scale_atmos_phy_tb_d1980 Module Reference

module ATMOSPHERE / Physics Turbulence More...

Functions/Subroutines

subroutine, public atmos_phy_tb_d1980_config (TYPE_TB, I_TKE_out)
 Config. More...

subroutine, public atmos_phy_tb_d1980_setup (CDZ, CDX, CDY, CZ)
 Setup. More...

subroutine, public atmos_phy_tb_d1980_finalize
 finalize More...

subroutine, public atmos_phy_tb_d1980 (qflx_sgs_momz, qflx_sgs_momx, qflx_sgs_momy, qflx_sgs_rhot, qflx_sgs_rhoq, RHOQ_t, Km, Ri, Pr, MOMZ, MOMX, MOMY, RHOT, DENS, QTRC, N2, SFLX_MW, SFLX_MU, SFLX_MV, SFLX_SH, SFLX_Q, GSQRT, J13G, J23G, J33G, MAPF, dt)


Detailed Description

module ATMOSPHERE / Physics Turbulence

Description
Sub-grid scale turbulence process 1.5th TKE model Deardorff (1980)
Author
Team SCALE
Reference
  • Deardorff, 1980: Stratocumulus-capped mixed layers derived from a three-dimensional model. Bound.-Layer Meteor., 18, 495-527
NAMELIST
  • PARAM_ATMOS_PHY_TB_D1980
    nametypedefault valuecomment
    ATMOS_PHY_TB_D1980_KM_MAX real(RP) 1000.0_RP
    ATMOS_PHY_TB_D1980_IMPLICIT logical .false.

History Output
No history output

Function/Subroutine Documentation

◆ atmos_phy_tb_d1980_config()

subroutine, public scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_config ( character(len=*), intent(in)  TYPE_TB,
integer, intent(out)  I_TKE_out
)

Config.

Definition at line 78 of file scale_atmos_phy_tb_d1980.F90.

81  use scale_prc, only: &
82  prc_abort
83  use scale_tracer, only: &
84  tracer_regist
85  implicit none
86
87  character(len=*), intent(in) :: TYPE_TB
88  integer, intent(out) :: I_TKE_out
89  !---------------------------------------------------------------------------
90
91  log_newline
92  log_info("ATMOS_PHY_TB_d1980_config",*) 'Setup'
93  log_info("ATMOS_PHY_TB_d1980_config",*) 'Tracers for Deardorff (1980) 1.5th TKE Model'
94
95  if ( type_tb /= 'D1980' ) then
96  log_error("ATMOS_PHY_TB_d1980_config",*) 'ATMOS_PHY_TB_TYPE is not D1980. Check!'
97  call prc_abort
98  endif
99
100  call tracer_regist( i_tke, & ! [OUT]
101  1, & ! [IN]
102  (/ 'TKE_D1980' /), & ! [IN]
103  (/ 'turbulent kinetic energy (D1980)' /), & ! [IN]
104  (/ 'm2/s2' /) ) ! [IN]
105
106  i_tke_out = i_tke
107
108  return
scale_prc
module PROCESS
Definition: scale_prc.F90:11
scale_prc::prc_abort
subroutine, public prc_abort
Abort Process.
Definition: scale_prc.F90:350
scale_tracer
module TRACER
Definition: scale_tracer.F90:12
scale_tracer::tracer_regist
subroutine, public tracer_regist(QS, NQ, NAME, DESC, UNIT, CV, CP, R, ENGI0, ADVC, MASS)
Regist tracer.
Definition: scale_tracer.F90:68

References scale_prc::prc_abort(), and scale_tracer::tracer_regist().

Referenced by mod_atmos_phy_tb_driver::atmos_phy_tb_driver_tracer_setup().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ atmos_phy_tb_d1980_setup()

subroutine, public scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_setup ( real(rp), dimension(ka), intent(in)  CDZ,
real(rp), dimension(ia), intent(in)  CDX,
real(rp), dimension(ja), intent(in)  CDY,
real(rp), dimension (ka,ia,ja), intent(in)  CZ
)

Setup.

Definition at line 113 of file scale_atmos_phy_tb_d1980.F90.

115  use scale_prc, only: &
116  prc_abort
117  implicit none
118
119  real(RP), intent(in) :: CDZ(KA)
120  real(RP), intent(in) :: CDX(IA)
121  real(RP), intent(in) :: CDY(JA)
122  real(RP), intent(in) :: CZ (KA,IA,JA)
123
124  namelist / param_atmos_phy_tb_d1980 / &
125  atmos_phy_tb_d1980_km_max, &
126  atmos_phy_tb_d1980_implicit
127
128  integer :: ierr
129  integer :: k, i, j
130  !---------------------------------------------------------------------------
131
132  log_newline
133  log_info("ATMOS_PHY_TB_d1980_setup",*) 'Setup'
134  log_info("ATMOS_PHY_TB_d1980_setup",*) 'Deardorff (1980) 1.5th TKE Model'
135
136  !--- read namelist
137  rewind(io_fid_conf)
138  read(io_fid_conf,nml=param_atmos_phy_tb_d1980,iostat=ierr)
139  if( ierr < 0 ) then !--- missing
140  log_info("ATMOS_PHY_TB_d1980_setup",*) 'Not found namelist. Default used.'
141  elseif( ierr > 0 ) then !--- fatal error
142  log_error("ATMOS_PHY_TB_d1980_setup",*) 'Not appropriate names in namelist PARAM_ATMOS_PHY_TB_D1980. Check!'
143  call prc_abort
144  endif
145  log_nml(param_atmos_phy_tb_d1980)
146
147  allocate( delta(ka,ia,ja) )
148
149 #ifdef DEBUG
150  delta(:,:,:) = undef
151 #endif
152  !$omp parallel do
153  do j = js-1, je+1
154  do i = is-1, ie+1
155  do k = ks, ke
156  delta(k,i,j) = ( cdz(k) * cdx(i) * cdy(j) )**(1.0_rp/3.0_rp)
157  enddo
158  enddo
159  enddo
160
161  return

References scale_atmos_grid_cartesc_index::ia, scale_atmos_grid_cartesc_index::ie, scale_io::io_fid_conf, scale_atmos_grid_cartesc_index::is, scale_atmos_grid_cartesc_index::ja, scale_atmos_grid_cartesc_index::je, scale_atmos_grid_cartesc_index::js, scale_tracer::k, scale_atmos_grid_cartesc_index::ka, scale_atmos_grid_cartesc_index::ke, scale_atmos_grid_cartesc_index::ks, and scale_prc::prc_abort().

