scale_fileio Module Reference

module FILE I/O (netcdf) More...

Functions/Subroutines

subroutine, public fileio_setup
 Setup. More...

subroutine, public fileio_set_coordinates (LON, LONX, LONY, LONXY, LAT, LATX, LATY, LATXY, CZ, FZ)
 set latlon and z More...

subroutine, public fileio_set_axes (fid, dtype, xy)
 write axis to the file More...

subroutine fileio_read_1d (var, basename, varname, axistype, step)
 Read 1D data from file. More...

subroutine fileio_read_2d (var, basename, varname, axistype, step)
 Read 2D data from file. More...

subroutine fileio_read_3d (var, basename, varname, axistype, step)
 Read 3D data from file. More...

subroutine fileio_read_4d (var, basename, varname, axistype, step)
 Read 4D data from file. More...

subroutine fileio_write_1d (var, basename, title, varname, desc, unit, axistype, datatype, date, subsec, append)
 Write 1D data to file. More...

subroutine fileio_write_2d (var, basename, title, varname, desc, unit, axistype, datatype, date, subsec, append, nohalo, nozcoord)
 Write 2D data to file. More...

subroutine fileio_write_3d (var, basename, title, varname, desc, unit, axistype, datatype, date, subsec, append, nohalo)
 Write 3D data to file. More...

subroutine fileio_write_3d_t (var, basename, title, varname, desc, unit, axistype, datatype, timeintv, tsince, append, timetarg, nohalo)
 Write 3D data with time dimension to file. More...

subroutine fileio_write_4d (var, basename, title, varname, desc, unit, axistype, datatype, timeintv, tsince, append, timetarg, nohalo)
 Write 4D data to file. More...

subroutine getcftunits (tunits, date)


Detailed Description

module FILE I/O (netcdf)

Description
general file I/O module frontend interface of netCDF I/O routine
Author
Team SCALE
History
  • 2013-02-20 (H.Yashiro) [new]

Function/Subroutine Documentation

◆ fileio_setup()

subroutine, public scale_fileio::fileio_setup ( )

Setup.

Definition at line 78 of file scale_fileio.F90.

References scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::imaxb, scale_stdio::io_fid_log, scale_stdio::io_l, and scale_grid_index::jmaxb.

Referenced by mod_rm_driver::scalerm(), and mod_rm_prep::scalerm_prep().

78  implicit none
79  !---------------------------------------------------------------------------
80
81  if( io_l ) write(io_fid_log,*)
82  if( io_l ) write(io_fid_log,*) '++++++ Module[FIELIO] / Categ[ATMOS-RM IO] / Origin[SCALElib]'
83  if( io_l ) write(io_fid_log,*) '*** No namelists.'
84  if( io_l ) write(io_fid_log,*)
85  if( io_l ) write(io_fid_log,*) '*** NetCDF header information ***'
86  if( io_l ) write(io_fid_log,*) '*** Data source : ', trim(h_source)
87  if( io_l ) write(io_fid_log,*) '*** Institute : ', trim(h_institute)
88
89  allocate( axis_lon(imaxb,jmaxb) )
90  allocate( axis_lonx(imaxb,jmaxb) )
91  allocate( axis_lony(imaxb,jmaxb) )
92  allocate( axis_lonxy(imaxb,jmaxb) )
93  allocate( axis_lat(imaxb,jmaxb) )
94  allocate( axis_latx(imaxb,jmaxb) )
95  allocate( axis_laty(imaxb,jmaxb) )
96  allocate( axis_latxy(imaxb,jmaxb) )
97
98  return
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
Here is the caller graph for this function:

◆ fileio_set_coordinates()

subroutine, public scale_fileio::fileio_set_coordinates ( real(rp), dimension (ia,ja), intent(in)  LON,
real(rp), dimension(ia,ja), intent(in)  LONX,
real(rp), dimension(ia,ja), intent(in)  LONY,
real(rp), dimension(ia,ja), intent(in)  LONXY,
real(rp), dimension (ia,ja), intent(in)  LAT,
real(rp), dimension(ia,ja), intent(in)  LATX,
real(rp), dimension(ia,ja), intent(in)  LATY,
real(rp), dimension(ia,ja), intent(in)  LATXY,
real(rp), dimension ( ka,ia,ja), intent(in)  CZ,
real(rp), dimension (0:ka,ia,ja), intent(in)  FZ
)

set latlon and z

Definition at line 114 of file scale_fileio.F90.

References scale_const::const_d2r, scale_grid_index::ieb, scale_grid_index::isb, scale_grid_index::jeb, and scale_grid_index::jsb.

Referenced by scale_grid_real::real_setup(), and scale_grid_real::real_update_z().

114  use scale_const, only: &
115  d2r => const_d2r
116  implicit none
117
118  real(RP), intent(in) :: lon (ia,ja)
119  real(RP), intent(in) :: lonx(ia,ja)
120  real(RP), intent(in) :: lony(ia,ja)
121  real(RP), intent(in) :: lonxy(ia,ja)
122  real(RP), intent(in) :: lat (ia,ja)
123  real(RP), intent(in) :: latx(ia,ja)
124  real(RP), intent(in) :: laty(ia,ja)
125  real(RP), intent(in) :: latxy(ia,ja)
126  real(RP), intent(in) :: cz ( ka,ia,ja)
127  real(RP), intent(in) :: fz (0:ka,ia,ja)
128  !---------------------------------------------------------------------------
129
130  axis_lon(:,:) = lon(isb:ieb,jsb:jeb) / d2r
131  axis_lonx(:,:) = lonx(isb:ieb,jsb:jeb) / d2r
132  axis_lony(:,:) = lony(isb:ieb,jsb:jeb) / d2r
133  axis_lonxy(:,:) = lonxy(isb:ieb,jsb:jeb) / d2r
134  axis_lat(:,:) = lat(isb:ieb,jsb:jeb) / d2r
135  axis_latx(:,:) = latx(isb:ieb,jsb:jeb) / d2r
136  axis_laty(:,:) = laty(isb:ieb,jsb:jeb) / d2r
137  axis_latxy(:,:) = latxy(isb:ieb,jsb:jeb) / d2r
138
139  return
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_const::const_d2r
real(rp), public const_d2r
degree to radian
Definition: scale_const.F90:35
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::ia
integer, public ia
of x whole cells (local, with HALO)
Definition: scale_grid_index.F90:55
scale_grid_index::ka
integer, public ka
of z whole cells (local, with HALO)
Definition: scale_grid_index.F90:54
scale_const
module CONSTANT
Definition: scale_const.F90:14
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_grid_index::ja
integer, public ja
of y whole cells (local, with HALO)
Definition: scale_grid_index.F90:56
Here is the caller graph for this function:

◆ fileio_set_axes()

subroutine, public scale_fileio::fileio_set_axes ( integer, intent(in)  fid,
integer, intent(in)  dtype,
logical, intent(in), optional  xy
)

write axis to the file

Definition at line 148 of file scale_fileio.F90.

References gtool_file::filesettattr(), scale_grid::grid_cbfx, scale_grid::grid_cbfxg, scale_grid::grid_cbfy, scale_grid::grid_cbfyg, scale_grid::grid_cbfz, scale_grid::grid_cdx, scale_grid::grid_cdy, scale_grid::grid_cdz, scale_grid::grid_cx, scale_grid::grid_cxg, scale_grid::grid_cy, scale_grid::grid_cyg, scale_grid::grid_cz, scale_grid::grid_fbfx, scale_grid::grid_fbfxg, scale_grid::grid_fbfy, scale_grid::grid_fbfyg, scale_grid::grid_fbfz, scale_grid::grid_fdx, scale_grid::grid_fdy, scale_grid::grid_fdz, scale_grid::grid_fx, scale_grid::grid_fxg, scale_grid::grid_fy, scale_grid::grid_fyg, scale_grid::grid_fz, scale_land_grid::grid_lcz, scale_land_grid::grid_lfz, scale_urban_grid::grid_ucz, scale_urban_grid::grid_ufz, scale_grid_index::ieb, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::ks, scale_land_grid_index::lke, scale_land_grid_index::lks, scale_urban_grid_index::uke, and scale_urban_grid_index::uks.

Referenced by fileio_write_1d(), fileio_write_2d(), fileio_write_3d(), fileio_write_3d_t(), and fileio_write_4d().

