapplib_ntracer - 1
        case default
           log_error("ATMOS_PHY_BL_driver_tracer_setup",*) 'ATMOS_PHY_BL_TYPE is invalid: ', trim(atmos_phy_bl_type)
           call prc_abort
        end select
     end if

     return

Referenced by mod_atmos_driver::atmos_driver_tracer_setup().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ atmos_phy_bl_driver_setup()

subroutine, public mod_atmos_phy_bl_driver::atmos_phy_bl_driver_setup

Setup.

Definition at line 108 of file mod_atmos_phy_bl_driver.F90.

     use scale_atmos_phy_bl_mynn, only: &
        atmos_phy_bl_mynn_setup
     use scale_atmos_phy_bl_mynn_jmapplib, only: &
        atmos_phy_bl_mynn_jmapplib_setup
     use scale_atmos_grid_cartesc, only: &
        cz => atmos_grid_cartesc_cz, &
        dx
     use mod_atmos_admin, only: &
        atmos_phy_bl_type, &
        atmos_sw_phy_bl
     use mod_atmos_phy_bl_vars, only: &
        atmos_phy_bl_zi, &
        atmos_phy_bl_sflx_buoy
     use scale_bulkflux, only: &
        bulkflux_type
     use scale_time, only: &
        dt_bl => time_dtsec_atmos_phy_bl
     implicit none
     !---------------------------------------------------------------------------

     log_newline
     log_info("ATMOS_PHY_BL_driver_setup",*) 'Setup'

     if ( atmos_sw_phy_bl ) then
        select case ( atmos_phy_bl_type )
        case ( 'MYNN' )
           call atmos_phy_bl_mynn_setup( &
                bulkflux_type, & ! (in)
                dx = dx        ) ! (in)
        case ( 'MYNN-JMAPPLIB' )
           call atmos_phy_bl_mynn_jmapplib_setup( &
                ka, ks, ke, &
                cz(:), &
                dt_bl )
        end select
     else
        log_info("ATMOS_PHY_BL_driver_setup",*) 'this component is never called.'
        !$acc kernels
        atmos_phy_bl_zi(:,:) = 0.0_rp
        atmos_phy_bl_sflx_buoy(:,:) = 0.0_rp
        !$acc end kernels
     endif

     return

References scale_atmos_grid_cartesc::atmos_grid_cartesc_cz, scale_atmos_phy_bl_mynn_jmapplib::atmos_phy_bl_mynn_jmapplib_setup(), scale_atmos_phy_bl_mynn::atmos_phy_bl_mynn_setup(), mod_atmos_phy_bl_vars::atmos_phy_bl_sflx_buoy, mod_atmos_admin::atmos_phy_bl_type, mod_atmos_phy_bl_vars::atmos_phy_bl_zi, mod_atmos_admin::atmos_sw_phy_bl, scale_bulkflux::bulkflux_type, scale_atmos_grid_cartesc::dx, scale_atmos_grid_cartesc_index::ka, scale_atmos_grid_cartesc_index::ke, scale_atmos_grid_cartesc_index::ks, and scale_time::time_dtsec_atmos_phy_bl.

Referenced by mod_atmos_driver::atmos_driver_setup().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ atmos_phy_bl_driver_finalize()

subroutine, public mod_atmos_phy_bl_driver::atmos_phy_bl_driver_finalize

Finalize.

Definition at line 157 of file mod_atmos_phy_bl_driver.F90.

     use scale_prc, only: &
        prc_abort
     use scale_atmos_phy_bl_mynn, only: &
        atmos_phy_bl_mynn_finalize
     use scale_atmos_phy_bl_mynn_jmapplib, only: &
        atmos_phy_bl_mynn_jmapplib_finalize
     use mod_atmos_admin, only: &
        atmos_phy_bl_type, &
        atmos_sw_phy_bl
     implicit none
     !---------------------------------------------------------------------------

     log_newline
     log_info("ATMOS_PHY_BL_driver_finalize",*) 'Finalize'

     if ( atmos_sw_phy_bl ) then
        select case ( atmos_phy_bl_type )
        case ( 'MYNN' )
           call atmos_phy_bl_mynn_finalize
        case ( 'MYNN-JMAPPLIB' )
           call atmos_phy_bl_mynn_jmapplib_finalize
        case default
           log_error("ATMOS_PHY_BL_driver_finalize",*) 'ATMOS_PHY_BL_TYPE is invalid: ', trim(atmos_phy_bl_type)
           call prc_abort
        end select
     end if

     return

References scale_atmos_phy_bl_mynn::atmos_phy_bl_mynn_finalize(), scale_atmos_phy_bl_mynn_jmapplib::atmos_phy_bl_mynn_jmapplib_finalize(), mod_atmos_admin::atmos_phy_bl_type, mod_atmos_admin::atmos_sw_phy_bl, and scale_prc::prc_abort().