Referenced by mod_atmos_phy_tb_driver::atmos_phy_tb_driver_setup().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ atmos_phy_tb_d1980_finalize()

subroutine, public scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980_finalize

finalize

Definition at line 166 of file scale_atmos_phy_tb_d1980.F90.

167
168  deallocate( delta )
169
170  return

Referenced by mod_atmos_phy_tb_driver::atmos_phy_tb_driver_finalize().

Here is the caller graph for this function:

◆ atmos_phy_tb_d1980()

subroutine, public scale_atmos_phy_tb_d1980::atmos_phy_tb_d1980 ( real(rp), dimension(ka,ia,ja,3), intent(out)  qflx_sgs_momz,
real(rp), dimension(ka,ia,ja,3), intent(out)  qflx_sgs_momx,
real(rp), dimension(ka,ia,ja,3), intent(out)  qflx_sgs_momy,
real(rp), dimension(ka,ia,ja,3), intent(out)  qflx_sgs_rhot,
real(rp), dimension(ka,ia,ja,3,qa), intent(out)  qflx_sgs_rhoq,
real(rp), dimension (ka,ia,ja,qa), intent(inout)  RHOQ_t,
real(rp), dimension (ka,ia,ja), intent(out)  Km,
real(rp), dimension (ka,ia,ja), intent(out)  Ri,
real(rp), dimension (ka,ia,ja), intent(out)  Pr,
real(rp), dimension (ka,ia,ja), intent(in)  MOMZ,
real(rp), dimension (ka,ia,ja), intent(in)  MOMX,
real(rp), dimension (ka,ia,ja), intent(in)  MOMY,
real(rp), dimension (ka,ia,ja), intent(in)  RHOT,
real(rp), dimension (ka,ia,ja), intent(in)  DENS,
real(rp), dimension (ka,ia,ja,qa), intent(in)  QTRC,
real(rp), dimension (ka,ia,ja), intent(in)  N2,
real(rp), dimension (ia,ja), intent(in)  SFLX_MW,
real(rp), dimension (ia,ja), intent(in)  SFLX_MU,
real(rp), dimension (ia,ja), intent(in)  SFLX_MV,
real(rp), dimension (ia,ja), intent(in)  SFLX_SH,
real(rp), dimension (ia,ja,qa), intent(in)  SFLX_Q,
real(rp), dimension (ka,ia,ja,7), intent(in)  GSQRT,
real(rp), dimension (ka,ia,ja,7), intent(in)  J13G,
real(rp), dimension (ka,ia,ja,7), intent(in)  J23G,
real(rp), intent(in)  J33G,
real(rp), dimension (ia,ja,2,4), intent(in)  MAPF,
real(dp), intent(in)  dt
)
Parameters
[in]gsqrtvertical metrics {G}^1/2
[in]j13g(1,3) element of Jacobian matrix
[in]j23g(1,3) element of Jacobian matrix
[in]j33g(3,3) element of Jacobian matrix
[in]mapfmap factor

Definition at line 174 of file scale_atmos_phy_tb_d1980.F90.