148  use gtool_file, only: &
149  fileputaxis, &
150  filesettattr, &
151  fileputassociatedcoordinates
152  use scale_grid, only: &
153  grid_cz, &
154  grid_cx, &
155  grid_cy, &
156  grid_fz, &
157  grid_fx, &
158  grid_fy, &
159  grid_cdz, &
160  grid_cdx, &
161  grid_cdy, &
162  grid_fdz, &
163  grid_fdx, &
164  grid_fdy, &
165  grid_cbfz, &
166  grid_cbfx, &
167  grid_cbfy, &
168  grid_fbfz, &
169  grid_fbfx, &
170  grid_fbfy, &
171  grid_cxg, &
172  grid_cyg, &
173  grid_fxg, &
174  grid_fyg, &
175  grid_cbfxg, &
176  grid_cbfyg, &
177  grid_fbfxg, &
178  grid_fbfyg
179  use scale_land_grid, only: &
180  grid_lcz, &
181  grid_lfz
182  use scale_urban_grid, only: &
183  grid_ucz, &
184  grid_ufz
185  implicit none
186
187  integer, intent(in) :: fid
188  integer, intent(in) :: dtype
189  logical, intent(in), optional :: xy
190
191  character(len=2) :: axis_name(2)
192  logical :: xy_
193  !---------------------------------------------------------------------------
194
195  if ( present(xy) ) then
196  xy_ = xy
197  else
198  xy_ = .false.
199  end if
200
201  if ( .NOT. xy_ ) then
202  call fileputaxis( fid, 'z', 'Z', 'm', 'z', dtype, grid_cz(ks:ke) )
203  end if
204  call fileputaxis( fid, 'x', 'X', 'm', 'x', dtype, grid_cx(isb:ieb) )
205  call fileputaxis( fid, 'y', 'Y', 'm', 'y', dtype, grid_cy(jsb:jeb) )
206  if ( .NOT. xy_ ) then
207  call fileputaxis( fid, 'zh', 'Z (half level)', 'm', 'zh', dtype, grid_fz(ks:ke) )
208  end if
209  call fileputaxis( fid, 'xh', 'X (half level)', 'm', 'xh', dtype, grid_fx(isb:ieb) )
210  call fileputaxis( fid, 'yh', 'Y (half level)', 'm', 'yh', dtype, grid_fy(jsb:jeb) )
211
212  if ( .NOT. xy_ ) then
213  call fileputaxis( fid, 'lz', 'LZ', 'm', 'lz', dtype, grid_lcz(lks:lke) )
214  call fileputaxis( fid, 'lzh', 'LZ (half level)', 'm', 'lzh', dtype, grid_lfz(lks:lke) )
215  call fileputaxis( fid, 'uz', 'UZ', 'm', 'uz', dtype, grid_ucz(uks:uke) )
216  call fileputaxis( fid, 'uzh', 'UZ (half level)', 'm', 'uzh', dtype, grid_ufz(uks:uke) )
217  end if
218
219
220  if ( .NOT. xy_ ) then
221  call fileputaxis( fid, 'CZ', 'Atmos Grid Center Position Z', 'm', 'CZ', dtype, grid_cz )
222  end if
223  call fileputaxis( fid, 'CX', 'Atmos Grid Center Position X', 'm', 'CX', dtype, grid_cx )
224  call fileputaxis( fid, 'CY', 'Atmos Grid Center Position Y', 'm', 'CY', dtype, grid_cy )
225  if ( .NOT. xy_ ) then
226  call fileputaxis( fid, 'FZ', 'Atmos Grid Face Position Z', 'm', 'FZ', dtype, grid_fz )
227  end if
228  call fileputaxis( fid, 'FX', 'Atmos Grid Face Position X', 'm', 'FX', dtype, grid_fx )
229  call fileputaxis( fid, 'FY', 'Atmos Grid Face Position Y', 'm', 'FY', dtype, grid_fy )
230
231  if ( .NOT. xy_ ) then
232  call fileputaxis( fid, 'CDZ', 'Grid Cell length Z', 'm', 'CZ', dtype, grid_cdz )
233  end if
234  call fileputaxis( fid, 'CDX', 'Grid Cell length X', 'm', 'CX', dtype, grid_cdx )
235  call fileputaxis( fid, 'CDY', 'Grid Cell length Y', 'm', 'CY', dtype, grid_cdy )
236  if ( .NOT. xy_ ) then
237  call fileputaxis( fid, 'FDZ', 'Grid distance Z', 'm', 'FDZ', dtype, grid_fdz )
238  end if
239  call fileputaxis( fid, 'FDX', 'Grid distance X', 'm', 'FDX', dtype, grid_fdx )
240  call fileputaxis( fid, 'FDY', 'Grid distance Y', 'm', 'FDY', dtype, grid_fdy )
241
242  if ( .NOT. xy_ ) then
243  call fileputaxis( fid, 'LCZ', 'Land Grid Center Position Z', 'm', 'LCZ', dtype, grid_lcz )
244  call fileputaxis( fid, 'LFZ', 'Land Grid Face Position Z', 'm', 'LFZ', dtype, grid_lfz )
245  call fileputaxis( fid, 'LCDZ', 'Land Grid Cell length Z', 'm', 'LCZ', dtype, grid_lcz )
246
247  call fileputaxis( fid, 'UCZ', 'Urban Grid Center Position Z', 'm', 'UCZ', dtype, grid_ucz )
248  call fileputaxis( fid, 'UFZ', 'Urban Grid Face Position Z', 'm', 'UFZ', dtype, grid_ufz )
249  call fileputaxis( fid, 'UCDZ', 'Urban Grid Cell length Z', 'm', 'UCZ', dtype, grid_ucz )
250  end if
251
252  if ( .NOT. xy_ ) then
253  call fileputaxis( fid, 'CBFZ', 'Boundary factor Center Z', '1', 'CZ', dtype, grid_cbfz )
254  end if
255  call fileputaxis( fid, 'CBFX', 'Boundary factor Center X', '1', 'CX', dtype, grid_cbfx )
256  call fileputaxis( fid, 'CBFY', 'Boundary factor Center Y', '1', 'CY', dtype, grid_cbfy )
257  if ( .NOT. xy_ ) then
258  call fileputaxis( fid, 'FBFZ', 'Boundary factor Face Z', '1', 'CZ', dtype, grid_fbfz )
259  end if
260  call fileputaxis( fid, 'FBFX', 'Boundary factor Face X', '1', 'CX', dtype, grid_fbfx )
261  call fileputaxis( fid, 'FBFY', 'Boundary factor Face Y', '1', 'CY', dtype, grid_fbfy )
262
263  call fileputaxis( fid, 'CXG', 'Grid Center Position X (global)', 'm', 'CXG', dtype, grid_cxg )
264  call fileputaxis( fid, 'CYG', 'Grid Center Position Y (global)', 'm', 'CYG', dtype, grid_cyg )
265  call fileputaxis( fid, 'FXG', 'Grid Face Position X (global)', 'm', 'FXG', dtype, grid_fxg )
266  call fileputaxis( fid, 'FYG', 'Grid Face Position Y (global)', 'm', 'FYG', dtype, grid_fyg )
267
268  call fileputaxis( fid, 'CBFXG', 'Boundary factor Center X (global)', '1', 'CXG', dtype, grid_cbfxg )
269  call fileputaxis( fid, 'CBFYG', 'Boundary factor Center Y (global)', '1', 'CYG', dtype, grid_cbfyg )
270  call fileputaxis( fid, 'FBFXG', 'Boundary factor Face X (global)', '1', 'CXG', dtype, grid_fbfxg )
271  call fileputaxis( fid, 'FBFYG', 'Boundary factor Face Y (global)', '1', 'CYG', dtype, grid_fbfyg )
272
273
274  ! associate coordinates
275  axis_name = (/'x ','y '/)
276  call fileputassociatedcoordinates( fid, 'lon' , 'longitude' , &
277  'degrees_east' , axis_name, dtype, axis_lon(:,:) )
278  axis_name = (/'xh','y '/)
279  call fileputassociatedcoordinates( fid, 'lon_uy', 'longitude (half level uy)', &
280  'degrees_east' , axis_name, dtype, axis_lonx(:,:) )
281  axis_name = (/'x ','yh'/)
282  call fileputassociatedcoordinates( fid, 'lon_xv', 'longitude (half level xv)', &
283  'degrees_east' , axis_name, dtype, axis_lony(:,:) )
284  axis_name = (/'xh','yh'/)
285  call fileputassociatedcoordinates( fid, 'lon_uv', 'longitude (half level uv)', &
286  'degrees_east' , axis_name, dtype, axis_lonxy(:,:) )
287  axis_name = (/'x ','y '/)
288  call fileputassociatedcoordinates( fid, 'lat' , 'latitude' , &
289  'degrees_north', axis_name, dtype, axis_lat(:,:) )
290  axis_name = (/'xh','y '/)
291  call fileputassociatedcoordinates( fid, 'lat_uy', 'latitude (half level uy)' , &
292  'degrees_north', axis_name, dtype, axis_latx(:,:) )
293  axis_name = (/'x ','yh'/)
294  call fileputassociatedcoordinates( fid, 'lat_xv', 'latitude (half level xv)' , &
295  'degrees_north', axis_name, dtype, axis_laty(:,:) )
296  axis_name = (/'xh','yh'/)
297  call fileputassociatedcoordinates( fid, 'lat_uv', 'latitude (half level uv)' , &
298  'degrees_north', axis_name, dtype, axis_latxy(:,:) )
299
300  ! attributes
301  if ( .NOT. xy_ ) then
302  call filesettattr( fid, 'lz', 'positive', 'down' )
303  call filesettattr( fid, 'lzh', 'positive', 'down' )
304  call filesettattr( fid, 'uz', 'positive', 'down' )
305  call filesettattr( fid, 'uzh', 'positive', 'down' )
306  call filesettattr( fid, 'LCZ', 'positive', 'down' )
307  call filesettattr( fid, 'LFZ', 'positive', 'down' )
308  call filesettattr( fid, 'UCZ', 'positive', 'down' )
309  call filesettattr( fid, 'UFZ', 'positive', 'down' )
310  end if
311
312  return
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_grid::grid_cyg
real(rp), dimension(:), allocatable, public grid_cyg
center coordinate [m]: y, global
Definition: scale_grid_cartesian.F90:83
scale_grid::grid_cbfyg
real(rp), dimension(:), allocatable, public grid_cbfyg
center buffer factor [0-1]: y, global
Definition: scale_grid_cartesian.F90:87
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_grid::grid_cxg
real(rp), dimension(:), allocatable, public grid_cxg
center coordinate [m]: x, global
Definition: scale_grid_cartesian.F90:82
scale_grid::grid_fdy
real(rp), dimension(:), allocatable, public grid_fdy
y-length of grid(j+1) to grid(j) [m]
Definition: scale_grid_cartesian.F90:68
scale_grid::grid_cz
real(rp), dimension(:), allocatable, public grid_cz
center coordinate [m]: z, local=global
Definition: scale_grid_cartesian.F90:53
scale_grid::grid_fxg
real(rp), dimension(:), allocatable, public grid_fxg
face coordinate [m]: x, global
Definition: scale_grid_cartesian.F90:80
scale_grid::grid_fbfy
real(rp), dimension(:), allocatable, public grid_fbfy
face buffer factor [0-1]: y
Definition: scale_grid_cartesian.F90:78
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_land_grid
module GRID (cartesian) for land
Definition: scale_land_grid.F90:13
scale_grid::grid_fx
real(rp), dimension(:), allocatable, public grid_fx
face coordinate [m]: x, local
Definition: scale_grid_cartesian.F90:64
scale_land_grid::grid_lfz
real(rp), dimension(:), allocatable, public grid_lfz
face coordinate [m]: z, local=global
Definition: scale_land_grid.F90:37
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_urban_grid
module GRID (cartesian) for urban
Definition: scale_urban_grid.F90:13
scale_grid::grid_fbfx
real(rp), dimension(:), allocatable, public grid_fbfx
face buffer factor [0-1]: x
Definition: scale_grid_cartesian.F90:77
scale_grid::grid_fdz
real(rp), dimension(:), allocatable, public grid_fdz
z-length of grid(k+1) to grid(k) [m]
Definition: scale_grid_cartesian.F90:66
scale_urban_grid::grid_ufz
real(rp), dimension(:), allocatable, public grid_ufz
face coordinate [m]: z, local=global
Definition: scale_urban_grid.F90:37
scale_grid::grid_fbfxg
real(rp), dimension(:), allocatable, public grid_fbfxg
face buffer factor [0-1]: x, global
Definition: scale_grid_cartesian.F90:84
gtool_file::filesettattr
subroutine, public filesettattr(fid, vname, key, val)
Definition: gtool_file.f90:942
scale_grid::grid_fz
real(rp), dimension(:), allocatable, public grid_fz
face coordinate [m]: z, local=global
Definition: scale_grid_cartesian.F90:63
scale_grid::grid_fbfz
real(rp), dimension(:), allocatable, public grid_fbfz
face buffer factor [0-1]: z
Definition: scale_grid_cartesian.F90:76
scale_grid::grid_cbfx
real(rp), dimension(:), allocatable, public grid_cbfx
center buffer factor [0-1]: x
Definition: scale_grid_cartesian.F90:74
scale_grid::grid_fbfyg
real(rp), dimension(:), allocatable, public grid_fbfyg
face buffer factor [0-1]: y, global
Definition: scale_grid_cartesian.F90:85
scale_urban_grid::grid_ucz
real(rp), dimension(:), allocatable, public grid_ucz
center coordinate [m]: z, local=global
Definition: scale_urban_grid.F90:36
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_grid::grid_cbfz
real(rp), dimension(:), allocatable, public grid_cbfz
center buffer factor [0-1]: z
Definition: scale_grid_cartesian.F90:73
scale_grid::grid_cx
real(rp), dimension(:), allocatable, public grid_cx
center coordinate [m]: x, local
Definition: scale_grid_cartesian.F90:54
scale_grid
module GRID (cartesian)
Definition: scale_grid_cartesian.F90:17
scale_grid::grid_cdz
real(rp), dimension(:), allocatable, public grid_cdz
z-length of control volume [m]
Definition: scale_grid_cartesian.F90:56
scale_grid::grid_fdx
real(rp), dimension(:), allocatable, public grid_fdx
x-length of grid(i+1) to grid(i) [m]
Definition: scale_grid_cartesian.F90:67
scale_land_grid::grid_lcz
real(rp), dimension(:), allocatable, public grid_lcz
center coordinate [m]: z, local=global
Definition: scale_land_grid.F90:36
scale_grid::grid_cdy
real(rp), dimension(:), allocatable, public grid_cdy
y-length of control volume [m]
Definition: scale_grid_cartesian.F90:58
scale_grid::grid_cbfy
real(rp), dimension(:), allocatable, public grid_cbfy
center buffer factor [0-1]: y
Definition: scale_grid_cartesian.F90:75
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_grid::grid_cdx
real(rp), dimension(:), allocatable, public grid_cdx
x-length of control volume [m]
Definition: scale_grid_cartesian.F90:57
scale_grid::grid_fyg
real(rp), dimension(:), allocatable, public grid_fyg
face coordinate [m]: y, global
Definition: scale_grid_cartesian.F90:81
scale_grid::grid_cy
real(rp), dimension(:), allocatable, public grid_cy
center coordinate [m]: y, local
Definition: scale_grid_cartesian.F90:55
scale_grid::grid_cbfxg
real(rp), dimension(:), allocatable, public grid_cbfxg
center buffer factor [0-1]: x, global
Definition: scale_grid_cartesian.F90:86
scale_grid::grid_fy
real(rp), dimension(:), allocatable, public grid_fy
face coordinate [m]: y, local
Definition: scale_grid_cartesian.F90:65
Here is the call graph for this function:
Here is the caller graph for this function:

◆ fileio_read_1d()

subroutine scale_fileio::fileio_read_1d ( real(rp), dimension(:), intent(out)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  axistype,
integer, intent(in)  step
)

Read 1D data from file.

Parameters
[out]varvalue of the variable
[in]basenamebasename of the file
[in]varnamename of the variable
[in]axistypeaxis type (Z/X/Y)
[in]stepstep number

Definition at line 323 of file scale_fileio.F90.

References scale_grid_index::ieb, scale_grid_index::imaxb, scale_stdio::io_fid_log, scale_stdio::io_l, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), and scale_prof::prof_rapstart().

323  use gtool_file, only: &
324  fileread
325  use scale_process, only: &
326  prc_myrank, &
327  prc_mpistop
328  implicit none
329
330  real(RP), intent(out) :: var(:)
331  character(len=*), intent(in) :: basename
332  character(len=*), intent(in) :: varname
333  character(len=*), intent(in) :: axistype
334  integer, intent(in) :: step
335
336  integer :: dim1_max, dim1_s, dim1_e
337  real(RP), allocatable :: var1d(:)
338  !---------------------------------------------------------------------------
339
340  call prof_rapstart('FILE_I_NetCDF', 2)
341
342  if( io_l ) write(io_fid_log,'(1x,A,A15)') '*** Read 1D var: ', trim(varname)
343
344  if ( axistype == 'Z' ) then
345  dim1_max = kmax
346  dim1_s = ks
347  dim1_e = ke
348  elseif( axistype == 'X' ) then
349  dim1_max = imaxb
350  dim1_s = isb
351  dim1_e = ieb
352  elseif( axistype == 'Y' ) then
353  dim1_max = jmaxb
354  dim1_s = jsb
355  dim1_e = jeb
356  else
357  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
358  call prc_mpistop
359  endif
360
361  allocate( var1d(dim1_max) )
362
363  call fileread( var1d(:), basename, varname, step, prc_myrank )
364  var(dim1_s:dim1_e) = var1d(1:dim1_max)
365
366  deallocate( var1d )
367
368  call prof_rapend ('FILE_I_NetCDF', 2)
369
370  return
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
Here is the call graph for this function:

◆ fileio_read_2d()

subroutine scale_fileio::fileio_read_2d ( real(rp), dimension(:,:), intent(out)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  axistype,
integer, intent(in)  step
)

Read 2D data from file.

Parameters
[out]varvalue of the variable
[in]basenamebasename of the file
[in]varnamename of the variable
[in]axistypeaxis type (Z/X/Y)
[in]stepstep number

Definition at line 381 of file scale_fileio.F90.

References scale_grid_index::ieb, scale_grid_index::imaxb, scale_stdio::io_fid_log, scale_stdio::io_l, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), and scale_prof::prof_rapstart().

381  use gtool_file, only: &
382  fileread
383  use scale_process, only: &
384  prc_myrank, &
385  prc_mpistop
386  implicit none
387
388  real(RP), intent(out) :: var(:,:)
389  character(len=*), intent(in) :: basename
390  character(len=*), intent(in) :: varname
391  character(len=*), intent(in) :: axistype
392  integer, intent(in) :: step
393
394  integer :: dim1_max, dim1_s, dim1_e
395  integer :: dim2_max, dim2_s, dim2_e
396  real(RP), allocatable :: var2d(:,:)
397  !---------------------------------------------------------------------------
398
399  call prof_rapstart('FILE_I_NetCDF', 2)
400
401  if( io_l ) write(io_fid_log,'(1x,A,A15)') '*** Read 2D var: ', trim(varname)
402
403  if ( axistype == 'XY' ) then
404  dim1_max = imaxb
405  dim2_max = jmaxb
406  dim1_s = isb
407  dim1_e = ieb
408  dim2_s = jsb
409  dim2_e = jeb
410  elseif( axistype == 'ZX' ) then
411  dim1_max = kmax
412  dim2_max = imaxb
413  dim1_s = ks
414  dim1_e = ke
415  dim2_s = isb
416  dim2_e = ieb
417  else
418  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
419  call prc_mpistop
420  endif
421
422  allocate( var2d(dim1_max,dim2_max) )
423
424  call fileread( var2d(:,:), basename, varname, step, prc_myrank )
425  var(dim1_s:dim1_e,dim2_s:dim2_e) = var2d(1:dim1_max,1:dim2_max)
426
427  deallocate( var2d )
428
429  call prof_rapend ('FILE_I_NetCDF', 2)
430
431  return
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
Here is the call graph for this function:

◆ fileio_read_3d()

subroutine scale_fileio::fileio_read_3d ( real(rp), dimension(:,:,:), intent(out)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  axistype,
integer, intent(in)  step
)

Read 3D data from file.

Parameters
[out]varvalue of the variable
[in]basenamebasename of the file
[in]varnamename of the variable
[in]axistypeaxis type (Z/X/Y/T)
[in]stepstep number

Definition at line 442 of file scale_fileio.F90.

References scale_grid_index::ieb, scale_grid_index::imaxb, scale_stdio::io_fid_log, scale_stdio::io_l, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_land_grid_index::lke, scale_land_grid_index::lkmax, scale_land_grid_index::lks, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), scale_urban_grid_index::uke, scale_urban_grid_index::ukmax, and scale_urban_grid_index::uks.

442  use gtool_file, only: &
443  fileread
444  use scale_process, only: &
445  prc_myrank, &
446  prc_mpistop
447  implicit none
448
449  real(RP), intent(out) :: var(:,:,:)
450  character(len=*), intent(in) :: basename
451  character(len=*), intent(in) :: varname
452  character(len=*), intent(in) :: axistype
453  integer, intent(in) :: step
454
455  integer :: dim1_max, dim1_s, dim1_e
456  integer :: dim2_max, dim2_s, dim2_e
457  integer :: dim3_max, dim3_s, dim3_e
458  real(RP), allocatable :: var3d(:,:,:)
459  !---------------------------------------------------------------------------
460
461  call prof_rapstart('FILE_I_NetCDF', 2)
462
463  if( io_l ) write(io_fid_log,'(1x,A,A15)') '*** Read 3D var: ', trim(varname)
464
465  if ( axistype == 'ZXY' ) then
466  dim1_max = kmax
467  dim2_max = imaxb
468  dim3_max = jmaxb
469  dim1_s = ks
470  dim1_e = ke
471  dim2_s = isb
472  dim2_e = ieb
473  dim3_s = jsb
474  dim3_e = jeb
475  else if ( axistype == 'XYT' ) then
476  dim1_max = imaxb
477  dim2_max = jmaxb
478  dim3_max = step
479  dim1_s = isb
480  dim1_e = ieb
481  dim2_s = jsb
482  dim2_e = jeb
483  dim3_s = 1
484  dim3_e = step
485  else if ( axistype == 'Land' ) then
486  dim1_max = lkmax
487  dim2_max = imaxb
488  dim3_max = jmaxb
489  dim1_s = lks
490  dim1_e = lke
491  dim2_s = isb
492  dim2_e = ieb
493  dim3_s = jsb
494  dim3_e = jeb
495  else if ( axistype == 'Urban' ) then
496  dim1_max = ukmax
497  dim2_max = imaxb
498  dim3_max = jmaxb
499  dim1_s = uks
500  dim1_e = uke
501  dim2_s = isb
502  dim2_e = ieb
503  dim3_s = jsb
504  dim3_e = jeb
505  else
506  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
507  call prc_mpistop
508  endif
509
510  allocate( var3d(dim1_max,dim2_max,dim3_max) )
511
512  call fileread( var3d(:,:,:), basename, varname, step, prc_myrank )
513  var(dim1_s:dim1_e,dim2_s:dim2_e,dim3_s:dim3_e) = var3d(1:dim1_max,1:dim2_max,1:dim3_max)
514
515  deallocate( var3d )
516
517  call prof_rapend ('FILE_I_NetCDF', 2)
518
519  return
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
Here is the call graph for this function:

◆ fileio_read_4d()

subroutine scale_fileio::fileio_read_4d ( real(rp), dimension(:,:,:,:), intent(out)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  axistype,
integer, intent(in)  step
)

Read 4D data from file.