Referenced by mod_atmos_driver::atmos_driver_finalize().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ atmos_phy_bl_driver_mkinit()

subroutine, public mod_atmos_phy_bl_driver::atmos_phy_bl_driver_mkinit ( real(rp), intent(in) TKE_CONST )

make initial state

Definition at line 190 of file mod_atmos_phy_bl_driver.F90.

     use scale_const, only: &
        undef => const_undef
     use scale_time, only: &
        dt_bl => time_dtsec_atmos_phy_bl
     use scale_atmos_phy_bl_mynn, only: &
        atmos_phy_bl_mynn_mkinit
     use scale_atmos_grid_cartesc_real, only: &
        z1 => atmos_grid_cartesc_real_z1, &
        cz => atmos_grid_cartesc_real_cz, &
        fz => atmos_grid_cartesc_real_fz, &
        f2h => atmos_grid_cartesc_real_f2h
     use scale_bulkflux, only: &
        bulkflux_type
     use scale_landuse, only: &
        frac_land => landuse_frac_land
     use scale_topography, only: &
        tansl_x => topography_tansl_x, &
        tansl_y => topography_tansl_y
     use scale_atmos_bottom, only: &
        bottom_estimate => atmos_bottom_estimate
     use scale_atmos_phy_sf_bulk, only: &
        atmos_phy_sf_bulk_flux
     use scale_comm_cartesc, only: &
        comm_vars8, &
        comm_wait
     use mod_atmos_phy_bl_vars, only: &
        qs, qe, &
        zi => atmos_phy_bl_zi
     use mod_atmos_phy_sf_vars, only: &
        sfc_temp => atmos_phy_sf_sfc_temp,  &
        sfc_dens => atmos_phy_sf_sfc_dens,  &
        sfc_pres => atmos_phy_sf_sfc_pres,  &
        sfc_z0m   => atmos_phy_sf_sfc_z0m,   &
        sfc_z0h   => atmos_phy_sf_sfc_z0h,   &
        sfc_z0e   => atmos_phy_sf_sfc_z0e,   &
        sflx_mu  => atmos_phy_sf_sflx_mu,   &
        sflx_mv  => atmos_phy_sf_sflx_mv,   &
        sflx_mw  => atmos_phy_sf_sflx_mv,   &
        sflx_sh  => atmos_phy_sf_sflx_sh,   &
        sflx_lh  => atmos_phy_sf_sflx_lh,   &
        sflx_qv  => atmos_phy_sf_sflx_qv,   &
        ustar    => atmos_phy_sf_ustar,     &
        tstar    => atmos_phy_sf_tstar,     &
        qstar    => atmos_phy_sf_qstar,     &
        wstar    => atmos_phy_sf_wstar,     &
        rlmo     => atmos_phy_sf_rlmo,      &
        u10       => atmos_phy_sf_u10,      &
        v10       => atmos_phy_sf_v10,      &
        t2        => atmos_phy_sf_t2,       &
        q2        => atmos_phy_sf_q2
     use mod_atmos_admin, only: &
        atmos_phy_bl_type, &
        atmos_sw_phy_bl
     use mod_atmos_vars, only: &
        dens,  &
        momz,  &
        momx,  &
        momy,  &
        rhot,  &
        qtrc,  &
        u,     &
        v,     &
        w,     &
        temp,  &
        pott,  &
        pres,  &
        exner, &
        qdry,  &
        qv,    &
        qc,    &
        qi,    &
        atmos_vars_calc_diagnostics, &
        atmos_vars_get_diagnostic
     implicit none
     real(RP), intent(in) :: TKE_CONST