182  use scale_precision
183  use scale_atmos_grid_cartesc_index
184  use scale_tracer
185  use scale_const, only: &
186  grav => const_grav
187  use scale_atmos_grid_cartesc, only: &
188  fdz => atmos_grid_cartesc_fdz, &
189  rcdz => atmos_grid_cartesc_rcdz, &
190  rcdx => atmos_grid_cartesc_rcdx, &
191  rcdy => atmos_grid_cartesc_rcdy, &
192  rfdz => atmos_grid_cartesc_rfdz, &
193  rfdx => atmos_grid_cartesc_rfdx, &
194  rfdy => atmos_grid_cartesc_rfdy
195  use scale_matrix, only: &
196  matrix_solver_tridiagonal
197  use scale_atmos_phy_tb_common, only: &
198  calc_strain_tensor => atmos_phy_tb_calc_strain_tensor, &
199  calc_tend_momz => atmos_phy_tb_calc_tend_momz, &
200  calc_tend_momx => atmos_phy_tb_calc_tend_momx, &
201  calc_tend_momy => atmos_phy_tb_calc_tend_momy, &
202  calc_tend_phi => atmos_phy_tb_calc_tend_phi, &
203  calc_flux_phi => atmos_phy_tb_calc_flux_phi
204  implicit none
205
206  ! SGS flux
207  real(RP), intent(out) :: qflx_sgs_momz(KA,IA,JA,3)
208  real(RP), intent(out) :: qflx_sgs_momx(KA,IA,JA,3)
209  real(RP), intent(out) :: qflx_sgs_momy(KA,IA,JA,3)
210  real(RP), intent(out) :: qflx_sgs_rhot(KA,IA,JA,3)
211  real(RP), intent(out) :: qflx_sgs_rhoq(KA,IA,JA,3,QA)
212
213  real(RP), intent(inout) :: RHOQ_t (KA,IA,JA,QA) ! tendency of rho * QTRC
214
215  real(RP), intent(out) :: Km (KA,IA,JA) ! eddy viscosity (center)
216  real(RP), intent(out) :: Ri (KA,IA,JA) ! Richardson number
217  real(RP), intent(out) :: Pr (KA,IA,JA) ! Prantle number
218
219  real(RP), intent(in) :: MOMZ (KA,IA,JA)
220  real(RP), intent(in) :: MOMX (KA,IA,JA)
221  real(RP), intent(in) :: MOMY (KA,IA,JA)
222  real(RP), intent(in) :: RHOT (KA,IA,JA)
223  real(RP), intent(in) :: DENS (KA,IA,JA)
224  real(RP), intent(in) :: QTRC (KA,IA,JA,QA)
225  real(RP), intent(in) :: N2 (KA,IA,JA)
226
227  real(RP), intent(in) :: SFLX_MW (IA,JA)
228  real(RP), intent(in) :: SFLX_MU (IA,JA)
229  real(RP), intent(in) :: SFLX_MV (IA,JA)
230  real(RP), intent(in) :: SFLX_SH (IA,JA)
231  real(RP), intent(in) :: SFLX_Q (IA,JA,QA)
232
233  real(RP), intent(in) :: GSQRT (KA,IA,JA,7)
234  real(RP), intent(in) :: J13G (KA,IA,JA,7)
235  real(RP), intent(in) :: J23G (KA,IA,JA,7)
236  real(RP), intent(in) :: J33G
237  real(RP), intent(in) :: MAPF (IA,JA,2,4)
238  real(DP), intent(in) :: dt
239
240  ! diagnostic variables
241  real(RP) :: POTT (KA,IA,JA)
242
243  ! deformation rate tensor
244  real(RP) :: S33_C (KA,IA,JA) ! (cell center)
245  real(RP) :: S11_C (KA,IA,JA)
246  real(RP) :: S22_C (KA,IA,JA)
247  real(RP) :: S31_C (KA,IA,JA)
248  real(RP) :: S12_C (KA,IA,JA)
249  real(RP) :: S23_C (KA,IA,JA)
250  real(RP) :: S12_Z (KA,IA,JA) ! (z edge or x-y plane)
251  real(RP) :: S23_X (KA,IA,JA) ! (x edge or y-z plane)
252  real(RP) :: S31_Y (KA,IA,JA) ! (y edge or z-x plane)
253  real(RP) :: S2 (KA,IA,JA) ! |S|^2
254
255  real(RP) :: Kh (KA,IA,JA) ! eddy diffusion
256  real(RP) :: l (KA,IA,JA) ! mixing length
257
258  real(RP) :: qflx_tke(KA,IA,JA,3)
259
260  real(RP) :: TEND(KA,IA,JA)
261  real(RP) :: TEND2(KA,IA,JA)
262  real(RP) :: a(KA,IA,JA)
263  real(RP) :: b(KA,IA,JA)
264  real(RP) :: c(KA,IA,JA)
265  real(RP) :: ap
266
267  integer :: IIS, IIE
268  integer :: JJS, JJE
269
270  integer :: k, i, j, iq
271  !---------------------------------------------------------------------------
272
273  log_progress(*) 'atmosphere / physics / turbulence / D1980'
274
275 #ifdef DEBUG
276  qflx_sgs_momz(:,:,:,:) = undef
277  qflx_sgs_momx(:,:,:,:) = undef
278  qflx_sgs_momy(:,:,:,:) = undef
279  qflx_sgs_rhot(:,:,:,:) = undef
280  qflx_sgs_rhoq(:,:,:,:,:) = undef
281
282  pr(:,:,:) = undef
283  ri(:,:,:) = undef
284  kh(:,:,:) = undef
285  km(:,:,:) = undef
286
287  pott(:,:,:) = undef
288 #endif
289
290  ! potential temperature
291  !$omp parallel do
292  do j = js-1, je+1
293  do i = is-1, ie+1
294  do k = ks, ke
295 #ifdef DEBUG
296  call check( __line__, rhot(k,i,j) )
297  call check( __line__, dens(k,i,j) )
298 #endif
299  pott(k,i,j) = rhot(k,i,j) / dens(k,i,j)
300  enddo
301  enddo
302  enddo
303 #ifdef DEBUG
304  i = iundef; j = iundef; k = iundef
305 #endif
306
307  !##### Start Upadate #####
308
309  call calc_strain_tensor( &
310  s33_c, s11_c, s22_c, & ! (out)
311  s31_c, s12_c, s23_c, & ! (out)
312  s12_z, s23_x, s31_y, & ! (out)
313  s2 , & ! (out)
314  dens, momz, momx, momy, & ! (in)
315  gsqrt, j13g, j23g, j33g, mapf ) ! (in)
316
317  do jjs = js, je, jblock
318  jje = jjs+jblock-1
319  do iis = is, ie, iblock
320  iie = iis+iblock-1
321
322  ! Ri = N^2 / |S|^2, N^2 = g / theta * dtheta/dz
323  !$omp parallel do
324  do j = jjs-1, jje+1
325  do i = iis-1, iie+1
326  do k = ks, ke
327 #ifdef DEBUG
328  call check( __line__, pott(k+1,i,j) )
329  call check( __line__, pott(k,i,j) )
330  call check( __line__, pott(k-1,i,j) )
331  call check( __line__, fdz(k) )
332  call check( __line__, fdz(k-1) )
333  call check( __line__, s2(k,i,j) )
334 #endif
335  ri(k,i,j) = n2(k,i,j) / s2(k,i,j)
336  enddo
337  enddo
338  enddo
339 #ifdef DEBUG
340  i = iundef; j = iundef; k = iundef
341 #endif
342
343  ! mixing length
344  !$omp parallel do
345  do j = jjs-1, jje+1
346  do i = iis-1, iie+1
347  do k = ks, ke
348  if ( n2(k,i,j) > 1e-10_rp ) then
349  l(k,i,j) = max( min( 0.76_rp * sqrt(qtrc(k,i,j,i_tke)/n2(k,i,j)), delta(k,i,j) ), 1e-10_rp )
350  else
351  l(k,i,j) = delta(k,i,j)
352  end if
353  enddo
354  enddo
355  enddo
356 #ifdef DEBUG
357  i = iundef; j = iundef; k = iundef
358 #endif
359
360  !$omp parallel do
361  do j = jjs-1, jje+1
362  do i = iis-1, iie+1
363  do k = ks, ke
364  km(k,i,j) = min( 0.10_rp * l(k,i,j) * sqrt(qtrc(k,i,j,i_tke)), atmos_phy_tb_d1980_km_max )
365  pr(k,i,j) = 1.0_rp / ( 1.0_rp + 2.0_rp * l(k,i,j) / delta(k,i,j) )