Parameters
[out]varvalue of the variable
[in]basenamebasename of the file
[in]varnamename of the variable
[in]axistypeaxis type (Z/X/Y/Time)
[in]stepstep number

Definition at line 530 of file scale_fileio.F90.

References scale_grid_index::ieb, scale_grid_index::imaxb, scale_stdio::io_fid_log, scale_stdio::io_l, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), and scale_prof::prof_rapstart().

530  use gtool_file, only: &
531  fileread
532  use scale_process, only: &
533  prc_myrank, &
534  prc_mpistop
535  implicit none
536
537  real(RP), intent(out) :: var(:,:,:,:)
538  character(len=*), intent(in) :: basename
539  character(len=*), intent(in) :: varname
540  character(len=*), intent(in) :: axistype
541  integer, intent(in) :: step
542
543  integer :: dim1_max, dim1_s, dim1_e
544  integer :: dim2_max, dim2_s, dim2_e
545  integer :: dim3_max, dim3_s, dim3_e
546  integer :: dim4_max, dim4_s, dim4_e
547  real(RP), allocatable :: var4d(:,:,:,:)
548  !---------------------------------------------------------------------------
549
550  call prof_rapstart('FILE_I_NetCDF', 2)
551
552  if( io_l ) write(io_fid_log,'(1x,A,A15)') '*** Read 4D var: ', trim(varname)
553
554  if ( axistype == 'ZXYT' ) then
555  dim1_max = kmax
556  dim2_max = imaxb
557  dim3_max = jmaxb
558  dim4_max = step
559  dim1_s = ks
560  dim1_e = ke
561  dim2_s = isb
562  dim2_e = ieb
563  dim3_s = jsb
564  dim3_e = jeb
565  dim4_s = 1
566  dim4_e = step
567  else
568  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
569  call prc_mpistop
570  endif
571
572  allocate( var4d(dim1_max,dim2_max,dim3_max,dim4_max) )
573
574  call fileread( var4d(:,:,:,:), basename, varname, step, prc_myrank )
575  var(dim1_s:dim1_e,dim2_s:dim2_e,dim3_s:dim3_e,dim4_s:dim4_e) = var4d(1:dim1_max,1:dim2_max,1:dim3_max,1:dim4_max)
576
577  deallocate( var4d )
578
579  call prof_rapend ('FILE_I_NetCDF', 2)
580
581  return
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
Here is the call graph for this function:

◆ fileio_write_1d()

subroutine scale_fileio::fileio_write_1d ( real(rp), dimension(:), intent(in)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  title,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  desc,
character(len=*), intent(in)  unit,
character(len=*), intent(in)  axistype,
character(len=*), intent(in)  datatype,
integer, dimension(6), intent(in), optional  date,
real(dp), intent(in), optional  subsec,
logical, intent(in), optional  append
)

Write 1D data to file.

Parameters
[in]varvalue of the variable
[in]basenamebasename of the file
[in]titletitle of the file
[in]varnamename of the variable
[in]descdescription of the variable
[in]unitunit of the variable
[in]axistypeaxis type (Z/X/Y)
[in]datatypedata type (REAL8/REAL4/default)
[in]dateymdhms of the time
[in]subsecsubsec of the time
[in]appendswitch whether append existing file or not (default=false)

Definition at line 598 of file scale_fileio.F90.

References gtool_file_h::file_real4, gtool_file_h::file_real8, gtool_file::filecreate(), fileio_set_axes(), getcftunits(), scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::ieb, scale_grid_index::imaxb, scale_grid_index::isb, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_rm_process::prc_2drank, scale_process::prc_masterrank, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), scale_precision::rp, scale_time::time_nowdate, scale_time::time_nowdaysec, and scale_time::time_nowms.

598  use gtool_file_h, only: &
599  file_real8, &
600  file_real4
601  use gtool_file, only: &
602  filecreate, &
603  fileaddvariable, &
604  filesetglobalattribute, &
605  filewrite
606  use scale_process, only: &
607  prc_masterrank, &
608  prc_myrank, &
609  prc_mpistop
610  use scale_rm_process, only: &
611  prc_2drank
612  use scale_time, only: &
613  nowdate => time_nowdate, &
614  nowms => time_nowms, &
615  nowsec => time_nowdaysec
616  implicit none
617
618  real(RP), intent(in) :: var(:)
619  character(len=*), intent(in) :: basename
620  character(len=*), intent(in) :: title
621  character(len=*), intent(in) :: varname
622  character(len=*), intent(in) :: desc
623  character(len=*), intent(in) :: unit
624  character(len=*), intent(in) :: axistype
625  character(len=*), intent(in) :: datatype
626
627  integer, optional, intent(in) :: date(6)
628  real(DP),optional, intent(in) :: subsec
629  logical, optional, intent(in) :: append
630
631  integer :: dtype
632  character(len=2) :: dims(1)
633  integer :: dim1_max, dim1_s, dim1_e
634  real(RP), allocatable :: var1d(:)
635
636  integer :: rankidx(2)
637  logical :: fileexisted
638  integer :: fid, vid
639  character(len=34) :: tunits
640  !---------------------------------------------------------------------------
641
642  call prof_rapstart('FILE_O_NetCDF', 2)
643
644  rankidx(1) = prc_2drank(prc_myrank,1)
645  rankidx(2) = prc_2drank(prc_myrank,2)
646
647  if ( datatype == 'REAL8' ) then
648  dtype = file_real8
649  elseif( datatype == 'REAL4' ) then
650  dtype = file_real4
651  else
652  if ( rp == 8 ) then
653  dtype = file_real8
654  elseif( rp == 4 ) then
655  dtype = file_real4
656  else
657  write(*,*) 'xxx unsupported data type. Check!', trim(datatype), ' item:',trim(varname)
658  call prc_mpistop
659  endif
660  endif
661
662  call filecreate( fid, & ! [OUT]
663  fileexisted, & ! [OUT]
664  basename, & ! [IN]
665  title, & ! [IN]
666  h_source, & ! [IN]
667  h_institute, & ! [IN]
668  prc_masterrank, & ! [IN]
669  prc_myrank, & ! [IN]
670  rankidx, & ! [IN]
671  append = append ) ! [IN]
672
673  if ( .NOT. fileexisted ) then ! only once
674  call fileio_set_axes( fid, dtype ) ! [IN]
675  if ( present( subsec ) ) then
676  call filesetglobalattribute( fid, "time", (/subsec/) )
677  else
678  call filesetglobalattribute( fid, "time", (/nowms/) )
679  end if
680  if ( present( date ) ) then
681  call getcftunits(tunits, date)
682  else
683  call getcftunits(tunits, nowdate)
684  end if
685  call filesetglobalattribute( fid, "time_units", tunits )
686  endif
687
688  if ( axistype == 'Z' ) then
689  dims = (/'z'/)
690  dim1_max = kmax
691  dim1_s = ks
692  dim1_e = ke
693  elseif( axistype == 'X' ) then
694  dims = (/'x'/)
695  dim1_max = imaxb
696  dim1_s = isb
697  dim1_e = ieb
698  elseif( axistype == 'Y' ) then
699  dims = (/'y'/)
700  dim1_max = jmaxb
701  dim1_s = jsb
702  dim1_e = jeb
703  else
704  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
705  call prc_mpistop
706  endif
707
708  call fileaddvariable( vid, fid, varname, desc, unit, dims, dtype ) ! [IN]
709
710  allocate( var1d(dim1_max) )
711
712  var1d(1:dim1_max) = var(dim1_s:dim1_e)
713  call filewrite( fid, vid, var1d(:), nowsec, nowsec ) ! [IN]
714
715  deallocate( var1d )
716
717  call prof_rapend ('FILE_O_NetCDF', 2)
718
719  return
gtool_file::filecreate
subroutine, public filecreate(fid, existed, basename, title, source, institution, master, myrank, rankidx, single, time_units, append)
Definition: gtool_file.f90:150
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_time::time_nowms
real(dp), public time_nowms
subsecond part of current time [millisec]
Definition: scale_time.F90:66
scale_time::time_nowdaysec
real(dp), public time_nowdaysec
second of current time [sec]
Definition: scale_time.F90:69
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_time
module TIME
Definition: scale_time.F90:15
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_process::prc_masterrank
integer, parameter, public prc_masterrank
master process in each communicator
Definition: scale_process.F90:56
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_rm_process
module RM PROCESS
Definition: scale_rm_process.F90:10
scale_rm_process::prc_2drank
integer, dimension(:,:), allocatable, public prc_2drank
node index in 2D topology
Definition: scale_rm_process.F90:46
gtool_file_h::file_real4
integer, parameter, public file_real4
Definition: gtool_file_h.f90:43
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_time::time_nowdate
integer, dimension(6), public time_nowdate
current time [YYYY MM DD HH MM SS]
Definition: scale_time.F90:65
gtool_file_h
module FILE I/O HEADER
Definition: gtool_file_h.f90:14
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:38
gtool_file_h::file_real8
integer, parameter, public file_real8
Definition: gtool_file_h.f90:44
Here is the call graph for this function:

◆ fileio_write_2d()

subroutine scale_fileio::fileio_write_2d ( real(rp), dimension(:,:), intent(in)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  title,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  desc,
character(len=*), intent(in)  unit,
character(len=*), intent(in)  axistype,
character(len=*), intent(in)  datatype,
integer, dimension(6), intent(in), optional  date,
real(dp), intent(in), optional  subsec,
logical, intent(in), optional  append,
logical, intent(in), optional  nohalo,
logical, intent(in), optional  nozcoord
)

Write 2D data to file.

Parameters
[in]varvalue of the variable
[in]basenamebasename of the file
[in]titletitle of the file
[in]varnamename of the variable
[in]descdescription of the variable
[in]unitunit of the variable
[in]axistypeaxis type (Z/X/Y)
[in]datatypedata type (REAL8/REAL4/default)
[in]dateymdhms of the time
[in]subsecsubsec of the time
[in]appendswitch whether append existing file or not (default=false)
[in]nohaloswitch whether include halo data or not (default=false)
[in]nozcoordswitch whether include zcoordinate or not (default=false)

Definition at line 738 of file scale_fileio.F90.

References gtool_file_h::file_real4, gtool_file_h::file_real8, gtool_file::filecreate(), fileio_set_axes(), getcftunits(), scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::ia, scale_grid_index::ie, scale_grid_index::ieb, scale_grid_index::imaxb, scale_grid_index::is, scale_grid_index::isb, scale_grid_index::ja, scale_grid_index::je, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::js, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_rm_process::prc_2drank, scale_process::prc_masterrank, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), gtool_file::rmiss, scale_precision::rp, scale_time::time_nowdate, scale_time::time_nowdaysec, and scale_time::time_nowms.