     real(RP) :: N2  (KA,IA,JA)
     real(RP) :: POTL(KA,IA,JA)
     real(RP) :: POTV(KA,IA,JA)

     real(RP) :: ATM_TEMP(IA,JA)
     real(RP) :: ATM_PRES(IA,JA)
     real(RP) :: ATM_U   (IA,JA)
     real(RP) :: ATM_V   (IA,JA)
     real(RP) :: ATM_W   (IA,JA)
     real(RP) :: ATM_QV  (IA,JA)

     real(RP) :: QW(KA,IA,JA)

     integer  :: k, i, j, iq
     !---------------------------------------------------------------------------

     if ( .not. atmos_sw_phy_bl ) return

     select case ( atmos_phy_bl_type )
     case ( 'MYNN' )
        if ( qtrc(ks,is,je,qs) == undef ) then

           !$acc data create(N2,POTL,POTV,ATM_TEMP,ATM_PRES,ATM_U,ATM_V,ATM_W,ATM_QV,QW)

           call comm_vars8(dens, 1)
           call comm_vars8(momz, 2)
           call comm_vars8(momx, 3)
           call comm_vars8(momy, 4)
           call comm_vars8(rhot, 5)
           call comm_vars8(qv, 6)
           call comm_vars8(qc, 7)
           call comm_vars8(qi, 8)
           call comm_wait(dens, 1)
           call comm_wait(momz, 2)
           call comm_wait(momx, 3)
           call comm_wait(momy, 4)
           call comm_wait(rhot, 5)
           call comm_wait(qv, 6)
           call comm_wait(qc, 7)
           call comm_wait(qi, 8)

           call atmos_vars_calc_diagnostics
           call atmos_vars_get_diagnostic( "N2",   n2   )
           call atmos_vars_get_diagnostic( "POTL", potl )
           call atmos_vars_get_diagnostic( "POTV", potv )

           call bottom_estimate( ka, ks, ke, ia, isb, ieb, ja, jsb, jeb, &
                                 dens(:,:,:), pres(:,:,:), qv(:,:,:), & ! [IN]
                                 sfc_temp(:,:),                       & ! [IN]
                                 fz(:,:,:),                           & ! [IN]
                                 sfc_dens(:,:), sfc_pres(:,:)         ) ! [OUT]

           !$omp parallel do
           !$acc kernels
           do j = jsb, jeb
           do i = isb, ieb
              atm_temp(i,j) = temp(ks,i,j)
              atm_pres(i,j) = pres(ks,i,j)
              atm_u(i,j) = u(ks,i,j)
              atm_v(i,j) = v(ks,i,j)
              atm_w(i,j) = atm_u(i,j) * tansl_x(i,j) + atm_v(i,j) * tansl_y(i,j)
              atm_qv(i,j) = qv(ks,i,j)
           enddo
           enddo
           !$acc end kernels

           call atmos_phy_sf_bulk_flux( ia, isb, ieb, ja, jsb, jeb, &
                                        atm_w(:,:), atm_u(:,:), atm_v(:,:),          & ! [IN]
                                        atm_temp(:,:), atm_pres(:,:), atm_qv(:,:),   & ! [IN]
                                        sfc_dens(:,:), sfc_temp(:,:), sfc_pres(:,:), & ! [IN]
                                        sfc_z0m(:,:), sfc_z0h(:,:), sfc_z0e(:,:),    & ! [IN]
                                        zi(:,:), z1(:,:),                            & ! [IN]
                                        sflx_mw(:,:), sflx_mu(:,:), sflx_mv(:,:),    & ! [OUT]
                                        sflx_sh(:,:), sflx_lh(:,:), sflx_qv(:,:),    & ! [OUT]
                                        ustar(:,:), tstar(:,:), qstar(:,:),          & ! [OUT]
                                        wstar(:,:),                                  & ! [OUT]
                                        rlmo(:,:),                                   & ! [OUT]
                                        u10(:,:), v10(:,:), t2(:,:), q2(:,:)         ) ! [OUT]