366  kh(k,i,j) = km(k,i,j) / pr(k,i,j)
367  enddo
368  enddo
369  enddo
370 #ifdef DEBUG
371  i = iundef; j = iundef; k = iundef
372 #endif
373
374  !##### momentum equation (z) #####
375  ! (cell center)
376  !$omp parallel do
377  do j = jjs, jje
378  do i = iis, iie
379  do k = ks+1, ke-1
380 #ifdef DEBUG
381  call check( __line__, dens(k,i,j) )
382  call check( __line__, km(k,i,j) )
383  call check( __line__, s33_c(k,i,j) )
384 #endif
385  qflx_sgs_momz(k,i,j,zdir) = dens(k,i,j) * ( - 2.0_rp * km(k,i,j) * s33_c(k,i,j) )
386  enddo
387  enddo
388  enddo
389 #ifdef DEBUG
390  i = iundef; j = iundef; k = iundef
391 #endif
392  !$omp parallel do
393  do j = jjs, jje
394  do i = iis, iie
395  qflx_sgs_momz(ks,i,j,zdir) = 0.0_rp ! just above bottom boundary
396  qflx_sgs_momz(ke,i,j,zdir) = 0.0_rp ! just below top boundary
397  enddo
398  enddo
399 #ifdef DEBUG
400  i = iundef; j = iundef; k = iundef
401 #endif
402  ! (y edge)
403  !$omp parallel do
404  do j = jjs, jje
405  do i = iis-1, iie
406  do k = ks, ke-1
407 #ifdef DEBUG
408  call check( __line__, dens(k,i,j) )
409  call check( __line__, dens(k,i+1,j) )
410  call check( __line__, dens(k+1,i,j) )
411  call check( __line__, dens(k+1,i+1,j) )
412  call check( __line__, km(k,i,j) )
413  call check( __line__, km(k,i+1,j) )
414  call check( __line__, km(k+1,i,j) )
415  call check( __line__, km(k+1,i+1,j) )
416  call check( __line__, s31_y(k,i,j) )
417 #endif
418  qflx_sgs_momz(k,i,j,xdir) = - 0.125_rp & ! 2.0 / 4 / 4
419  * ( dens(k,i,j)+dens(k+1,i,j)+dens(k,i+1,j)+dens(k+1,i+1,j) ) &
420  * ( km(k,i,j)+km(k+1,i,j)+km(k,i+1,j)+km(k+1,i+1,j)) &
421  * s31_y(k,i,j)
422  enddo
423  enddo
424  enddo
425 #ifdef DEBUG
426  i = iundef; j = iundef; k = iundef
427 #endif
428  ! (x edge)
429  !$omp parallel do
430  do j = jjs-1, jje
431  do i = iis, iie
432  do k = ks, ke-1
433 #ifdef DEBUG
434  call check( __line__, dens(k,i,j) )
435  call check( __line__, dens(k,i,j+1) )
436  call check( __line__, dens(k+1,i,j) )
437  call check( __line__, dens(k+1,i,j+1) )
438  call check( __line__, km(k,i,j) )
439  call check( __line__, km(k,i,j+1) )
440  call check( __line__, km(k+1,i,j) )
441  call check( __line__, km(k+1,i,j+1) )
442  call check( __line__, s23_x(k,i,j) )
443 #endif
444  qflx_sgs_momz(k,i,j,ydir) = - 0.125_rp & ! 2/4/4
445  * ( dens(k,i,j)+dens(k+1,i,j)+dens(k,i,j+1)+dens(k+1,i,j+1) ) &
446  * ( km(k,i,j)+km(k+1,i,j)+km(k,i,j+1)+km(k+1,i,j+1) ) &
447  * s23_x(k,i,j)
448  enddo
449  enddo
450  enddo
451 #ifdef DEBUG
452  i = iundef; j = iundef; k = iundef
453 #endif
454
455  if ( atmos_phy_tb_d1980_implicit ) then
456  call calc_tend_momz( tend, & ! (out)
457  qflx_sgs_momz, & ! (in)
458  gsqrt, j13g, j23g, j33g, mapf, & ! (in)
459  iis, iie, jjs, jje ) ! (in)
460
461  !$omp parallel do &
462  !$omp private(ap)
463  do j = jjs, jje
464  do i = iis, iie
465
466  ap = - fouroverthree * dt &
467  * dens(ks+1,i,j)*km(ks+1,i,j) &
468  * rcdz(ks+1) / gsqrt(ks+1,i,j,i_xyz)
469  a(ks,i,j) = ap * rfdz(ks) / gsqrt(ks,i,j,i_xyw)
470  c(ks,i,j) = 0.0_rp
471  b(ks,i,j) = - a(ks,i,j) + 0.5_rp * ( dens(ks,i,j)+dens(ks+1,i,j) )
472  do k = ks+1, ke-2
473  c(k,i,j) = ap * rfdz(k+1) / gsqrt(k+1,i,j,i_xyw)
474  ap = - fouroverthree * dt &
475  * dens(k+1,i,j)*km(k+1,i,j) &
476  * rcdz(k+1) / gsqrt(k+1,i,j,i_xyz)
477  a(k,i,j) = ap * rfdz(k) / gsqrt(k,i,j,i_xyw)
478  b(k,i,j) = - a(k,i,j) - c(k,i,j) + 0.5_rp * ( dens(k,i,j)+dens(k+1,i,j) )
479  end do
480  a(ke-1,i,j) = 0.0_rp
481  c(ke-1,i,j) = ap * rfdz(ke) / gsqrt(ke,i,j,i_xyw)
482  b(ke-1,i,j) = - c(ke-1,i,j) + 0.5_rp * ( dens(ke-1,i,j)+dens(ke,i,j) )
483  end do
484  end do
485
486  call matrix_solver_tridiagonal( ka, ks, ke-1, ia, iis, iie, ja, jjs, jje, &
487  a(:,:,:), b(:,:,:), c(:,:,:), tend(:,:,:), & ! (in)
488  tend2(:,:,:) ) ! (out)
489
490  !$omp parallel do
491  do j = jjs, jje
492  do i = iis, iie
493  do k = ks+1, ke-1
494  qflx_sgs_momz(k,i,j,zdir) = qflx_sgs_momz(k,i,j,zdir) &
495  - fouroverthree * dens(k,i,j) * km(k,i,j) * dt &
496  * ( tend2(k,i,j) - tend2(k-1,i,j) ) * rcdz(k) / gsqrt(k,i,j,i_xyz)
497  end do
498
499  end do
500  end do
501
502  end if
503
504  !##### momentum equation (x) #####
505  ! (y edge)
506  !$omp parallel do
507  do j = jjs, jje
508  do i = iis, iie
509  do k = ks, ke-1
510 #ifdef DEBUG
511  call check( __line__, dens(k,i,j) )
512  call check( __line__, dens(k,i+1,j) )
513  call check( __line__, dens(k+1,i,j) )
514  call check( __line__, dens(k+1,i+1,j) )
515  call check( __line__, km(k,i,j) )
516  call check( __line__, km(k,i+1,j) )
517  call check( __line__, km(k+1,i,j) )
518  call check( __line__, km(k+1,i+1,j) )
519  call check( __line__, s31_y(k,i,j) )
520 #endif
521  qflx_sgs_momx(k,i,j,zdir) = - 0.125_rp & ! 2/4/4
522  * ( dens(k,i,j)+dens(k+1,i,j)+dens(k,i+1,j)+dens(k+1,i+1,j) ) &
523  * ( km(k,i,j)+km(k+1,i,j)+km(k,i+1,j)+km(k+1,i+1,j) ) &
524  * s31_y(k,i,j)
525  enddo
526  enddo
527  enddo
528 #ifdef DEBUG
529  i = iundef; j = iundef; k = iundef
530 #endif
531  !$omp parallel do
532  do j = jjs, jje
533  do i = iis, iie
534  qflx_sgs_momx(ks-1,i,j,zdir) = 0.0_rp ! bottom boundary
535  qflx_sgs_momx(ke ,i,j,zdir) = 0.0_rp ! top boundary
536  enddo
537  enddo
538 #ifdef DEBUG
539  i = iundef; j = iundef; k = iundef
540 #endif
541  ! (cell center)
542  !$omp parallel do
543  do j = jjs, jje
544  do i = iis, iie+1
545  do k = ks, ke
546 #ifdef DEBUG
547  call check( __line__, dens(k,i,j) )
548  call check( __line__, km(k,i,j) )
549  call check( __line__, s11_c(k,i,j) )
550 #endif
551  qflx_sgs_momx(k,i,j,xdir) = dens(k,i,j) * ( - 2.0_rp * km(k,i,j) * s11_c(k,i,j) )
552  enddo
553  enddo
554  enddo
555 #ifdef DEBUG