738  use gtool_file, only: &
739  rmiss
740  use gtool_file_h, only: &
741  file_real8, &
742  file_real4
743  use gtool_file, only: &
744  filecreate, &
745  fileaddvariable, &
746  filesetglobalattribute, &
747  filewrite
748  use scale_process, only: &
749  prc_masterrank, &
750  prc_myrank, &
751  prc_mpistop
752  use scale_rm_process, only: &
753  prc_2drank
754  use scale_time, only: &
755  nowdate => time_nowdate, &
756  nowms => time_nowms, &
757  nowsec => time_nowdaysec
758  implicit none
759
760  real(RP), intent(in) :: var(:,:)
761  character(len=*), intent(in) :: basename
762  character(len=*), intent(in) :: title
763  character(len=*), intent(in) :: varname
764  character(len=*), intent(in) :: desc
765  character(len=*), intent(in) :: unit
766  character(len=*), intent(in) :: axistype
767  character(len=*), intent(in) :: datatype
768  integer, optional, intent(in) :: date(6)
769  real(DP),optional, intent(in) :: subsec
770  logical, optional, intent(in) :: append
771  logical, optional, intent(in) :: nohalo
772  logical, optional, intent(in) :: nozcoord
773
774  real(RP) :: varhalo( size(var(:,1)), size(var(1,:)) )
775
776  integer :: dtype
777  character(len=2) :: dims(2)
778  integer :: dim1_max, dim1_s, dim1_e
779  integer :: dim2_max, dim2_s, dim2_e
780  real(RP), allocatable :: var2d(:,:)
781
782  integer :: rankidx(2)
783  logical :: fileexisted
784  integer :: fid, vid
785  integer :: i, j
786  logical :: nohalo_
787  character(len=34) :: tunits
788  !---------------------------------------------------------------------------
789
790  call prof_rapstart('FILE_O_NetCDF', 2)
791
792  nohalo_ = .false.
793  if ( present(nohalo) ) nohalo_ = nohalo
794
795  rankidx(1) = prc_2drank(prc_myrank,1)
796  rankidx(2) = prc_2drank(prc_myrank,2)
797
798  if ( datatype == 'REAL8' ) then
799  dtype = file_real8
800  elseif( datatype == 'REAL4' ) then
801  dtype = file_real4
802  else
803  if ( rp == 8 ) then
804  dtype = file_real8
805  elseif( rp == 4 ) then
806  dtype = file_real4
807  else
808  write(*,*) 'xxx unsupported data type. Check!', trim(datatype), ' item:',trim(varname)
809  call prc_mpistop
810  endif
811  endif
812
813  call filecreate( fid, & ! [OUT]
814  fileexisted, & ! [OUT]
815  basename, & ! [IN]
816  title, & ! [IN]
817  h_source, & ! [IN]
818  h_institute, & ! [IN]
819  prc_masterrank, & ! [IN]
820  prc_myrank, & ! [IN]
821  rankidx, & ! [IN]
822  append = append ) ! [IN]
823
824  if ( axistype == 'XY' ) then
825  dims = (/'x','y'/)
826  dim1_max = imaxb
827  dim2_max = jmaxb
828  dim1_s = isb
829  dim1_e = ieb
830  dim2_s = jsb
831  dim2_e = jeb
832  elseif ( axistype == 'UY' ) then
833  dims = (/'xh','y '/)
834  dim1_max = imaxb
835  dim2_max = jmaxb
836  dim1_s = isb
837  dim1_e = ieb
838  dim2_s = jsb
839  dim2_e = jeb
840  elseif ( axistype == 'XV' ) then
841  dims = (/'x ','yh'/)
842  dim1_max = imaxb
843  dim2_max = jmaxb
844  dim1_s = isb
845  dim1_e = ieb
846  dim2_s = jsb
847  dim2_e = jeb
848  elseif ( axistype == 'UV' ) then
849  dims = (/'xh','yh'/)
850  dim1_max = imaxb
851  dim2_max = jmaxb
852  dim1_s = isb
853  dim1_e = ieb
854  dim2_s = jsb
855  dim2_e = jeb
856  elseif( axistype == 'ZX' ) then
857  dims = (/'z','x'/)
858  dim1_max = kmax
859  dim2_max = imaxb
860  dim1_s = ks
861  dim1_e = ke
862  dim2_s = isb
863  dim2_e = ieb
864  else
865  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
866  call prc_mpistop
867  endif
868
869  if ( .NOT. fileexisted ) then ! only once
870  call fileio_set_axes( fid, dtype, nozcoord ) ! [IN]
871  if ( present( subsec ) ) then
872  call filesetglobalattribute( fid, "time", (/subsec/) )
873  else
874  call filesetglobalattribute( fid, "time", (/nowms/) )
875  end if
876  if ( present( date ) ) then
877  call getcftunits(tunits, date)
878  else
879  call getcftunits(tunits, nowdate)
880  end if
881  call filesetglobalattribute( fid, "time_units", tunits )
882  endif
883
884  varhalo(:,:) = var(:,:)
885
886  if ( nohalo_ ) then
887  ! W halo
888  do j = 1, ja
889  do i = 1, is-1
890  varhalo(i,j) = rmiss
891  end do
892  end do
893  ! E halo
894  do j = 1, ja
895  do i = ie+1, ia
896  varhalo(i,j) = rmiss
897  end do
898  end do
899  ! S halo
900  do j = 1, js-1
901  do i = 1, ia
902  varhalo(i,j) = rmiss
903  end do
904  end do
905  ! N halo
906  do j = je+1, ja
907  do i = 1, ia
908  varhalo(i,j) = rmiss
909  end do
910  end do
911  end if
912
913  call fileaddvariable( vid, fid, varname, desc, unit, dims, dtype ) ! [IN]
914
915  allocate( var2d(dim1_max,dim2_max) )
916
917  var2d(1:dim1_max,1:dim2_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e)
918  call filewrite( fid, vid, var2d(:,:), nowsec, nowsec ) ! [IN]
919
920  deallocate( var2d )
921
922  call prof_rapend ('FILE_O_NetCDF', 2)
923
924  return
scale_grid_index::is
integer, public is
start point of inner domain: x, local
Definition: scale_grid_index.F90:60
gtool_file::filecreate
subroutine, public filecreate(fid, existed, basename, title, source, institution, master, myrank, rankidx, single, time_units, append)
Definition: gtool_file.f90:150
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_grid_index::je
integer, public je
end point of inner domain: y, local
Definition: scale_grid_index.F90:63
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_time::time_nowms
real(dp), public time_nowms
subsecond part of current time [millisec]
Definition: scale_time.F90:66
gtool_file::rmiss
real(dp), parameter, public rmiss
Definition: gtool_file.f90:110
scale_time::time_nowdaysec
real(dp), public time_nowdaysec
second of current time [sec]
Definition: scale_time.F90:69
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::ia
integer, public ia
of x whole cells (local, with HALO)
Definition: scale_grid_index.F90:55
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_grid_index::js
integer, public js
start point of inner domain: y, local
Definition: scale_grid_index.F90:62
scale_time
module TIME
Definition: scale_time.F90:15
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_process::prc_masterrank
integer, parameter, public prc_masterrank
master process in each communicator
Definition: scale_process.F90:56
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_rm_process
module RM PROCESS
Definition: scale_rm_process.F90:10
scale_grid_index::ie
integer, public ie
end point of inner domain: x, local
Definition: scale_grid_index.F90:61
scale_rm_process::prc_2drank
integer, dimension(:,:), allocatable, public prc_2drank
node index in 2D topology
Definition: scale_rm_process.F90:46
gtool_file_h::file_real4
integer, parameter, public file_real4
Definition: gtool_file_h.f90:43
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_time::time_nowdate
integer, dimension(6), public time_nowdate
current time [YYYY MM DD HH MM SS]
Definition: scale_time.F90:65
gtool_file_h
module FILE I/O HEADER
Definition: gtool_file_h.f90:14
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:38
gtool_file_h::file_real8
integer, parameter, public file_real8
Definition: gtool_file_h.f90:44
scale_grid_index::ja
integer, public ja
of y whole cells (local, with HALO)
Definition: scale_grid_index.F90:56
Here is the call graph for this function:

◆ fileio_write_3d()

subroutine scale_fileio::fileio_write_3d ( real(rp), dimension(:,:,:), intent(in)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  title,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  desc,
character(len=*), intent(in)  unit,
character(len=*), intent(in)  axistype,
character(len=*), intent(in)  datatype,
integer, dimension(6), intent(in), optional  date,
real(dp), intent(in), optional  subsec,
logical, intent(in), optional  append,
logical, intent(in), optional  nohalo
)

Write 3D data to file.

Parameters
[in]varvalue of the variable
[in]basenamebasename of the file
[in]titletitle of the file
[in]varnamename of the variable
[in]descdescription of the variable
[in]unitunit of the variable
[in]axistypeaxis type (Z/X/Y)
[in]datatypedata type (REAL8/REAL4/default)
[in]dateymdhms of the time
[in]subsecsubsec of the time
[in]appendappend existing (closed) file?
[in]nohaloinclude halo data?

Definition at line 942 of file scale_fileio.F90.

References gtool_file_h::file_real4, gtool_file_h::file_real8, gtool_file::filecreate(), fileio_set_axes(), getcftunits(), scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::ia, scale_grid_index::ie, scale_grid_index::ieb, scale_grid_index::imaxb, scale_grid_index::is, scale_grid_index::isb, scale_grid_index::ja, scale_grid_index::je, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::js, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_land_grid_index::lke, scale_land_grid_index::lkmax, scale_land_grid_index::lks, scale_rm_process::prc_2drank, scale_process::prc_masterrank, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), gtool_file::rmiss, scale_precision::rp, scale_time::time_nowdate, scale_time::time_nowdaysec, scale_time::time_nowms, scale_urban_grid_index::uke, scale_urban_grid_index::ukmax, and scale_urban_grid_index::uks.