           !$acc kernels
           do j = jsb, jeb
           do i = isb, ieb
           do k = ks, ke
              qw(k,i,j) = qv(k,i,j) + qc(k,i,j) + qi(k,i,j)
           end do
           end do
           end do
           !$acc end kernels

           call atmos_phy_bl_mynn_mkinit( &
                ka, ks, ke, ia, isb, ieb, ja, jsb, jeb, &
                qtrc(:,:,:,qs:qe),                                      & ! (out)
                dens(:,:,:), u(:,:,:), v(:,:,:), w(:,:,:), pott(:,:,:), & ! (in)
                pres(:,:,:), exner(:,:,:), n2(:,:,:),                   & ! (in)
                qdry(:,:,:), qv(:,:,:), qw(:,:,:),                      & ! (in)
                potl(:,:,:), potv(:,:,:),                               & ! (in)
                sfc_dens(:,:),                                          & ! (in)
                sflx_mu(:,:), sflx_mv(:,:), sflx_sh(:,:), sflx_qv(:,:), & ! (in)
                ustar(:,:), tstar(:,:), qstar(:,:), rlmo(:,:),          & ! (in)
                frac_land(:,:),                                         & ! (in)
                cz(:,:,:), fz(:,:,:), f2h(:,:,:,:),                     & ! (in)
                bulkflux_type                                           ) ! (in)

           !$acc end data

        end if

     case ( 'MYNN-JMAPPLIB' )
        !$acc kernels
        !$acc loop independent collapse(3)
        do j = jsb, jeb
        do i = isb, ieb
        do k = ks, ke
           if ( qtrc(k,i,j,qs) == undef ) then
              qtrc(k,i,j,qs) = tke_const
           end if
        end do
        end do
        end do
        !$acc end kernels
        !$acc kernels
        !$acc loop independent collapse(4)
        do iq = qs+1, qe
        do j = jsb, jeb
        do i = isb, ieb
        do k = ks, ke
           if ( qtrc(k,i,j,iq) == undef ) then
              qtrc(k,i,j,iq) = 0.0_rp
           end if
        end do
        end do
        end do
        end do
        !$acc end kernels
     end select

     return

Referenced by mod_mkinit::tke_setup().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ atmos_phy_bl_driver_calc_tendency()

subroutine, public mod_atmos_phy_bl_driver::atmos_phy_bl_driver_calc_tendency ( logical, intent(in) update_flag )

calculate tendency

Definition at line 408 of file mod_atmos_phy_bl_driver.F90.

     use scale_statistics, only: &
        statistics_checktotal, &
        statistics_total
     use scale_file_history, only: &
        file_history_in
     use scale_time, only: &
        dt_bl => time_dtsec_atmos_phy_bl
     use scale_atmos_phy_bl_common, only: &
        atmos_phy_bl_tendency_tracer
     use scale_atmos_phy_bl_mynn, only: &
        atmos_phy_bl_mynn_tendency
     use scale_atmos_phy_bl_mynn_jmapplib, only: &
        atmos_phy_bl_mynn_jmapplib_tendency
     use scale_atmos_grid_cartesc_real, only: &
        cz => atmos_grid_cartesc_real_cz, &
        fz => atmos_grid_cartesc_real_fz, &
        f2h => atmos_grid_cartesc_real_f2h, &
        atmos_grid_cartesc_real_vol, &
        atmos_grid_cartesc_real_totvol
     use scale_atmos_hydrometeor, only: &
        i_qv
     use scale_bulkflux, only: &
        bulkflux_type
     use scale_landuse, only: &
        frac_land => landuse_frac_land
     use mod_atmos_admin, only: &
        atmos_phy_bl_type
     use mod_atmos_vars, only: &
        dens => dens_av, &
        qtrc => qtrc_av, &
        u,     &
        v,     &
        w,     &
        pott,  &
        pres,  &
        exner, &
        qdry,  &
        qv,    &
        qc,    &
        qi,    &
        rhou_t => rhou_tp, &
        rhov_t => rhov_tp, &
        rhot_t => rhot_tp, &
        rhoq_t => rhoq_tp, &
        atmos_vars_get_diagnostic
     use mod_atmos_phy_bl_vars, only: &
        qs, qe, &
        atmos_phy_bl_mix_tracers, &
        rhou_t_bl => atmos_phy_bl_rhou_t,    &
        rhov_t_bl => atmos_phy_bl_rhov_t,    &
        rhot_t_bl => atmos_phy_bl_rhot_t,    &
        rhoq_t_bl => atmos_phy_bl_rhoq_t,    &
        zi        => atmos_phy_bl_zi,        &
        sflx_buoy => atmos_phy_bl_sflx_buoy, &
        ql        => atmos_phy_bl_ql,        &
        cldfrac   => atmos_phy_bl_cldfrac
     use mod_atmos_phy_sf_vars, only: &
        sfc_dens => atmos_phy_sf_sfc_dens,  &
        sfc_pres => atmos_phy_sf_sfc_pres,  &
        sflx_mu  => atmos_phy_sf_sflx_mu,   &
        sflx_mv  => atmos_phy_sf_sflx_mv,   &
        sflx_sh  => atmos_phy_sf_sflx_sh,   &
        sflx_q   => atmos_phy_sf_sflx_qtrc, &
        sflx_qv  => atmos_phy_sf_sflx_qv,   &
        ustar    => atmos_phy_sf_ustar,     &
        tstar    => atmos_phy_sf_tstar,     &
        qstar    => atmos_phy_sf_qstar,     &
        rlmo     => atmos_phy_sf_rlmo
     implicit none