556  i = iundef; j = iundef; k = iundef
557 #endif
558  ! (z edge)
559  !$omp parallel do
560  do j = jjs-1, jje
561  do i = iis, iie
562  do k = ks, ke
563 #ifdef DEBUG
564  call check( __line__, dens(k,i,j) )
565  call check( __line__, dens(k,i+1,j) )
566  call check( __line__, dens(k,i,j+1) )
567  call check( __line__, dens(k,i+1,j+1) )
568  call check( __line__, km(k,i,j) )
569  call check( __line__, km(k,i+1,j) )
570  call check( __line__, km(k,i,j+1) )
571  call check( __line__, km(k,i+1,j+1) )
572  call check( __line__, s12_z(k,i,j) )
573 #endif
574  qflx_sgs_momx(k,i,j,ydir) = - 0.125_rp & ! 2/4/4
575  * ( dens(k,i,j)+dens(k,i+1,j)+dens(k,i,j+1)+dens(k,i+1,j+1) ) &
576  * ( km(k,i,j)+km(k,i+1,j)+km(k,i,j+1)+km(k,i+1,j+1) ) &
577  * s12_z(k,i,j)
578  enddo
579  enddo
580  enddo
581 #ifdef DEBUG
582  i = iundef; j = iundef; k = iundef
583 #endif
584
585  if ( atmos_phy_tb_d1980_implicit ) then
586  call calc_tend_momx( tend, & ! (out)
587  qflx_sgs_momx, & ! (in)
588  gsqrt, j13g, j23g, j33g, mapf, & ! (in)
589  iis, iie, jjs, jje ) ! (in)
590
591  !$omp parallel do &
592  !$omp private(ap)
593  do j = jjs, jje
594  do i = iis, iie
595
596  ap = - dt * 0.25_rp * ( dens(ks ,i ,j)*km(ks ,i ,j) &
597  + dens(ks+1,i ,j)*km(ks+1,i ,j) &
598  + dens(ks ,i+1,j)*km(ks ,i+1,j) &
599  + dens(ks+1,i+1,j)*km(ks+1,i+1,j) ) &
600  * rfdz(ks) / gsqrt(ks,i,j,i_uyw)
601  a(ks,i,j) = ap * rcdz(ks) / gsqrt(ks,i,j,i_uyz)
602  c(ks,i,j) = 0.0_rp
603  b(ks,i,j) = - a(ks,i,j) + 0.5_rp * ( dens(ks,i,j)+dens(ks,i+1,j) )
604  do k = ks+1, ke-1
605  c(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_uyz)
606  ap = - dt * 0.25_rp * ( dens(k ,i ,j)*km(k ,i ,j) &
607  + dens(k+1,i ,j)*km(k+1,i ,j) &
608  + dens(k ,i+1,j)*km(k ,i+1,j) &
609  + dens(k+1,i+1,j)*km(k+1,i+1,j) ) &
610  * rfdz(k) / gsqrt(k,i,j,i_uyw)
611  a(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_uyz)
612  b(k,i,j) = - a(k,i,j) - c(k,i,j) + 0.5_rp * ( dens(k,i,j)+dens(k,i+1,j) )
613  end do
614  a(ke,i,j) = 0.0_rp
615  c(ke,i,j) = ap * rcdz(ke) / gsqrt(ke,i,j,i_uyz)
616  b(ke,i,j) = - c(ke,i,j) + 0.5_rp * ( dens(ke,i,j)+dens(ke,i+1,j) )
617  end do
618  end do
619
620  call matrix_solver_tridiagonal( ka, ks, ke, ia, iis, iie, ja, jjs, jje, &
621  a(:,:,:), b(:,:,:), c(:,:,:), tend(:,:,:), & ! (in)
622  tend2(:,:,:) ) ! (out)
623
624  !$omp parallel do
625  do j = jjs, jje
626  do i = iis, iie
627  do k = ks, ke-1
628  qflx_sgs_momx(k,i,j,zdir) = qflx_sgs_momx(k,i,j,zdir) &
629  - 0.25_rp * ( dens(k ,i ,j)*km(k ,i ,j) &
630  + dens(k+1,i ,j)*km(k+1,i ,j) &
631  + dens(k ,i+1,j)*km(k ,i+1,j) &
632  + dens(k+1,i+1,j)*km(k+1,i+1,j) ) &
633  * dt * ( tend2(k+1,i,j) - tend2(k,i,j) ) * rfdz(k) / gsqrt(k,i,j,i_uyw)
634  end do
635
636  end do
637  end do
638
639  end if
640
641  !##### momentum equation (y) #####
642  ! (x edge)
643  !$omp parallel do
644  do j = jjs, jje
645  do i = iis, iie
646  do k = ks, ke-1
647 #ifdef DEBUG
648  call check( __line__, dens(k,i,j) )
649  call check( __line__, dens(k,i,j+1) )
650  call check( __line__, dens(k+1,i,j) )
651  call check( __line__, dens(k+1,i,j+1) )
652  call check( __line__, km(k,i,j) )
653  call check( __line__, km(k,i,j+1) )
654  call check( __line__, km(k+1,i,j) )
655  call check( __line__, km(k+1,i,j+1) )
656  call check( __line__, s23_x(k,i,j) )
657 #endif
658  qflx_sgs_momy(k,i,j,zdir) = - 0.125_rp & ! 2/4/4
659  * ( dens(k,i,j)+dens(k+1,i,j)+dens(k,i,j+1)+dens(k+1,i,j+1) ) &
660  * ( km(k,i,j)+km(k+1,i,j)+km(k,i,j+1)+km(k+1,i,j+1) ) &
661  * s23_x(k,i,j)
662  enddo
663  enddo
664  enddo
665 #ifdef DEBUG
666  i = iundef; j = iundef; k = iundef
667 #endif
668  !$omp parallel do
669  do j = jjs, jje
670  do i = iis, iie
671  qflx_sgs_momy(ks-1,i,j,zdir) = 0.0_rp ! bottom boundary
672  qflx_sgs_momy(ke ,i,j,zdir) = 0.0_rp ! top boundary
673  enddo
674  enddo
675 #ifdef DEBUG
676  i = iundef; j = iundef; k = iundef
677 #endif
678
679  ! (z edge)
680  !$omp parallel do
681  do j = jjs, jje
682  do i = iis-1, iie
683  do k = ks, ke
684 #ifdef DEBUG
685  call check( __line__, dens(k,i,j) )
686  call check( __line__, dens(k,i+1,j) )
687  call check( __line__, dens(k,i,j+1) )
688  call check( __line__, dens(k,i+1,j+1) )
689  call check( __line__, km(k,i,j) )
690  call check( __line__, km(k,i+1,j) )
691  call check( __line__, km(k,i,j+1) )
692  call check( __line__, km(k,i+1,j+1) )
693  call check( __line__, s12_z(k,i,j) )
694 #endif
695  qflx_sgs_momy(k,i,j,xdir) = - 0.125_rp & !
696  * ( dens(k,i,j)+dens(k,i+1,j)+dens(k,i,j+1)+dens(k,i+1,j+1) ) &
697  * ( km(k,i,j)+km(k,i+1,j)+km(k,i,j+1)+km(k,i+1,j+1) ) &
698  * s12_z(k,i,j)
699  enddo
700  enddo
701  enddo
702 #ifdef DEBUG
703  i = iundef; j = iundef; k = iundef
704 #endif
705
706  ! (z-x plane)
707  !$omp parallel do
708  do j = jjs, jje+1
709  do i = iis, iie
710  do k = ks, ke
711 #ifdef DEBUG
712  call check( __line__, dens(k,i,j) )
713  call check( __line__, km(k,i,j) )
714  call check( __line__, s22_c(k,i,j) )
715 #endif
716  qflx_sgs_momy(k,i,j,ydir) = dens(k,i,j) * ( - 2.0_rp * km(k,i,j) * s22_c(k,i,j) )
717  enddo
718  enddo
719  enddo
720 #ifdef DEBUG
721  i = iundef; j = iundef; k = iundef
722 #endif
723
724  if ( atmos_phy_tb_d1980_implicit ) then
725  call calc_tend_momy( tend, & ! (out)
726  qflx_sgs_momy, & ! (in)
727  gsqrt, j13g, j23g, j33g, mapf, & ! (in)
728  iis, iie, jjs, jje ) ! (in)
729
730  !$omp parallel do &
731  !$omp private(ap)
732  do j = jjs, jje
733  do i = iis, iie
734
735  ap = - dt * 0.25_rp * ( dens(ks ,i,j )*km(ks ,i,j ) &
736  + dens(ks+1,i,j )*km(ks+1,i,j ) &
737  + dens(ks ,i,j+1)*km(ks ,i,j+1) &
738  + dens(ks+1,i,j+1)*km(ks+1,i,j+1) ) &
739  * rfdz(ks) / gsqrt(ks,i,j,i_xvw)
740  a(ks,i,j) = ap * rcdz(ks) / gsqrt(ks,i,j,i_xvz)