942  use gtool_file, only: &
943  rmiss
944  use gtool_file_h, only: &
945  file_real8, &
946  file_real4
947  use gtool_file, only: &
948  filecreate, &
949  fileaddvariable, &
950  filesetglobalattribute, &
951  filewrite
952  use scale_process, only: &
953  prc_masterrank, &
954  prc_myrank, &
955  prc_mpistop
956  use scale_rm_process, only: &
957  prc_2drank
958  use scale_time, only: &
959  nowdate => time_nowdate, &
960  nowms => time_nowms, &
961  nowsec => time_nowdaysec
962  implicit none
963
964  real(RP), intent(in) :: var(:,:,:)
965  character(len=*), intent(in) :: basename
966  character(len=*), intent(in) :: title
967  character(len=*), intent(in) :: varname
968  character(len=*), intent(in) :: desc
969  character(len=*), intent(in) :: unit
970  character(len=*), intent(in) :: axistype
971  character(len=*), intent(in) :: datatype
972  integer, optional, intent(in) :: date(6)
973  real(DP),optional, intent(in) :: subsec
974  logical, optional, intent(in) :: append
975  logical, optional, intent(in) :: nohalo
976
977  real(RP) :: varhalo( size(var(:,1,1)), size(var(1,:,1)), size(var(1,1,:)) )
978
979  integer :: dtype
980  character(len=2) :: dims(3)
981  integer :: dim1_max, dim1_s, dim1_e
982  integer :: dim2_max, dim2_s, dim2_e
983  integer :: dim3_max, dim3_s, dim3_e
984
985  real(RP), allocatable :: var3d(:,:,:)
986
987  integer :: rankidx(2)
988  logical :: append_sw
989  logical :: fileexisted
990  integer :: fid, vid
991  integer :: i, j, k
992  logical :: nohalo_
993  character(len=34) :: tunits
994  !---------------------------------------------------------------------------
995
996  call prof_rapstart('FILE_O_NetCDF', 2)
997
998  nohalo_ = .false.
999  if ( present(nohalo) ) nohalo_ = nohalo
1000
1001  rankidx(1) = prc_2drank(prc_myrank,1)
1002  rankidx(2) = prc_2drank(prc_myrank,2)
1003
1004  if ( datatype == 'REAL8' ) then
1005  dtype = file_real8
1006  elseif( datatype == 'REAL4' ) then
1007  dtype = file_real4
1008  else
1009  if ( rp == 8 ) then
1010  dtype = file_real8
1011  elseif( rp == 4 ) then
1012  dtype = file_real4
1013  else
1014  write(*,*) 'xxx unsupported data type. Check!', trim(datatype), ' item:',trim(varname)
1015  call prc_mpistop
1016  endif
1017  endif
1018
1019  append_sw = .false.
1020  if ( present(append) ) then
1021  append_sw = append
1022  endif
1023
1024  call filecreate( fid, & ! [OUT]
1025  fileexisted, & ! [OUT]
1026  basename, & ! [IN]
1027  title, & ! [IN]
1028  h_source, & ! [IN]
1029  h_institute, & ! [IN]
1030  prc_masterrank, & ! [IN]
1031  prc_myrank, & ! [IN]
1032  rankidx, & ! [IN]
1033  append = append_sw ) ! [IN]
1034
1035  if ( .NOT. fileexisted ) then ! only once
1036  call fileio_set_axes( fid, dtype ) ! [IN]
1037  if ( present( subsec ) ) then
1038  call filesetglobalattribute( fid, "time", (/subsec/) )
1039  else
1040  call filesetglobalattribute( fid, "time", (/nowms/) )
1041  end if
1042  if ( present( date ) ) then
1043  call getcftunits(tunits, date)
1044  else
1045  call getcftunits(tunits, nowdate)
1046  end if
1047  call filesetglobalattribute( fid, "time_units", tunits )
1048  endif
1049
1050  if ( axistype == 'ZXY' ) then
1051  dims = (/'z','x','y'/)
1052  dim1_max = kmax
1053  dim2_max = imaxb
1054  dim3_max = jmaxb
1055  dim1_s = ks
1056  dim1_e = ke
1057  dim2_s = isb
1058  dim2_e = ieb
1059  dim3_s = jsb
1060  dim3_e = jeb
1061  elseif( axistype == 'ZHXY' ) then
1062  dims = (/'zh','x ','y '/)
1063  dim1_max = kmax
1064  dim2_max = imaxb
1065  dim3_max = jmaxb
1066  dim1_s = ks
1067  dim1_e = ke
1068  dim2_s = isb
1069  dim2_e = ieb
1070  dim3_s = jsb
1071  dim3_e = jeb
1072  elseif( axistype == 'ZXHY' ) then
1073  dims = (/'z ','xh','y '/)
1074  dim1_max = kmax
1075  dim2_max = imaxb
1076  dim3_max = jmaxb
1077  dim1_s = ks
1078  dim1_e = ke
1079  dim2_s = isb
1080  dim2_e = ieb
1081  dim3_s = jsb
1082  dim3_e = jeb
1083  elseif( axistype == 'ZXYH' ) then
1084  dims = (/'z ','x ','yh'/)
1085  dim1_max = kmax
1086  dim2_max = imaxb
1087  dim3_max = jmaxb
1088  dim1_s = ks
1089  dim1_e = ke
1090  dim2_s = isb
1091  dim2_e = ieb
1092  dim3_s = jsb
1093  dim3_e = jeb
1094  elseif( axistype == 'Land' ) then
1095  dims = (/'lz','x ','y '/)
1096  dim1_max = lkmax
1097  dim2_max = imaxb
1098  dim3_max = jmaxb
1099  dim1_s = lks
1100  dim1_e = lke
1101  dim2_s = isb
1102  dim2_e = ieb
1103  dim3_s = jsb
1104  dim3_e = jeb
1105  elseif( axistype == 'Urban' ) then
1106  dims = (/'uz','x ','y '/)
1107  dim1_max = ukmax
1108  dim2_max = imaxb
1109  dim3_max = jmaxb
1110  dim1_s = uks
1111  dim1_e = uke
1112  dim2_s = isb
1113  dim2_e = ieb
1114  dim3_s = jsb
1115  dim3_e = jeb
1116  else
1117  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
1118  call prc_mpistop
1119  endif
1120
1121  varhalo(:,:,:) = var(:,:,:)
1122
1123  if ( nohalo_ ) then
1124  ! W halo
1125  do k = 1, dim1_max
1126  do j = 1, ja
1127  do i = 1, is-1
1128  varhalo(k,i,j) = rmiss
1129  end do
1130  end do
1131  end do
1132  ! E halo
1133  do k = 1, dim1_max
1134  do j = 1, ja
1135  do i = ie+1, ia
1136  varhalo(k,i,j) = rmiss
1137  end do
1138  end do
1139  end do
1140  ! S halo
1141  do k = 1, dim1_max
1142  do j = 1, js-1
1143  do i = 1, ia
1144  varhalo(k,i,j) = rmiss
1145  end do
1146  end do
1147  end do
1148  ! N halo
1149  do k = 1, dim1_max
1150  do j = je+1, ja
1151  do i = 1, ia
1152  varhalo(k,i,j) = rmiss
1153  end do
1154  end do
1155  end do
1156  end if
1157
1158  call fileaddvariable( vid, fid, varname, desc, unit, dims, dtype ) ! [IN]
1159
1160  allocate( var3d(dim1_max,dim2_max,dim3_max) )
1161
1162  var3d(1:dim1_max,1:dim2_max,1:dim3_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e,dim3_s:dim3_e)
1163  call filewrite( fid, vid, var3d(:,:,:), nowsec, nowsec ) ! [IN]
1164
1165  deallocate( var3d )
1166
1167  call prof_rapend ('FILE_O_NetCDF', 2)
1168
1169  return
scale_grid_index::is
integer, public is
start point of inner domain: x, local
Definition: scale_grid_index.F90:60
gtool_file::filecreate
subroutine, public filecreate(fid, existed, basename, title, source, institution, master, myrank, rankidx, single, time_units, append)
Definition: gtool_file.f90:150
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_grid_index::je
integer, public je
end point of inner domain: y, local
Definition: scale_grid_index.F90:63
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
scale_time::time_nowms
real(dp), public time_nowms
subsecond part of current time [millisec]
Definition: scale_time.F90:66
gtool_file::rmiss
real(dp), parameter, public rmiss
Definition: gtool_file.f90:110
scale_time::time_nowdaysec
real(dp), public time_nowdaysec
second of current time [sec]
Definition: scale_time.F90:69
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::ia
integer, public ia
of x whole cells (local, with HALO)
Definition: scale_grid_index.F90:55
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_grid_index::js
integer, public js
start point of inner domain: y, local
Definition: scale_grid_index.F90:62
scale_time
module TIME
Definition: scale_time.F90:15
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_process::prc_masterrank
integer, parameter, public prc_masterrank
master process in each communicator
Definition: scale_process.F90:56
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_rm_process
module RM PROCESS
Definition: scale_rm_process.F90:10
scale_grid_index::ie
integer, public ie
end point of inner domain: x, local
Definition: scale_grid_index.F90:61
scale_rm_process::prc_2drank
integer, dimension(:,:), allocatable, public prc_2drank
node index in 2D topology
Definition: scale_rm_process.F90:46
gtool_file_h::file_real4
integer, parameter, public file_real4
Definition: gtool_file_h.f90:43
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
scale_time::time_nowdate
integer, dimension(6), public time_nowdate
current time [YYYY MM DD HH MM SS]
Definition: scale_time.F90:65
gtool_file_h
module FILE I/O HEADER
Definition: gtool_file_h.f90:14
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:38
gtool_file_h::file_real8
integer, parameter, public file_real8
Definition: gtool_file_h.f90:44
scale_grid_index::ja
integer, public ja
of y whole cells (local, with HALO)
Definition: scale_grid_index.F90:56
Here is the call graph for this function:

◆ fileio_write_3d_t()

subroutine scale_fileio::fileio_write_3d_t ( real(rp), dimension(:,:,:), intent(in)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  title,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  desc,
character(len=*), intent(in)  unit,
character(len=*), intent(in)  axistype,
character(len=*), intent(in)  datatype,
real(rp), intent(in)  timeintv,
integer, dimension(6), intent(in)  tsince,
logical, intent(in), optional  append,
integer, intent(in), optional  timetarg,
logical, intent(in), optional  nohalo
)

Write 3D data with time dimension to file.

Parameters
[in]varvalue of the variable
[in]basenamebasename of the file
[in]titletitle of the file
[in]varnamename of the variable
[in]descdescription of the variable
[in]unitunit of the variable
[in]axistypeaxis type (X/Y/Time)
[in]datatypedata type (REAL8/REAL4/default)
[in]timeintvtime interval [sec]
[in]tsincestart time
[in]appendappend existing (closed) file?
[in]timetargtarget timestep (optional)
[in]nohaloinclude halo data?

Definition at line 1188 of file scale_fileio.F90.

References gtool_file_h::file_real4, gtool_file_h::file_real8, gtool_file::filecreate(), fileio_set_axes(), scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::ia, scale_grid_index::ie, scale_grid_index::ieb, scale_grid_index::imaxb, scale_grid_index::is, scale_grid_index::isb, scale_grid_index::ja, scale_grid_index::je, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::js, scale_grid_index::jsb, scale_rm_process::prc_2drank, scale_process::prc_masterrank, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), gtool_file::rmiss, and scale_precision::rp.