     logical, intent(in) :: update_flag

     real(RP) :: Nu(KA,IA,JA)
     real(RP) :: Kh(KA,IA,JA)

     real(RP) :: QW(KA,IA,JA)

     real(RP) :: N2  (KA,IA,JA)
     real(RP) :: POTL(KA,IA,JA)
     real(RP) :: POTV(KA,IA,JA)

     real(RP), pointer :: RHOQV_t(:,:,:)

     integer  :: k, i, j, iq
     !---------------------------------------------------------------------------

     if ( update_flag ) then

        !$acc data create(Nu,Kh,QW,N2,POTL,POTV)

        !$acc kernels
        rhoq_t_bl(:,:,:,:) = 0.0_rp
        !$acc end kernels

        select case ( atmos_phy_bl_type )
        case ( 'MYNN' )
           call atmos_vars_get_diagnostic( "N2",   n2   )
           call atmos_vars_get_diagnostic( "POTL", potl )
           call atmos_vars_get_diagnostic( "POTV", potv )
           !$acc kernels
           do j = jsb, jeb
           do i = isb, ieb
           do k = ks, ke
              qw(k,i,j) = qv(k,i,j) + qc(k,i,j) + qi(k,i,j)
           end do
           end do
           end do
           !$acc end kernels
           if ( i_qv > 0 ) then
              rhoqv_t => rhoq_t_bl(:,:,:,i_qv)
           else
              allocate( rhoqv_t(ka,ia,ja) )
              !$acc enter data create(RHOQV_t)
           end if
           call atmos_phy_bl_mynn_tendency( &
                ka, ks, ke, ia, is, ie, ja, js, je, &
                dens(:,:,:), u(:,:,:), v(:,:,:), w(:,:,:),              & ! (in)
                pott(:,:,:), qtrc(:,:,:,qs:qe),                         & ! (in)
                pres(:,:,:), exner(:,:,:), n2(:,:,:),                   & ! (in)
                qdry(:,:,:), qv(:,:,:), qw(:,:,:),                      & ! (in)
                potl(:,:,:), potv(:,:,:),                               & ! (in)
                sfc_dens(:,:),                                          & ! (in)
                sflx_mu(:,:), sflx_mv(:,:), sflx_sh(:,:), sflx_qv(:,:), & ! (in)
                ustar(:,:), tstar(:,:), qstar(:,:), rlmo(:,:),          & ! (in)
                frac_land(:,:),                                         & ! (in)
                cz(:,:,:), fz(:,:,:), f2h(:,:,:,:), dt_bl,              & ! (in)
                bulkflux_type,                                          & ! (in)
                rhou_t_bl(:,:,:), rhov_t_bl(:,:,:), rhot_t_bl(:,:,:),   & ! (out)
                rhoqv_t(:,:,:), rhoq_t_bl(:,:,:,qs:qe),                 & ! (out)
                nu(:,:,:), kh(:,:,:),                                   & ! (out)
                ql(:,:,:), cldfrac(:,:,:), zi(:,:), sflx_buoy(:,:)      ) ! (out)
           if ( i_qv <= 0 ) then
              !$acc exit data delete(RHOQV_t)
              deallocate( rhoqv_t )
           end if
        case ( 'MYNN-JMAPPLIB' )
           if ( i_qv > 0 ) then
              rhoqv_t => rhoq_t_bl(:,:,:,i_qv)
           else
              allocate( rhoqv_t(ka,ia,ja) )
              !$acc enter data create(RHOQV_t)
           end if
           !$acc update host(DENS,U,V,POTT,QTRC(:,:,:,QS:QE),PRES,EXNER,QDRY,QV,QC,QI,SFC_DENS,SFC_PRES,SFLX_MU,SFLX_MV,SFLX_SH,SFLX_QV,Ustar,RLmo)
           call atmos_phy_bl_mynn_jmapplib_tendency( &
                ka, ks, ke, ia, is, ie, ja, js, je, &
                dens(:,:,:), u(:,:,:), v(:,:,:),                        & ! (in)
                pott(:,:,:), qtrc(:,:,:,qs:qe),                         & ! (in)
                pres(:,:,:), exner(:,:,:),                              & ! (in)
                qdry(:,:,:), qv(:,:,:), qc(:,:,:), qi(:,:,:),           & ! (in)
                sfc_dens(:,:), sfc_pres(:,:),                           & ! (in)
                sflx_mu(:,:), sflx_mv(:,:), sflx_sh(:,:), sflx_qv(:,:), & ! (in)
                ustar(:,:), rlmo(:,:),                                  & ! (in)
                cz(:,:,:), fz(:,:,:), f2h(:,:,:,:), dt_bl,              & ! (in)
                rhou_t_bl(:,:,:), rhov_t_bl(:,:,:), rhot_t_bl(:,:,:),   & ! (out)
                rhoqv_t(:,:,:), rhoq_t_bl(:,:,:,qs:qe),                 & ! (out)
                nu(:,:,:), kh(:,:,:),                                   & ! (out)
                zi = zi(:,:), sflx_buoy = sflx_buoy(:,:)                ) ! (out)
           !$acc update device(RHOU_t_BL,RHOV_t_BL,RHOT_t_BL,RHOQV_t,RHOQ_t_BL,Nu,Kh,Zi,SFLX_BUOY)
           if ( i_qv <= 0 ) then
              !$acc exit data delete(RHOQV_t)
              deallocate( rhoqv_t )
           end if
        end select