741  c(ks,i,j) = 0.0_rp
742  b(ks,i,j) = - a(ks,i,j) + 0.5_rp * ( dens(ks,i,j)+dens(ks,i,j+1) )
743  do k = ks+1, ke-1
744  c(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xvz)
745  ap = - dt * 0.25_rp * ( dens(k ,i,j )*km(k ,i,j ) &
746  + dens(k+1,i,j )*km(k+1,i,j ) &
747  + dens(k ,i,j+1)*km(k ,i,j+1) &
748  + dens(k+1,i,j+1)*km(k+1,i,j+1) ) &
749  * rfdz(k) / gsqrt(k,i,j,i_xvw)
750  a(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xvz)
751  b(k,i,j) = - a(k,i,j) - c(k,i,j) + 0.5_rp * ( dens(k,i,j)+dens(k,i,j+1) )
752  end do
753  a(ke,i,j) = 0.0_rp
754  c(ke,i,j) = ap * rcdz(ke) / gsqrt(ke,i,j,i_xvz)
755  b(ke,i,j) = - c(ke,i,j) + 0.5_rp * ( dens(ke,i,j)+dens(ke,i,j+1) )
756  end do
757  end do
758
759  call matrix_solver_tridiagonal( ka, ks, ke, ia, iis, iie, ja, jjs, jje, &
760  a(:,:,:), b(:,:,:), c(:,:,:), tend(:,:,:), & ! (in)
761  tend2(:,:,:) ) ! (out)
762
763  !$omp parallel do
764  do j = jjs, jje
765  do i = iis, iie
766  do k = ks, ke-1
767  qflx_sgs_momy(k,i,j,zdir) = qflx_sgs_momy(k,i,j,zdir) &
768  - 0.25_rp * ( dens(k ,i,j )*km(k ,i,j ) &
769  + dens(k+1,i,j )*km(k+1,i,j ) &
770  + dens(k ,i,j+1)*km(k ,i,j+1) &
771  + dens(k+1,i,j+1)*km(k+1,i,j+1) ) &
772  * dt * ( tend2(k+1,i,j) - tend2(k,i,j) ) * rfdz(k) / gsqrt(k,i,j,i_xvw)
773  end do
774
775  end do
776  end do
777
778  end if
779
780  !##### Thermodynamic Equation #####
781
782  if ( atmos_phy_tb_d1980_implicit ) then
783
784  !$omp parallel do &
785  !$omp private(ap)
786  do j = jjs, jje
787  do i = iis, iie
788
789  ap = - dt * 0.25_rp * ( dens(ks,i,j)+dens(ks+1,i,j) ) &
790  * ( kh(ks,i,j)+kh(ks+1,i,j) ) &
791  * rfdz(ks) / gsqrt(ks,i,j,i_xyw)
792  a(ks,i,j) = ap * rcdz(ks) / gsqrt(ks,i,j,i_xyz)
793  c(ks,i,j) = 0.0_rp
794  b(ks,i,j) = - a(ks,i,j) + dens(ks,i,j)
795  do k = ks+1, ke-1
796  c(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xyz)
797  ap = - dt * 0.25_rp * ( dens(k,i,j)+dens(k+1,i,j) ) &
798  * ( kh(k,i,j)+kh(k+1,i,j) ) &
799  * rfdz(k) / gsqrt(k,i,j,i_xyw)
800  a(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xyz)
801  b(k,i,j) = - a(k,i,j) - c(k,i,j) + dens(k,i,j)
802  end do
803  a(ke,i,j) = 0.0_rp
804  c(ke,i,j) = ap * rcdz(ke) / gsqrt(ke,i,j,i_xyz)
805  b(ke,i,j) = - c(ke,i,j) + dens(ke,i,j)
806
807  end do
808  end do
809
810  end if
811
812  call calc_flux_phi( &
813  qflx_sgs_rhot, &
814  dens, pott, kh, 1.0_rp, &
815  gsqrt, j13g, j23g, j33g, mapf, &
816  .false., &
817  atmos_phy_tb_d1980_implicit, &
818  a, b, c, dt, &
819  iis, iie, jjs, jje )
820
821  enddo
822  enddo
823
824
825  !##### Tracers #####
826  do iq = 1, qa
827
828  if ( iq == i_tke ) then
829  qflx_sgs_rhoq(:,:,:,:,iq) = 0.0_rp
830  cycle
831  end if
832  if ( .not. tracer_advc(iq) ) cycle
833
834  do jjs = js, je, jblock
835  jje = jjs+jblock-1
836  do iis = is, ie, iblock
837  iie = iis+iblock-1
838
839  call calc_flux_phi( &
840  qflx_sgs_rhoq(:,:,:,:,iq), &
841  dens, qtrc(:,:,:,iq), kh, 1.0_rp, &
842  gsqrt, j13g, j23g, j33g, mapf, &
843  .false., &
844  atmos_phy_tb_d1980_implicit, &
845  a, b, c, dt, &
846  iis, iie, jjs, jje )
847
848  enddo
849  enddo
850 #ifdef DEBUG
851  iis = iundef; iie = iundef; jjs = iundef; jje = iundef
852 #endif
853
854  enddo ! scalar quantities loop
855 #ifdef DEBUG
856  iq = iundef
857 #endif
858
859  ! TKE
860  do jjs = js, je, jblock
861  jje = jjs+jblock-1
862  do iis = is, ie, iblock
863  iie = iis+iblock-1
864
865  if ( atmos_phy_tb_d1980_implicit ) then
866
867  !$omp parallel do &
868  !$omp private(ap)
869  do j = jjs, jje
870  do i = iis, iie
871
872  ap = - dt * 0.25_rp * ( dens(ks,i,j)+dens(ks+1,i,j) ) &
873  * 2.0_rp * ( km(ks,i,j)+km(ks+1,i,j) ) &
874  * rfdz(ks) / gsqrt(ks,i,j,i_xyw)
875  a(ks,i,j) = ap * rcdz(ks) / gsqrt(ks,i,j,i_xyz)
876  c(ks,i,j) = 0.0_rp
877  b(ks,i,j) = - a(ks,i,j) + dens(ks,i,j)
878  do k = ks+1, ke-1
879  c(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xyz)
880  ap = - dt * 0.25_rp * ( dens(k,i,j)+dens(k+1,i,j) ) &
881  * 2.0_rp * ( km(k,i,j)+km(k+1,i,j) ) &
882  * rfdz(k) / gsqrt(k,i,j,i_xyw)
883  a(k,i,j) = ap * rcdz(k) / gsqrt(k,i,j,i_xyz)
884  b(k,i,j) = - a(k,i,j) - c(k,i,j) + dens(k,i,j)
885  end do
886  a(ke,i,j) = 0.0_rp
887  c(ke,i,j) = ap * rcdz(ke) / gsqrt(ke,i,j,i_xyz)
888  b(ke,i,j) = - c(ke,i,j) + dens(ke,i,j)
889
890  end do
891  end do
892
893  end if
894
895  call calc_flux_phi( &
896  qflx_tke, & ! (out)
897  dens, qtrc(:,:,:,i_tke), km, 2.0_rp, & ! (in)
898  gsqrt, j13g, j23g, j33g, mapf, & ! (in)
899  .false., & ! (in)
900  atmos_phy_tb_d1980_implicit, & ! (in)
901  a, b, c, dt, & ! (in)
902  iis, iie, jjs, jje ) ! (in)
903
904  call calc_tend_phi( rhoq_t(:,:,:,i_tke), & ! (out)
905  qflx_tke, & ! (in)
906  gsqrt, j13g, j23g, j33g, mapf, & ! (in)
907  iis, iie, jjs, jje ) ! (in)
908  !$omp parallel do
909  do j = jjs, jje
910  do i = iis, iie
911  do k = ks, ke
912  rhoq_t(k,i,j,i_tke) = max( &
913  rhoq_t(k,i,j,i_tke) &
914  + ( km(k,i,j) * s2(k,i,j) &
915  - kh(k,i,j) * n2(k,i,j) &
916  - ( c1 + c2*l(k,i,j)/delta(k,i,j) ) * qtrc(k,i,j,i_tke)**(1.5_rp) / l(k,i,j) ) * dens(k,i,j), &
917  - qtrc(k,i,j,i_tke) * dens(k,i,j) / real(dt,kind=rp) )
918  enddo
919  enddo
920  enddo
921 #ifdef DEBUG
922  i = iundef; j = iundef; k = iundef
923 #endif
924
925  end do
926  end do
927
928
929  return
scale_atmos_grid_cartesc_index
module atmosphere / grid / cartesC index
Definition: scale_atmos_grid_cartesC_index.F90:12
scale_atmos_grid_cartesc_index::i_xvw
integer, public i_xvw
Definition: scale_atmos_grid_cartesC_index.F90:94
scale_atmos_grid_cartesc_index::xdir
integer, parameter, public xdir
Definition: scale_atmos_grid_cartesC_index.F90:33
scale_atmos_grid_cartesc_index::i_uyz