1188  use gtool_file, only: &
1189  rmiss
1190  use gtool_file_h, only: &
1191  file_real8, &
1192  file_real4
1193  use gtool_file, only: &
1194  filecreate, &
1195  fileputaxis, &
1196  fileaddvariable, &
1197  filewrite
1198  use scale_process, only: &
1199  prc_masterrank, &
1200  prc_myrank, &
1201  prc_mpistop
1202  use scale_rm_process, only: &
1203  prc_2drank
1204  implicit none
1205
1206  real(RP), intent(in) :: var(:,:,:)
1207  character(len=*), intent(in) :: basename
1208  character(len=*), intent(in) :: title
1209  character(len=*), intent(in) :: varname
1210  character(len=*), intent(in) :: desc
1211  character(len=*), intent(in) :: unit
1212  character(len=*), intent(in) :: axistype
1213  character(len=*), intent(in) :: datatype
1214  real(RP), intent(in) :: timeintv
1215  integer , intent(in) :: tsince(6)
1216  logical, optional, intent(in) :: append
1217  integer, optional, intent(in) :: timetarg
1218  logical, optional, intent(in) :: nohalo
1219
1220  real(RP) :: varhalo( size(var(:,1,1)), size(var(1,:,1)) )
1221
1222  integer :: dtype
1223  character(len=2) :: dims(2)
1224  integer :: dim1_max, dim1_s, dim1_e
1225  integer :: dim2_max, dim2_s, dim2_e
1226
1227  real(RP), allocatable :: var2d(:,:)
1228  real(DP) :: time_interval, nowtime
1229
1230  character(len=34) :: tunits
1231
1232  integer :: rankidx(2)
1233  logical :: append_sw
1234  logical :: fileexisted
1235  integer :: fid, vid
1236  integer :: step
1237  integer :: i, j, n
1238  logical :: nohalo_
1239  !---------------------------------------------------------------------------
1240
1241  call prof_rapstart('FILE_O_NetCDF', 2)
1242
1243  nohalo_ = .false.
1244  if ( present(nohalo) ) nohalo_ = nohalo
1245
1246  time_interval = timeintv
1247  step = size(var(isb,jsb,:))
1248
1249  rankidx(1) = prc_2drank(prc_myrank,1)
1250  rankidx(2) = prc_2drank(prc_myrank,2)
1251
1252  if ( datatype == 'REAL8' ) then
1253  dtype = file_real8
1254  elseif( datatype == 'REAL4' ) then
1255  dtype = file_real4
1256  else
1257  if ( rp == 8 ) then
1258  dtype = file_real8
1259  elseif( rp == 4 ) then
1260  dtype = file_real4
1261  else
1262  write(*,*) 'xxx unsupported data type. Check!', trim(datatype), ' item:',trim(varname)
1263  call prc_mpistop
1264  endif
1265  endif
1266
1267  append_sw = .false.
1268  if ( present(append) ) then
1269  append_sw = append
1270  endif
1271
1272  write(tunits,'(a,i4.4,"-",i2.2,"-",i2.2," ",i2.2,":",i2.2,":",i2.2)') 'seconds since ', tsince
1273
1274  call filecreate( fid, & ! [OUT]
1275  fileexisted, & ! [OUT]
1276  basename, & ! [IN]
1277  title, & ! [IN]
1278  h_source, & ! [IN]
1279  h_institute, & ! [IN]
1280  prc_masterrank, & ! [IN]
1281  prc_myrank, & ! [IN]
1282  rankidx, & ! [IN]
1283  time_units = tunits, & ! [IN]
1284  append = append_sw ) ! [IN]
1285
1286  if ( .NOT. fileexisted ) then ! only once
1287  call fileio_set_axes( fid, dtype ) ! [IN]
1288  endif
1289
1290  if ( axistype == 'XYT' ) then
1291  dims = (/'x','y'/)
1292  dim1_max = imaxb
1293  dim2_max = jmaxb
1294  dim1_s = isb
1295  dim1_e = ieb
1296  dim2_s = jsb
1297  dim2_e = jeb
1298  else
1299  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
1300  call prc_mpistop
1301  endif
1302
1303  call fileaddvariable( vid, fid, varname, desc, unit, dims, dtype, time_interval ) ! [IN]
1304  allocate( var2d(dim1_max,dim2_max) )
1305
1306  if ( present(timetarg) ) then
1307  varhalo(:,:) = var(:,:,timetarg)
1308
1309  if ( nohalo_ ) then
1310  ! W halo
1311  do j = 1, ja
1312  do i = 1, is-1
1313  varhalo(i,j) = rmiss
1314  end do
1315  end do
1316  ! E halo
1317  do j = 1, ja
1318  do i = ie+1, ia
1319  varhalo(i,j) = rmiss
1320  end do
1321  end do
1322  ! S halo
1323  do j = 1, js-1
1324  do i = 1, ia
1325  varhalo(i,j) = rmiss
1326  end do
1327  end do
1328  ! N halo
1329  do j = je+1, ja
1330  do i = 1, ia
1331  varhalo(i,j) = rmiss
1332  end do
1333  end do
1334  end if
1335
1336  nowtime = (timetarg-1) * time_interval
1337  var2d(1:dim1_max,1:dim2_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e)
1338  call filewrite( fid, vid, var2d(:,:), nowtime, nowtime ) ! [IN]
1339  else
1340  nowtime = 0.0_dp
1341  do n = 1, step
1342  varhalo(:,:) = var(:,:,n)
1343
1344  if ( nohalo_ ) then
1345  ! W halo
1346  do j = 1, ja
1347  do i = 1, is-1
1348  varhalo(i,j) = rmiss
1349  end do
1350  end do
1351  ! E halo
1352  do j = 1, ja
1353  do i = ie+1, ia
1354  varhalo(i,j) = rmiss
1355  end do
1356  end do
1357  ! S halo
1358  do j = 1, js-1
1359  do i = 1, ia
1360  varhalo(i,j) = rmiss
1361  end do
1362  end do
1363  ! N halo
1364  do j = je+1, ja
1365  do i = 1, ia
1366  varhalo(i,j) = rmiss
1367  end do
1368  end do
1369  end if
1370
1371  var2d(1:dim1_max,1:dim2_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e)
1372  call filewrite( fid, vid, var2d(:,:), nowtime, nowtime ) ! [IN]
1373  nowtime = nowtime + time_interval
1374  enddo
1375  endif
1376
1377  deallocate( var2d )
1378
1379  call prof_rapend ('FILE_O_NetCDF', 2)
1380
1381  return
scale_grid_index::is
integer, public is
start point of inner domain: x, local
Definition: scale_grid_index.F90:60
gtool_file::filecreate
subroutine, public filecreate(fid, existed, basename, title, source, institution, master, myrank, rankidx, single, time_units, append)
Definition: gtool_file.f90:150
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_grid_index::je
integer, public je
end point of inner domain: y, local
Definition: scale_grid_index.F90:63
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
gtool_file::rmiss
real(dp), parameter, public rmiss
Definition: gtool_file.f90:110
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::ia
integer, public ia
of x whole cells (local, with HALO)
Definition: scale_grid_index.F90:55
scale_grid_index::js
integer, public js
start point of inner domain: y, local
Definition: scale_grid_index.F90:62
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_process::prc_masterrank
integer, parameter, public prc_masterrank
master process in each communicator
Definition: scale_process.F90:56
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_rm_process
module RM PROCESS
Definition: scale_rm_process.F90:10
scale_grid_index::ie
integer, public ie
end point of inner domain: x, local
Definition: scale_grid_index.F90:61
scale_rm_process::prc_2drank
integer, dimension(:,:), allocatable, public prc_2drank
node index in 2D topology
Definition: scale_rm_process.F90:46
gtool_file_h::file_real4
integer, parameter, public file_real4
Definition: gtool_file_h.f90:43
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
gtool_file_h
module FILE I/O HEADER
Definition: gtool_file_h.f90:14
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:38
gtool_file_h::file_real8
integer, parameter, public file_real8
Definition: gtool_file_h.f90:44
scale_grid_index::ja
integer, public ja
of y whole cells (local, with HALO)
Definition: scale_grid_index.F90:56
Here is the call graph for this function:

◆ fileio_write_4d()

subroutine scale_fileio::fileio_write_4d ( real(rp), dimension(:,:,:,:), intent(in)  var,
character(len=*), intent(in)  basename,
character(len=*), intent(in)  title,
character(len=*), intent(in)  varname,
character(len=*), intent(in)  desc,
character(len=*), intent(in)  unit,
character(len=*), intent(in)  axistype,
character(len=*), intent(in)  datatype,
real(rp), intent(in)  timeintv,
integer, dimension(6), intent(in)  tsince,
logical, intent(in), optional  append,
integer, intent(in), optional  timetarg,
logical, intent(in), optional  nohalo
)

Write 4D data to file.

Parameters
[in]varvalue of the variable
[in]basenamebasename of the file
[in]titletitle of the file
[in]varnamename of the variable
[in]descdescription of the variable
[in]unitunit of the variable
[in]axistypeaxis type (Z/X/Y/Time)
[in]datatypedata type (REAL8/REAL4/default)
[in]timeintvtime interval [sec]
[in]tsincestart time
[in]appendappend existing (closed) file?
[in]timetargtarget timestep (optional)
[in]nohaloinclude halo data?

Definition at line 1400 of file scale_fileio.F90.

References gtool_file_h::file_real4, gtool_file_h::file_real8, gtool_file::filecreate(), fileio_set_axes(), getcftunits(), scale_stdio::h_institute, scale_stdio::h_source, scale_grid_index::ia, scale_grid_index::ie, scale_grid_index::ieb, scale_grid_index::imaxb, scale_grid_index::is, scale_grid_index::isb, scale_grid_index::ja, scale_grid_index::je, scale_grid_index::jeb, scale_grid_index::jmaxb, scale_grid_index::js, scale_grid_index::jsb, scale_grid_index::ke, scale_grid_index::kmax, scale_grid_index::ks, scale_rm_process::prc_2drank, scale_process::prc_masterrank, scale_process::prc_mpistop(), scale_process::prc_myrank, scale_prof::prof_rapend(), scale_prof::prof_rapstart(), gtool_file::rmiss, and scale_precision::rp.