        if ( atmos_phy_bl_mix_tracers ) then
           do iq = 1, qa
              if ( ( .not. tracer_advc(iq) ) .or. iq==i_qv .or. (iq>=qs .and. iq<=qe) ) cycle
              call atmos_phy_bl_tendency_tracer( &
                   ka, ks, ke, ia, is, ie, ja, js, je, &
                   dens(:,:,:), qtrc(:,:,:,iq),        & ! (in)
                   sflx_q(:,:,iq),                     & ! (in)
                   kh(:,:,:),                          & ! (in)
                   tracer_mass(iq),                    & ! (in)
                   cz(:,:,:), fz(:,:,:), f2h(:,:,:,:), & ! (in)
                   dt_bl, tracer_name(iq),             & ! (in)
                   rhoq_t_bl(:,:,:,iq)                 ) ! (out)
           end do
        end if

        call file_history_in( nu(:,:,:),     'Nu_BL',     'eddy viscosity',                         'm2/s',      fill_halo=.true., dim_type="ZHXY" )
        call file_history_in( kh(:,:,:),     'Kh_BL',     'eddy diffusion',                         'm2/s',      fill_halo=.true., dim_type="ZHXY" )

        call file_history_in( ql(:,:,:),    'QL_BL',      'liquid water content in partial condensation', 'kg/kg', fill_halo=.true. )
        call file_history_in( cldfrac(:,:,:),   'cldfrac_BL', 'cloud fraction in partial condensation',       '1',     fill_halo=.true. )

        call file_history_in( zi(:,:),     'Zi_BL',      'depth of the boundary layer', 'm', fill_halo=.true. )

        call file_history_in( rhou_t_bl(:,:,:), 'RHOU_t_BL', 'MOMX tendency (BL)',                     'kg/m2/s2',  fill_halo=.true. )
        call file_history_in( rhov_t_bl(:,:,:), 'RHOV_t_BL', 'MOMY tendency (BL)',                     'kg/m2/s2',  fill_halo=.true. )
        call file_history_in( rhot_t_bl(:,:,:), 'RHOT_t_BL', 'RHOT tendency (BL)',                     'K.kg/m3/s', fill_halo=.true. )