integer, public i_uyz
Definition: scale_atmos_grid_cartesC_index.F90:95
scale_atmos_grid_cartesc_index::ie
integer, public ie
end point of inner domain: x, local
Definition: scale_atmos_grid_cartesC_index.F90:54
scale_atmos_grid_cartesc_index::je
integer, public je
end point of inner domain: y, local
Definition: scale_atmos_grid_cartesC_index.F90:56
scale_atmos_grid_cartesc_index::is
integer, public is
start point of inner domain: x, local
Definition: scale_atmos_grid_cartesC_index.F90:53
scale_atmos_grid_cartesc_index::ia
integer, public ia
Definition: scale_atmos_grid_cartesC_index.F90:48
scale_atmos_grid_cartesc_index::i_xvz
integer, public i_xvz
Definition: scale_atmos_grid_cartesC_index.F90:96
scale_atmos_grid_cartesc_index::i_xyw
integer, public i_xyw
Definition: scale_atmos_grid_cartesC_index.F90:92
scale_atmos_grid_cartesc_index::iblock
integer, public iblock
block size for cache blocking: x
Definition: scale_atmos_grid_cartesC_index.F90:40
scale_atmos_grid_cartesc_index::i_xyz
integer, public i_xyz
Definition: scale_atmos_grid_cartesC_index.F90:91
scale_atmos_grid_cartesc_index::zdir
integer, parameter, public zdir
Definition: scale_atmos_grid_cartesC_index.F90:32
scale_atmos_grid_cartesc_index::jblock
integer, public jblock
block size for cache blocking: y
Definition: scale_atmos_grid_cartesC_index.F90:41
scale_atmos_grid_cartesc_index::ka
integer, public ka
Definition: scale_atmos_grid_cartesC_index.F90:47
scale_atmos_grid_cartesc_index::js
integer, public js
start point of inner domain: y, local
Definition: scale_atmos_grid_cartesC_index.F90:55
scale_atmos_grid_cartesc_index::ydir
integer, parameter, public ydir
Definition: scale_atmos_grid_cartesC_index.F90:34
scale_atmos_grid_cartesc_index::ja
integer, public ja
Definition: scale_atmos_grid_cartesC_index.F90:49
scale_atmos_grid_cartesc_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_atmos_grid_cartesC_index.F90:52
scale_atmos_grid_cartesc_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_atmos_grid_cartesC_index.F90:51
scale_atmos_grid_cartesc_index::i_uyw
integer, public i_uyw
Definition: scale_atmos_grid_cartesC_index.F90:93
scale_atmos_grid_cartesc
module atmosphere / grid / cartesC
Definition: scale_atmos_grid_cartesC.F90:12
scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdy
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rfdy
reciprocal of face-dy
Definition: scale_atmos_grid_cartesC.F90:69
scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdx
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rcdx
reciprocal of center-dx
Definition: scale_atmos_grid_cartesC.F90:66
scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdx
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rfdx
reciprocal of face-dx
Definition: scale_atmos_grid_cartesC.F90:68
scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdz
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rcdz
reciprocal of center-dz
Definition: scale_atmos_grid_cartesC.F90:45
scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdy
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rcdy
reciprocal of center-dy
Definition: scale_atmos_grid_cartesC.F90:67
scale_atmos_grid_cartesc::atmos_grid_cartesc_fdz
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_fdz
z-length of grid(i+1) to grid(i) [m]
Definition: scale_atmos_grid_cartesC.F90:44
scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdz
real(rp), dimension(:), allocatable, public atmos_grid_cartesc_rfdz
reciprocal of face-dz
Definition: scale_atmos_grid_cartesC.F90:46
scale_atmos_phy_tb_common
module ATMOSPHERE / Physics Turbulence
Definition: scale_atmos_phy_tb_common.F90:12
scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momx
subroutine, public atmos_phy_tb_calc_tend_momx(MOMX_t_TB, QFLX_MOMX, GSQRT, J13G, J23G, J33G, MAPF, IIS, IIE, JJS, JJE)
Definition: scale_atmos_phy_tb_common.F90:1679
scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momz
subroutine, public atmos_phy_tb_calc_tend_momz(MOMZ_t_TB, QFLX_MOMZ, GSQRT, J13G, J23G, J33G, MAPF, IIS, IIE, JJS, JJE)
Definition: scale_atmos_phy_tb_common.F90:1616
scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_phi
subroutine, public atmos_phy_tb_calc_tend_phi(phi_t_TB, QFLX_phi, GSQRT, J13G, J23G, J33G, MAPF, IIS, IIE, JJS, JJE)
Definition: scale_atmos_phy_tb_common.F90:1804
scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momy
subroutine, public atmos_phy_tb_calc_tend_momy(MOMY_t_TB, QFLX_MOMY, GSQRT, J13G, J23G, J33G, MAPF, IIS, IIE, JJS, JJE)
Definition: scale_atmos_phy_tb_common.F90:1741
scale_atmos_phy_tb_common::atmos_phy_tb_calc_flux_phi
subroutine, public atmos_phy_tb_calc_flux_phi(qflx_phi, DENS, PHI, Kh, FACT, GSQRT, J13G, J23G, J33G, MAPF, horizontal, implicit, a, b, c, dt, IIS, IIE, JJS, JJE)
Definition: scale_atmos_phy_tb_common.F90:1337
scale_atmos_phy_tb_common::atmos_phy_tb_calc_strain_tensor
subroutine, public atmos_phy_tb_calc_strain_tensor(S33_C, S11_C, S22_C, S31_C, S12_C, S23_C, S12_Z, S23_X, S31_Y, S2, DENS, MOMZ, MOMX, MOMY, GSQRT, J13G, J23G, J33G, MAPF)
Definition: scale_atmos_phy_tb_common.F90:66
scale_const
module CONSTANT
Definition: scale_const.F90:11
scale_const::const_grav
real(rp), public const_grav
standard acceleration of gravity [m/s2]
Definition: scale_const.F90:49
scale_matrix
module MATRIX
Definition: scale_matrix.F90:17
scale_precision
module PRECISION
Definition: scale_precision.F90:14
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:41
scale_tracer::tracer_advc
logical, dimension(qa_max), public tracer_advc
Definition: scale_tracer.F90:46
scale_tracer::k
real(rp), public k
Definition: scale_tracer.F90:45
scale_tracer::qa
integer, public qa
Definition: scale_tracer.F90:35