1400  use gtool_file, only: &
1401  rmiss
1402  use gtool_file_h, only: &
1403  file_real8, &
1404  file_real4
1405  use gtool_file, only: &
1406  filecreate, &
1407  fileputaxis, &
1408  fileaddvariable, &
1409  filewrite
1410  use scale_process, only: &
1411  prc_masterrank, &
1412  prc_myrank, &
1413  prc_mpistop
1414  use scale_rm_process, only: &
1415  prc_2drank
1416  implicit none
1417
1418  real(RP), intent(in) :: var(:,:,:,:)
1419  character(len=*), intent(in) :: basename
1420  character(len=*), intent(in) :: title
1421  character(len=*), intent(in) :: varname
1422  character(len=*), intent(in) :: desc
1423  character(len=*), intent(in) :: unit
1424  character(len=*), intent(in) :: axistype
1425  character(len=*), intent(in) :: datatype
1426  real(RP), intent(in) :: timeintv
1427  integer , intent(in) :: tsince(6)
1428  logical, optional, intent(in) :: append
1429  integer, optional, intent(in) :: timetarg
1430  logical, optional, intent(in) :: nohalo
1431
1432  real(RP) :: varhalo( size(var(:,1,1,1)), size(var(1,:,1,1)), size(var(1,1,:,1)) )
1433
1434  integer :: dtype
1435  character(len=2) :: dims(3)
1436  integer :: dim1_max, dim1_s, dim1_e
1437  integer :: dim2_max, dim2_s, dim2_e
1438  integer :: dim3_max, dim3_s, dim3_e
1439
1440  real(RP), allocatable :: var3d(:,:,:)
1441  real(DP) :: time_interval, nowtime
1442
1443  character(len=34) :: tunits
1444
1445  integer :: rankidx(2)
1446  logical :: append_sw
1447  logical :: fileexisted
1448  integer :: fid, vid
1449  integer :: step
1450  integer :: i, j, k, n
1451  logical :: nohalo_
1452  !---------------------------------------------------------------------------
1453
1454  call prof_rapstart('FILE_O_NetCDF', 2)
1455
1456  nohalo_ = .false.
1457  if ( present(nohalo) ) nohalo_ = nohalo
1458
1459  time_interval = timeintv
1460  step = size(var(ks,isb,jsb,:))
1461
1462  rankidx(1) = prc_2drank(prc_myrank,1)
1463  rankidx(2) = prc_2drank(prc_myrank,2)
1464
1465  if ( datatype == 'REAL8' ) then
1466  dtype = file_real8
1467  elseif( datatype == 'REAL4' ) then
1468  dtype = file_real4
1469  else
1470  if ( rp == 8 ) then
1471  dtype = file_real8
1472  elseif( rp == 4 ) then
1473  dtype = file_real4
1474  else
1475  write(*,*) 'xxx unsupported data type. Check!', trim(datatype), ' item:',trim(varname)
1476  call prc_mpistop
1477  endif
1478  endif
1479
1480  append_sw = .false.
1481  if ( present(append) ) then
1482  append_sw = append
1483  endif
1484
1485  call getcftunits(tunits, tsince)
1486
1487  call filecreate( fid, & ! [OUT]
1488  fileexisted, & ! [OUT]
1489  basename, & ! [IN]
1490  title, & ! [IN]
1491  h_source, & ! [IN]
1492  h_institute, & ! [IN]
1493  prc_masterrank, & ! [IN]
1494  prc_myrank, & ! [IN]
1495  rankidx, & ! [IN]
1496  time_units = tunits, & ! [IN]
1497  append = append_sw ) ! [IN]
1498
1499  if ( .NOT. fileexisted ) then ! only once
1500  call fileio_set_axes( fid, dtype ) ! [IN]
1501  endif
1502
1503  if ( axistype == 'ZXYT' ) then
1504  dims = (/'z','x','y'/)
1505  dim1_max = kmax
1506  dim2_max = imaxb
1507  dim3_max = jmaxb
1508  dim1_s = ks
1509  dim1_e = ke
1510  dim2_s = isb
1511  dim2_e = ieb
1512  dim3_s = jsb
1513  dim3_e = jeb
1514  else
1515  write(*,*) 'xxx unsupported axis type. Check!', trim(axistype), ' item:',trim(varname)
1516  call prc_mpistop
1517  endif
1518
1519  call fileaddvariable( vid, fid, varname, desc, unit, dims, dtype, time_interval ) ! [IN]
1520  allocate( var3d(dim1_max,dim2_max,dim3_max) )
1521
1522  if ( present(timetarg) ) then
1523  varhalo(:,:,:) = var(:,:,:,timetarg)
1524
1525  if ( nohalo_ ) then
1526  ! W halo
1527  do k = 1, dim1_max
1528  do j = 1, ja
1529  do i = 1, is-1
1530  varhalo(k,i,j) = rmiss
1531  end do
1532  end do
1533  end do
1534  ! E halo
1535  do k = 1, dim1_max
1536  do j = 1, ja
1537  do i = ie+1, ia
1538  varhalo(k,i,j) = rmiss
1539  end do
1540  end do
1541  end do
1542  ! S halo
1543  do k = 1, dim1_max
1544  do j = 1, js-1
1545  do i = 1, ia
1546  varhalo(k,i,j) = rmiss
1547  end do
1548  end do
1549  end do
1550  ! N halo
1551  do k = 1, dim1_max
1552  do j = je+1, ja
1553  do i = 1, ia
1554  varhalo(k,i,j) = rmiss
1555  end do
1556  end do
1557  end do
1558  end if
1559
1560  nowtime = (timetarg-1) * time_interval
1561  var3d(1:dim1_max,1:dim2_max,1:dim3_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e,dim3_s:dim3_e)
1562  call filewrite( fid, vid, var3d(:,:,:), nowtime, nowtime ) ! [IN]
1563  else
1564  nowtime = 0.0_dp
1565  do n = 1, step
1566  varhalo(:,:,:) = var(:,:,:,n)
1567
1568  if ( nohalo_ ) then
1569  ! W halo
1570  do k = 1, dim1_max
1571  do j = 1, ja
1572  do i = 1, is-1
1573  varhalo(k,i,j) = rmiss
1574  end do
1575  end do
1576  end do
1577  ! E halo
1578  do k = 1, dim1_max
1579  do j = 1, ja
1580  do i = ie+1, ia
1581  varhalo(k,i,j) = rmiss
1582  end do
1583  end do
1584  end do
1585  ! S halo
1586  do k = 1, dim1_max
1587  do j = 1, js-1
1588  do i = 1, ia
1589  varhalo(k,i,j) = rmiss
1590  end do
1591  end do
1592  end do
1593  ! N halo
1594  do k = 1, dim1_max
1595  do j = je+1, ja
1596  do i = 1, ia
1597  varhalo(k,i,j) = rmiss
1598  end do
1599  end do
1600  end do
1601  end if
1602
1603  var3d(1:dim1_max,1:dim2_max,1:dim3_max) = varhalo(dim1_s:dim1_e,dim2_s:dim2_e,dim3_s:dim3_e)
1604  call filewrite( fid, vid, var3d(:,:,:), nowtime, nowtime ) ! [IN]
1605  nowtime = nowtime + time_interval
1606  enddo
1607  endif
1608
1609  deallocate( var3d )
1610
1611  call prof_rapend ('FILE_O_NetCDF', 2)
1612
1613  return
scale_grid_index::is
integer, public is
start point of inner domain: x, local
Definition: scale_grid_index.F90:60
gtool_file::filecreate
subroutine, public filecreate(fid, existed, basename, title, source, institution, master, myrank, rankidx, single, time_units, append)
Definition: gtool_file.f90:150
gtool_file
module GTOOL_FILE
Definition: gtool_file.f90:17
scale_grid_index::je
integer, public je
end point of inner domain: y, local
Definition: scale_grid_index.F90:63
scale_process::prc_mpistop
subroutine, public prc_mpistop
Abort MPI.
Definition: scale_process.F90:234
scale_grid_index::jeb
integer, public jeb
Definition: scale_grid_index.F90:74
gtool_file::rmiss
real(dp), parameter, public rmiss
Definition: gtool_file.f90:110
scale_grid_index::ke
integer, public ke
end point of inner domain: z, local
Definition: scale_grid_index.F90:59
scale_grid_index::imaxb
integer, public imaxb
Definition: scale_grid_index.F90:69
scale_grid_index::jmaxb
integer, public jmaxb
Definition: scale_grid_index.F90:70
scale_grid_index::ieb
integer, public ieb
Definition: scale_grid_index.F90:72
scale_grid_index::ia
integer, public ia
of x whole cells (local, with HALO)
Definition: scale_grid_index.F90:55
scale_grid_index::kmax
integer, public kmax
of computational cells: z
Definition: scale_grid_index.F90:43
scale_grid_index::js
integer, public js
start point of inner domain: y, local
Definition: scale_grid_index.F90:62
scale_process
module PROCESS
Definition: scale_process.F90:14
scale_process::prc_masterrank
integer, parameter, public prc_masterrank
master process in each communicator
Definition: scale_process.F90:56
scale_grid_index::ks
integer, public ks
start point of inner domain: z, local
Definition: scale_grid_index.F90:58
scale_process::prc_myrank
integer, public prc_myrank
process num in local communicator
Definition: scale_process.F90:78
scale_prof::prof_rapstart
subroutine, public prof_rapstart(rapname_base, level)
Start raptime.
Definition: scale_prof.F90:132
scale_rm_process
module RM PROCESS
Definition: scale_rm_process.F90:10
scale_grid_index::ie
integer, public ie
end point of inner domain: x, local
Definition: scale_grid_index.F90:61
scale_rm_process::prc_2drank
integer, dimension(:,:), allocatable, public prc_2drank
node index in 2D topology
Definition: scale_rm_process.F90:46
gtool_file_h::file_real4
integer, parameter, public file_real4
Definition: gtool_file_h.f90:43
scale_grid_index::isb
integer, public isb
Definition: scale_grid_index.F90:71
gtool_file_h
module FILE I/O HEADER
Definition: gtool_file_h.f90:14
scale_grid_index::jsb
integer, public jsb
Definition: scale_grid_index.F90:73
scale_prof::prof_rapend
subroutine, public prof_rapend(rapname_base, level)
Save raptime.
Definition: scale_prof.F90:178
scale_precision::rp
integer, parameter, public rp
Definition: scale_precision.F90:38
gtool_file_h::file_real8
integer, parameter, public file_real8
Definition: gtool_file_h.f90:44
scale_grid_index::ja
integer, public ja
of y whole cells (local, with HALO)
Definition: scale_grid_index.F90:56
Here is the call graph for this function:

◆ getcftunits()

subroutine scale_fileio::getcftunits ( character(len=34), intent(out)  tunits,
integer, dimension(6), intent(in)  date
)

Definition at line 1619 of file scale_fileio.F90.

Referenced by fileio_write_1d(), fileio_write_2d(), fileio_write_3d(), and fileio_write_4d().

1619  character(len=34), intent(out) :: tunits
1620  integer, intent(in) :: date(6)
1621
1622  write(tunits,'(a,i4.4,"-",i2.2,"-",i2.2," ",i2.2,":",i2.2,":",i2.2)') 'seconds since ', date
1623
1624  return
Here is the caller graph for this function:
Generated by   doxygen 1.8.13