        do iq = 1, qa
           if ( .not. tracer_advc(iq) ) cycle
           call file_history_in( rhoq_t_bl(:,:,:,iq), trim(tracer_name(iq))//'_t_BL',                      &
                         'RHO*'//trim(tracer_name(iq))//' tendency (BL)', 'kg/m3/s', fill_halo=.true. )
        enddo

        if ( statistics_checktotal ) then
           call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                  rhou_t_bl(:,:,:), 'RHOU_t_BL',      &
                                  atmos_grid_cartesc_real_vol(:,:,:), &
                                  atmos_grid_cartesc_real_totvol      )
           call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                  rhov_t_bl(:,:,:), 'RHOV_t_BL',      &
                                  atmos_grid_cartesc_real_vol(:,:,:), &
                                  atmos_grid_cartesc_real_totvol      )
           call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                  rhot_t_bl(:,:,:), 'RHOT_t_BL',      &
                                  atmos_grid_cartesc_real_vol(:,:,:), &
                                  atmos_grid_cartesc_real_totvol      )
           call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                  nu(:,:,:),        'Nu_BL',          &
                                  atmos_grid_cartesc_real_vol(:,:,:), &
                                  atmos_grid_cartesc_real_totvol      )
           call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                  kh(:,:,:),         'Kh_BL',         &
                                  atmos_grid_cartesc_real_vol(:,:,:), &
                                  atmos_grid_cartesc_real_totvol      )

           do iq = 1, qa
              if ( .not. tracer_advc(iq) ) cycle
              call statistics_total( ka, ks, ke, ia, is, ie, ja, js, je, &
                                     rhoq_t_bl(:,:,:,iq), trim(tracer_name(iq))//'_t_BL', &
                                     atmos_grid_cartesc_real_vol(:,:,:),                  &
                                     atmos_grid_cartesc_real_totvol                       )
           enddo
        endif

        !$acc end data

     endif

     !$omp parallel do default(none) private(i,j,k) OMP_SCHEDULE_ collapse(2) &
     !$omp shared(JS,JE,IS,IE,KS,KE,RHOU_t,RHOU_t_BL,RHOV_t,RHOV_t_BL,RHOT_t,RHOT_t_BL)
     !$acc kernels
     do j = js, je
     do i = is, ie
     do k = ks, ke
        rhou_t(k,i,j) = rhou_t(k,i,j) + rhou_t_bl(k,i,j)
        rhov_t(k,i,j) = rhov_t(k,i,j) + rhov_t_bl(k,i,j)
        rhot_t(k,i,j) = rhot_t(k,i,j) + rhot_t_bl(k,i,j)
     enddo
     enddo
     enddo
     !$acc end kernels

     !$omp parallel private(iq,i,j,k)
     !$acc kernels
     do iq = 1,  qa
 #ifndef _OPENACC
        if ( .not. tracer_advc(iq) ) cycle
 #endif
        !$omp do OMP_SCHEDULE_ collapse(2)
        do j  = js, je
        do i  = is, ie
        do k  = ks, ke
 #ifdef _OPENACC
           if ( tracer_advc(iq) ) &
 #endif
           rhoq_t(k,i,j,iq) = rhoq_t(k,i,j,iq) + rhoq_t_bl(k,i,j,iq)
        enddo
        enddo
        enddo
        !$omp end do nowait
     enddo
     !$acc end kernels
     !$omp end parallel

     return

Referenced by mod_atmos_driver::atmos_driver_calc_tendency(), and mod_atmos_driver::atmos_driver_calc_tendency_from_sflux().

Here is the call graph for this function:

Here is the caller graph for this function:

Functions/Subroutines

Detailed Description

Function/Subroutine Documentation

◆ atmos_phy_bl_driver_tracer_setup()

◆ atmos_phy_bl_driver_setup()

◆ atmos_phy_bl_driver_finalize()

◆ atmos_phy_bl_driver_mkinit()

◆ atmos_phy_bl_driver_calc_tendency()