References scale_atmos_grid_cartesc::atmos_grid_cartesc_fdz, scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdx, scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdy, scale_atmos_grid_cartesc::atmos_grid_cartesc_rcdz, scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdx, scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdy, scale_atmos_grid_cartesc::atmos_grid_cartesc_rfdz, scale_atmos_phy_tb_common::atmos_phy_tb_calc_flux_phi(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_strain_tensor(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momx(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momy(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_momz(), scale_atmos_phy_tb_common::atmos_phy_tb_calc_tend_phi(), scale_debug::check(), scale_const::const_grav, scale_atmos_grid_cartesc_index::i_uyw, scale_atmos_grid_cartesc_index::i_uyz, scale_atmos_grid_cartesc_index::i_xvw, scale_atmos_grid_cartesc_index::i_xvz, scale_atmos_grid_cartesc_index::i_xyw, scale_atmos_grid_cartesc_index::i_xyz, scale_atmos_grid_cartesc_index::ia, scale_atmos_grid_cartesc_index::iblock, scale_atmos_grid_cartesc_index::ie, scale_atmos_grid_cartesc_index::is, scale_atmos_grid_cartesc_index::ja, scale_atmos_grid_cartesc_index::jblock, scale_atmos_grid_cartesc_index::je, scale_atmos_grid_cartesc_index::js, scale_tracer::k, scale_atmos_grid_cartesc_index::ka, scale_atmos_grid_cartesc_index::ke, scale_atmos_grid_cartesc_index::ks, scale_tracer::qa, scale_tracer::tracer_advc, scale_atmos_grid_cartesc_index::xdir, scale_atmos_grid_cartesc_index::ydir, and scale_atmos_grid_cartesc_index::zdir.

Referenced by mod_atmos_phy_tb_driver::atmos_phy_tb_driver_calc_tendency().

Here is the call graph for this function:
Here is the caller graph for this function:
Generated by doxygen 1.9.1
